Quick Details
-
Brand Name:
-
Forlong
-
Model Number:
-
DDSY1286
-
Accuracy Class:
-
1
-
Output Voltage:
-
230V
-
Operating Temperature:
-
-33°c ~+55°c
-
Dimensions:
-
115x198x65mm
-
color:
-
grey
-
nameplate:
-
OEM
Quick Details
-
Phase:
-
Single Phase
-
Measuring Energy Range:
-
0-999999
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Forlong
-
Model Number:
-
DDSY1286
-
Accuracy Class:
-
1
-
Output Voltage:
-
230V
-
Operating Temperature:
-
-33°c ~+55°c
-
Dimensions:
-
115x198x65mm
-
color:
-
grey
-
nameplate:
-
OEM
Single Phase Prepaid electric meter with insert card with card reader power meter
1.Purpose and applicable scope
DDSY1286, single phase electronic pre-payment watt-hour meter, is the new type of watt-hour meter developed by our company that has multi-functions like electricity energy measuring, load control, user information management etc. It is the high-tech product adopting large-scaled integrated circuit technology and advanced microcomputer and IC card technology.
This product can be installed in the watt-meter box indoor and outdoor, and is suitable for the environment where the temperature is -30°C~55°C and the relative humidity is not more than 85%.
This product meet IECF 62053-21; GB/T17215-2002 alternating current static watt-hour meters for active energy (classes 1 and 2) and GB/T18460-2001 Pre-payment vending system using integrated circuit(s) cards with contacts.
2.Specification and main technical parameters
1) Rated voltage: 220V
2) Standard current: 5 (30) A, 5 (40) A, 10 (40) A, 10 (60) A
3) Rated frequency: 50Hz
4) Accuracy: Class 1
5) Start current: 0.4%Ib (Class 1)
6) Shunt running: has the logic circuit to prevent shunt running.
7) Power consumption: ≤1.5W/6VA
8) Environmental condition: normal working temperature: -10°C~45°C, Ultimate working temperature: -30°C~55°C
9) Relative humidity: ≤85%
10) Weight: about 750g
11) Dimension: 195 x 116 x 65mm
