Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CHINT
-
Model Number:
-
NXHB-125
-
Product name:
-
NXHB Switch Disconnector
-
Rated voltage Ue:
-
240
-
Rated current le:
-
20A,32A,40A,63A,80A,100A,125A
-
Number of poles:
-
1P, 2P, 3P, 4P;
-
Rated insulation voltage Ui:
-
500V
-
Rated operation voltage Ue:
-
240V~(1P), 415V~(2P, 3P, 4P);
-
Rated impulse withstand voltage Uimp:
-
6kV
-
Rated short time withstand current Icw:
-
12 Ie, power-on time of 1s
-
Rated short-circuit making capacity Icm:
-
20Ie, power-on time of 0.1s
-
Rated making and breaking capacity:
-
3Ie, 1.05Ue, COS 0.65
Quick Details
-
Number of Pole:
-
3
-
Rated Current:
-
20A,32A,40A,63A,80A,100A,125A
-
Rated Voltage:
-
240
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
CHINT
-
Model Number:
-
NXHB-125
-
Product name:
-
NXHB Switch Disconnector
-
Rated voltage Ue:
-
240
-
Rated current le:
-
20A,32A,40A,63A,80A,100A,125A
-
Number of poles:
-
1P, 2P, 3P, 4P;
-
Rated insulation voltage Ui:
-
500V
-
Rated operation voltage Ue:
-
240V~(1P), 415V~(2P, 3P, 4P);
-
Rated impulse withstand voltage Uimp:
-
6kV
-
Rated short time withstand current Icw:
-
12 Ie, power-on time of 1s
-
Rated short-circuit making capacity Icm:
-
20Ie, power-on time of 0.1s
-
Rated making and breaking capacity:
-
3Ie, 1.05Ue, COS 0.65
Product Description
CHINT NCH8-125 Isolation Switch 1P 2P 3P 4P Rated Current 20A to 125A Chint Switch Disconnector
