LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V
LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V

LJ12A3-4-Z/BY PNP switch Inductive Proximity Sensor Switch DC 6V-36V

FOB Reference Price: Get Latest Price
≥10 Pieces
US $0.99
≥101 Pieces
US $0.93
≥1001 Pieces
US $0.91
≥3001 Pieces
US $0.89
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Place of Origin:
Guangdong, China
Brand Name:
OEM
Theory:
Proximity Switch Sensor
Voltage:
6-36VDC
Output current:
300mA
Detection Way:
Inductive
Weight:
44g
Shape:
cylindrical straight 12MM
Output:
DC three-wire PNP normally open type
Detection Distance:
4 mm
Can detect objects:
metal body
Part number:
LJ12A3-4-Z / BY
Housing Material:
Metal (Copper)

Quick Details

Mounting Type:
Standard
Description:
LJ12A3-4-Z/BY, LJ12A3-4-Z/BY
Model Number:
OKY3279-1
Place of Origin:
Guangdong, China
Brand Name:
OEM
Theory:
Proximity Switch Sensor
Voltage:
6-36VDC
Output current:
300mA
Detection Way:
Inductive
Weight:
44g
Shape:
cylindrical straight 12MM
Output:
DC three-wire PNP normally open type
Detection Distance:
4 mm
Can detect objects:
metal body
Part number:
LJ12A3-4-Z / BY
Housing Material:
Metal (Copper)
Why Choose Us
Description:
An Inductive Proximity/Distance Sensor That Can Detect Metallic Objects At Close Range. As Soon As A Metal Object Is Detected, The Signal Wire And Ground Are Connected With A Transistor. If No Object Is Detected, The Signal Wire Takes The Voltage Of The Power Supply Through The Built-In Pull-Up Resistor.

Specification:
1. Model: LJ12A3-4-Z / BY
2. Detection Way: Inductive
3. Shape: cylindrical straight 12MM
4. Output: DC three-wire PNP normally open type
5. Detection distance: 4mm
6. Power supply voltage: 6-36VDC
7. Output current: 300mA
8. Can detect objects: metal body
9. Housing Material: Metal (Copper)
10. Weight: 44g

Package Including:
1PC * Inductive Proximity Sensor

Packaging example
Customer Feedback
Exhibition
FAQ

1 . What is the delivery time?

Normally, 1-5 workdays after payment;

Special requirement order s, delivery time is negotia ble.

2. If the product s can’t work after receiving it,what should I do?

We will replace new items for you at once, and respect your final decision for wrong goods.

3. If the products don’t meet my demand after I received it,can I return it?

Yes,no problem.

You can return back to us, we will refund your full payment.

4.what is the warranty?

1-2 years warranty according to different products.

1-3 months to replace new items for free.

All products are tested strictly for 2-3 times before leaving factory. we have earned very good reputation in quality,Certified by the ISO9001.
