Quick Details
-
Mounting Type:
-
Ground Mounting
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LUNA
-
Model Number:
-
LNT26
-
Output Voltage (V):
-
48V/51.2V
-
Product name1::
-
Energy Storage Cabinet
-
Size:
-
600x600x1600mm
-
Nominal Voltage ::
-
48V/51.2V
-
Warranty::
-
5~10 Years
-
Battery Type::
-
LiFePo4, Lifepo4 Battery
-
Discharge Cut-off Voltage::
-
45V±1.0V(15S);48V±1.0V(16S)
-
communication protocol::
-
CAN/RS485/RS232
-
Color::
-
black
-
Installation method:
-
cabinet type
-
Cycle life:
-
>3000weeks 80%DOD
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LUNA
-
Model Number:
-
LNT26
-
Output Voltage (V):
-
48V/51.2V
-
Product name1::
-
Energy Storage Cabinet
-
Size:
-
600x600x1600mm
-
Nominal Voltage ::
-
48V/51.2V
-
Warranty::
-
5~10 Years
-
Battery Type::
-
LiFePo4, Lifepo4 Battery
-
Discharge Cut-off Voltage::
-
45V±1.0V(15S);48V±1.0V(16S)
-
communication protocol::
-
CAN/RS485/RS232
-
Color::
-
black
-
Installation method:
-
cabinet type
-
Cycle life:
-
>3000weeks 80%DOD
Specification
|
Nominal Voltage
|
48/51.2V（Optional）
|
|
|
|
|
|
|||||
|
Capacity
|
600Ah
|
800Ah
|
1000Ah
|
1200Ah
|
1400Ah
|
1600Ah
|
|||||
|
Energy
|
30KWH
|
40KWH
|
50KWH
|
60KWH
|
70KWH
|
80KWH
|
|||||
|
Internal Resistance
|
≤60mΩ
|
|
|
|
|
|
|||||
|
Cycle Life
|
≥6000cycles@90%DOD,25℃，0.5C
|
|
|
|
|
|
|||||
|
Design Life
|
≥10 years
|
|
|
|
|
|
|||||
|
Charge Cut-off Voltage
|
53V ±0.5V(15S);56.0V±0.5V(16S);
|
|
|
|
|
|
|||||
|
Max. Continuous
Work Current |
200Ah
|
300Ah
|
400Ah
|
400Ah
|
400Ah
|
400Ah
|
|||||
|
Discharge Cut-off Voltage
|
45V±1.0V(15S);48V±1.0V(16S);
|
45V±1.0V(15S);48V±1.0V(16S);
|
|
|
|
|
|||||
|
Charge Temperature
|
0℃~60℃
|
|
|
|
|
|
|||||
|
Storage Temperature
|
-20℃~60℃
|
|
|
|
|
|
|||||
|
Dimensions
|
600*800*988cm
|
600*800*1166 cm
|
600*800*1388 cm
|
600*800*1610 cm
|
600*800*1833 cm
|
600*800* 2055 cm
|
|||||
|
Weight
|
350kg
|
460kg
|
570kg
|
680kg
|
780kg
|
900kg
|
|||||
|
Protocol (optional)
|
RS232-PC,RS485(B)-PC
RS485(A)-Inverter,Canbus-Inverter
|
|
|
|
|
|
|||||
|
Batteries in parallel
|
Support up to 10 batteries in parallel
|
|
|
|
|
|
|||||
|
Certification
|
UN38.3,MSDS,UL1973(Cell),IEC62619(Cell)
|
|
|
|
|
|
|||||
Product Description
1.Support a variety of communications
2.Can communicate with a variety of inverters
2.Can communicate with a variety of inverters
Products cover 30-80KWH capacity segment;
The product supports parallel connection and expansion
The product supports parallel connection and expansion
