Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Seasun Laser
-
Model Number:
-
laser stack
-
Function:
-
produce repair laser hair removal handle
-
Laser Power:
-
300W 500W 600W 800W 1200W 1600W 4800W optional
-
Laser type:
-
808nm diod bar
-
Wavelength:
-
755/1064/808nm±10nm
-
Frequency:
-
1~20 Hz
-
Working voltage:
-
6-48V according to laser power
-
Power supply:
-
600W - 4800W according to laser power
-
heat radiating system:
-
Water cooling
-
Bars quanity:
-
3-24 bars optional, 10 bars is normal
Quick Details
-
Feature:
-
Skin Tightening, Whitening, Hair Removal, Face Lift
-
After-sales Service Provided:
-
Free spare parts, Online support, Video technical support
-
Warranty:
-
1 Year
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Seasun Laser
-
Model Number:
-
laser stack
-
Function:
-
produce repair laser hair removal handle
-
Laser Power:
-
300W 500W 600W 800W 1200W 1600W 4800W optional
-
Laser type:
-
808nm diod bar
-
Wavelength:
-
755/1064/808nm±10nm
-
Frequency:
-
1~20 Hz
-
Working voltage:
-
6-48V according to laser power
-
Power supply:
-
600W - 4800W according to laser power
-
heat radiating system:
-
Water cooling
-
Bars quanity:
-
3-24 bars optional, 10 bars is normal
handpiece depiladora 100 watt laser diodo 808nm 808 diode bar de laser diodo hw 1442 3 waves gsd coherent
ONE-STOP LASER MACHINE AND PARTS SERVICES
Best Selling
Product Description
Diode Laser bar, the individual emitting areas (emitters) line side by side, separated by the non-emitting areas(heat sink). These sets of emitting/non-emitting regions form the so-called active layer or laser bar. The laser bar quantity, central wavelengths,outer structure sizes customizing is acceptable. That means ODM is acceptable. And tailor exclusively laser module is our core competency. Your company logo can be written on the laser bar. That means OEM is acceptable.
The relative value of the emitting areas in the active layer with respect to the bar width is the filling factor (FF). The Market FF is 10%-15%。In order to longer laser stack lifetime, Our FF is the best 10%.
Z is the propagation axis of the laser radiation. The propagation axis Y is the fast axis (FA) and the X axis is the slow axis (SA), referring to the rate of divergence. Compared with the traditional IPL technology,The diode laser technology has far much better lights beams focusingability. Our laser module FA is 36 degrees and SA is 4 degrees only. While IPL is 360 degrees and even after filtering, IPL FA is about 180 degrees.
You can use our diode laser bar to produce / reapir / upgrade your laser hair removal machine and handles.
Hair removal diode laser bar
|
Product Name
|
Diode Laser Stack Bar
|
|
Company logo
|
Your company logo can be written on the module
|
|
Function
|
Produce / repair laser hair removal machines and handles, replace your old laser modules
|
|
New sizes structure customize
|
support
|
|
Laser power
|
300W to 2400W optional
|
|
Electric connection map
|
support for free
|
|
Assembly guidance
|
support for free and 7*24 hours services
|
|
Tailor whole laser handpiece
|
support
|
|
Heat radiating
|
flowing cold water
|
|
Working voltage
|
6V to 48V according to your laser module
|
|
Packaging level
|
gold plate
|
Macro channel laser bar
Hair removal macro channel laser have obvious advantages now.
1. Unit bar power can be 200W now. and in the market, the most popular are 50W,60W,100W laser bars.
2. affordable costs. Compared with expensive micro channel bars, macro channel laser have better price advantages.
3. Lifetime. the macro channel laser have bigger water road, so it is not easy to be blocked and burnt the laser. so the macro channel laser have longer lifetime generally.
4. several macro channel laser stacks are as below.
Micro channel laser modules
Hair removal micro channel laser bars features
1. Unit bar power is usually 100W. It is the traditional strong power laser bars.
2. you can change some of the bars instead of change the whole laser stack.
3. Lower requirements on water temperature.
4. Several micro channel laser stacks are as below.
Diode laser stack applications
Our diode laser stacks can be used to produce or repair laser hair removal handpieces and assembly laser hair removal machine furtherly.
Several hair removal laser handles samples are as below
Produce new diode laser handles
Several new 808nm diode laser handles producing displaying. We can also customize design and produce hair removal diode handles for you.
Repair old hair removal laser handpieces
Several old hair removal diode laser handpieces repair showing...As a professional laser technology center, we repaired over 2000 pcs handles per year.
Using Effects
With our diode laser stack, then you can produce hair removal laser handle out, Then you can assembly portable or vertical diode laser hair removal machines. Here are some sample machines as below for your references. You can also buy some chassis from market to produce hair removal diode laser machines.
Related Products
$300 - $ 1000 Pieces
100 Pieces
(MOQ)
$500 - $ 1200 Pieces
100 Pieces
(MOQ)
$800 - $ 2000 Pieces
100 Pieces
(MOQ)
Certificate
-
Thailand CFS
-
Europe CE
ISO 13485
Packing & Delivery
All our diode laser spare parts are packed into strong cartons with customized vibration-resistant polyethylene foam. professional and Safety. Reinforcement belt to enhance the packing. And also professional aluminum flight case is optional. Just the aluminum box empty is about 10Kg..so the shipping costs will increasing a little.
Company Introduction
Seasun Laser started its hair removal 808nm diode laser complete spare parts supplying in 2009 as the China first one to provide diode laser technology services. Till now,We produce and supply diode laser stacks,hair removal laser handles, ready machines and complete spare parts of laser hair removal, fractional CO2 laser,vacuum roller RF weight loss body slimming,H I F U face and body, Picosecond laser, Tattoo removal, nutrient liquid injection,IPL etc. We can customize and produce beauty equipment for you and we can help you produce beauty equipment in your office also. We are aim to become your beauty equipment technology service center.
