Quick Details
-
Shade Shape:
-
rectangular
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OGJG
-
Model Number:
-
OG-SPC
-
Color Temperature(CCT):
-
3000K, 4000K, 5000K, 6000K, 6500K
-
Input Voltage(V):
-
AC100-277V, 347V
-
Lamp Luminous Efficiency(lm/w):
-
120
-
Lamp Luminous Flux(lm):
-
2100-9600
-
Working Temperature(℃):
-
-20 - 40
-
Color Rendering Index(Ra):
-
83
-
Lifespan (hours):
-
50000
-
Working Time (hours):
-
50000
-
PCs/ Ctn:
-
6
-
Packing Dimension:
-
2ft 4ft 5ft
-
Product Dimension:
-
2ft 4ft 5ft
-
Product Weight（kg）:
-
1
-
Product name:
-
Modern Ceiling Light
-
LED Light Source:
-
SMD2835
-
Power available:
-
20W, 40W, 50W, 60W, 80W
-
fixture lamp available:
-
2ft, 4ft, 5ft
-
Driver:
-
Isolated Led Driver
-
Dimmable:
-
0-10V/Dali
-
Function:
-
Microwave motion sensor, Emergency battery backup
-
Feature:
-
Aluminum Heatsink
-
Install Style:
-
surface or suspended mounted
-
IP Rating:
-
IP40
Quick Details
-
Lamp Body Material:
-
Cold rolled steel housing
-
Design Style:
-
Modern
-
Shade material:
-
PC
-
Shade Shape:
-
rectangular
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OGJG
-
Model Number:
-
OG-SPC
-
Color Temperature(CCT):
-
3000K, 4000K, 5000K, 6000K, 6500K
-
Input Voltage(V):
-
AC100-277V, 347V
-
Lamp Luminous Efficiency(lm/w):
-
120
-
Lamp Luminous Flux(lm):
-
2100-9600
-
Working Temperature(℃):
-
-20 - 40
-
Color Rendering Index(Ra):
-
83
-
Lifespan (hours):
-
50000
-
Working Time (hours):
-
50000
-
PCs/ Ctn:
-
6
-
Packing Dimension:
-
2ft 4ft 5ft
-
Product Dimension:
-
2ft 4ft 5ft
-
Product Weight（kg）:
-
1
-
Product name:
-
Modern Ceiling Light
-
LED Light Source:
-
SMD2835
-
Power available:
-
20W, 40W, 50W, 60W, 80W
-
fixture lamp available:
-
2ft, 4ft, 5ft
-
Driver:
-
Isolated Led Driver
-
Dimmable:
-
0-10V/Dali
-
Function:
-
Microwave motion sensor, Emergency battery backup
-
Feature:
-
Aluminum Heatsink
-
Install Style:
-
surface or suspended mounted
-
IP Rating:
-
IP40
ETL DLC ROHS SAA aisle steel housing 2ft 4ft 5ft batten lighting fixture Balcony 20w 40w 60w led motion sensor ceiling light
Product Description
| Model | OG-SPC(LED) |
| Material | Cold rolled steel housing, PC cover |
| Color | White, Black, Silver |
| Size | 2ft, 4ft, 5ft |
| Wattage | 20W, 40W, 50W, 60W, 80W |
| Luminous Efficiency | 105lm/w, 130lm/w |
| Input Voltage | 100-277V, 347V |
| CRI | >83 |
| Power Factor | >0.9 |
| LED Light Source | Epistar SMD2835 |
| CCT | 3000K, 3500K, 4000K, 5000K, 6000K, 6500K |
| Function | 0-10V dali dimming, Microwave motion sensor, Emergency battery backup, Linkable |
| Feature | Isolated driver, Aluminum heatsink, Replaceable LED strips, Match to junction box, Knockouts |
| Certificate | ETL, cETL, DLC premium, TUV-CE(EMC, LVD), TUV-SAA, CB |
| Installation | Ceiling mounted, Wall mounted, Suspended |
| Model | Wattage | Size | Dimensions(mm) | Voltage | Lumens | CCT(K) |
| OG-LED210-SPC | 20W | 2' | 610x112x62 | 100-277V | >2100lm/>2600lm |
3000K 4000K 5000K 6500K |
| OG-LED220-SPC-2 | 40W | 2' | 610x112x62 | 100-277V | >4800lm | |
| OG-LED220-SPC | 40W | 4' | 1220x112x62 | 100-277V | >4200lm/>5200lm | |
| OG-LED320-SPC | 60W | 4' | 1220x112x62 | 100-277V | >7200lm | |
| OG-LED240-SPC | 60W | 5' | 1506x112x62 | 100-277V | >6300lm/>7800lm | |
| OG-LED330-SPC | 80W | 5' | 1506x112x62 | 100-277V | >9600lm |
