Power Specifications
|
|
|
|
Input Connection
|
3-Phase : 3P+N+PE( Single-Phase Optional: P+N+PE )
|
|
|
Input Voltage
|
400Vac ±10% （ 230Vac±10% Optional ）
|
|
|
Frequency
|
50Hz or 60Hz
|
|
|
Output Voltage
|
400Vac ±10% （ 230Vac±10% Optional ）
|
|
|
Rated Power
|
11kW - 22kW (3.7kW - 7.4kW Optional)
|
|
|
User Interface & Control
|
|
|
|
LCD Display
|
4.3" Color Touch Screen( Optional )
|
|
|
LED Indicator
|
Green/Blue/Red
|
|
|
Charging Interface
|
IEC 62196-2 Type 2 Plug (SAEJ1772 Type 1 Plug Optional)
|
|
|
Energy Measuring
|
MID Meter
|
|
|
Communication
|
|
|
|
Backend
|
Bluetooth / Wi-Fi / Ethernet (4G Optional )
|
|
|
Backend Protocol
|
OCPP 1.6 JSON ( OCPP2.0.1 )
|
|
|
Protection
|
|
|
|
Residual Current Device
|
RCD Type A 30mA+DC 6mA
|
|
|
Electrical Protection
|
Over/Under Voltage Protection,Over Current Protection, Short Circuit Protection, Over/Under Temperature Protection, Lightning
Protection, Ground Fault, Surge Protection |
|
|
Environmental
|
|
|
|
Operating Temperature
|
-30℃—+55℃
|
|
|
Storage Temperature
|
-40℃—+85℃
|
|
|
Operating Humidity
|
Max. 90% RH, Non-Condensing
|
|
|
Operating Altitude
|
≤ 2000m
|
|
|
IP, IK Level
|
IP55, IK08
|
|
|
Cooling Method
|
Natural Cooling
|
|
|
Mechanical
|
|
|
|
Product Dimension
|
300mm*154mm*420mm( W*D*H )
|
|
|
Package Dimension
|
380mm*320mm*590mm( W*D*H )
|
|
|
Weight
|
7.5kg( Net ) / 9kg( Gross )
|
|
|
Mounting
|
Wall-mount and Stand-mount
|
|
|
Certifications
|
|
|
|
Certifificate
|
IEC 61851-1, IEC 62196-1, IE62196-2,SAEJ1772-2017
|
|
|
Safety
|
CE, TUV
|
|
