Quick Details
-
Model Number:
-
K800GE-1U, Q800GE-1U
-
Place of Origin:
-
Guangdong, China
-
Ports:
-
8*i211 LAN+1*HD Video+1*RS232+2*USB2.0+4*USB3.0
-
OS:
-
Linux/win7/win8/win10/win 11
-
Material:
-
Aluminum
-
Operating Temp:
-
0°C~50°C
-
Memory:
-
1 x DDR4 SO-DIMM Socket (Up to 32G, 2133/2400MHz)
-
Storage:
-
1 x mSATA, 1 x Mini PCIe, 1 x M.2, 1 x SATA 3.0
-
Audio:
-
Intel HD Graphics 610
-
Watch Dog:
-
Yes
-
Product Name:
-
1U Rack Mini PC
Quick Details
-
Type:
-
Rack
-
Processor Type:
-
Intel
-
Brand Name:
-
Kansung
-
Model Number:
-
K800GE-1U, Q800GE-1U
-
Place of Origin:
-
Guangdong, China
-
Ports:
-
8*i211 LAN+1*HD Video+1*RS232+2*USB2.0+4*USB3.0
-
OS:
-
Linux/win7/win8/win10/win 11
-
Material:
-
Aluminum
-
Operating Temp:
-
0°C~50°C
-
Memory:
-
1 x DDR4 SO-DIMM Socket (Up to 32G, 2133/2400MHz)
-
Storage:
-
1 x mSATA, 1 x Mini PCIe, 1 x M.2, 1 x SATA 3.0
-
Audio:
-
Intel HD Graphics 610
-
Watch Dog:
-
Yes
-
Product Name:
-
1U Rack Mini PC
SupportQo
Product Description
|
Dimension |
440*112*44mm(L*H*W) |
|
Weight |
2.5kg (Reference) |
|
Power Consumption |
15W |
|
CPU(Support) |
k818GE-1U Rack:
8
th Gen intel Celeron 3867U Dual Core 2 Threads 1.8GHz 2M Cache
k828GE-1U Rack:
8
th Gen intel Celeron 4417U Dual Core 2 Threads 2.3GHz 2M Cache
k838GE-1U Rack:
8
th Gen intel Core i3 8130U Dual Core 4 Threads 2.0GHz-3.4GHz 4M Cache
k858GE-1U Rack:
8
th Gen intel Core i5 8250U Quad Core 8 Threads 1.6GHz-3.4GHz 6M Cache
k878GE-1U Rack:
8
th Gen intel Core i7 8550U Quad Core 8 Threads 1.8GHz-4.0GHz 8M Cache
|
|
Memory |
1 x DDR4 SO-DIMM Socket (Up to 32G, 2133/2400MHz) |
|
Chipset |
By CPU |
|
Hard Disk |
supports mSATA SSD
|
| Watch Dog | Yes |
|
Onboard LAN |
8* Intel I211AT - 10/100/1000 Controller |
|
Front-Panel Connectors |
• power Button • Reset Button
•
1 x Power LED, 1 x HDD LED
• 1 x HD Video Output • 1 x RS-232 Port (RJ-45 ) |
|
Expansion |
• 1 x Mini PCIe Full-length for 4G, Half-length for Wi-Fi Only Support USB Device • 1 x M.2 for Wi-Fi (E key, 2230) • 1 x SIM Card Slot • 1 x Automatically Boot Jumper • 1 x 2.0 Pitch Header for GPIO • 1 x DC-in Header (Optional) |
|
Back-Panel Connectors |
•8 x Intel I211-AT Gigabit LAN
|
|
Operating System |
Support Win7 /8 / Win10 /Linux etc(can't support win XP). |
Configuration for Selection
|
Memory |
2G, 4G , 8G DDR3 RAM |
|
Hard Disk |
8G/16G/24G/32G/64G/128G/256G/512G Msata SSD or 500G/1Tb 2.5" HDD(Optional) |
|
WIFI |
Optional |
Firewall Appliance & Personal Computer
With 8 x Intel 1GbE and , this appliance can be configured as a firewall, LAN or WAN router, DHCP Server, DNS Server, and so on.
With powerful Intel Core Processor, attaching a keyboard & monitor and reinstalling a Operating system and some softwares, it's your new personal computer, excellent POS terminal, mini server, etc.
Small, quiet, compact and cheap, running 24/7, Kansung Mini PC is a good solution for home, office, factory and so on.
OS
1) If the product is with RAM and SSD, It will come with inactive Windows 10 for test and we do not provide any Windows license. You also can install OS and software package by yourself. Press F11 key boot from USB Drive, press Delete key enter into BIOS.
2) We can provide Windows drivers download link and motherboard user manual download link.
User manual or windows drivers :
http://www.kansung.store/download/drivers/
Leave me a message and provide your email address. i will send it to you asap.
3) This appliance can be configured as a firewall, LAN or WAN router, DHCP Server, DNS Server, and IDS/IPS with optional packages to deliver a high performance, high throughput front-line security.
SIM & 3G/ 4G Module
There is a SIM slot on motherboard but the mini pcie slot supports Wi-Fi module by default.
We don't supply any 3G/ 4G modules.
BIOS
Mini PC supports Windows 7/ 8/ 10, Linux, ect. It will come with inactive Windows 7 for test and we do not provide any Windows license. You also can install OS and software package by yourself. F11 key boot from USB Drive. Delete key enter BIOS.
It can not support Windows XP.
Advantages: Wide application: Bought this little guy as a functional server connect with tons of computers at the same time.
You may also find it at house,bedroom, theatre ,and school and so on.
The pocket size may help you save space compared to others such as the tower one.
As it takes low power consumption,work in deep silence, you may find it very eco-friendly.
Package
What's in the Package box?
1* mini pc
1* the holder
2* antenna (if you order wifi)
1* package box
1*12V 3A/5A Power adapter and power plug.
There are 4 kinds of plug: European standard / British standard / Australian standard / American standard)
