Features:
Usually made of low carbon steel material, carbon steel balls without heat-treatment are more cheaper and have bright surface but very low hardness. For balls with heat-treatment, they have good hardness and the best precision is G100.
Diameter:
2mm - 25.4mm
Grade：
G100 - G1000
Hardness：
HRC55 - 65
Applications:
1. General industry for automobile, motorcycle, bicycle manufacturing, special bearings & micro – ball for the electronics industry..
2. High accuracy & low noise motor bearing& household appliance bearings
3. High - speed, low noise special bearing
4. Ball valves for liquid and gas etc.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Saige
-
Model Number:
-
3mm 6mm 7mm 8mm 12mm 24mm stainless steel ball
-
Product name:
-
AISI 304 316 420 4403mm 6mm 7mm 8mm 12mm 24mm Stainless Bearing Ball
-
Size:
-
0.8mm-50.8mm
-
Surface:
-
High Polished
-
Application:
-
Manufacturing Plant
-
Package:
-
plastic bag+box+carton
-
Hardness:
-
HRC 58-62
-
Certifications:
-
ISO9001, IATF16949
-
Vdws:
-
0.25μm
-
Vdwl:
-
0.5μm
-
Merterial:
-
AISI201/304/316/420/440 Stainless Steel
Quick Details
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Bearings
-
Material:
-
Stainless steel
-
Place of Origin:
-
Jiangsu
-
Brand Name:
-
Saige
-
Model Number:
-
3mm 6mm 7mm 8mm 12mm 24mm stainless steel ball
-
Product name:
-
AISI 304 316 420 4403mm 6mm 7mm 8mm 12mm 24mm Stainless Bearing Ball
-
Size:
-
0.8mm-50.8mm
-
Surface:
-
High Polished
-
Application:
-
Manufacturing Plant
-
Package:
-
plastic bag+box+carton
-
Hardness:
-
HRC 58-62
-
Certifications:
-
ISO9001, IATF16949
-
Vdws:
-
0.25μm
-
Vdwl:
-
0.5μm
-
Merterial:
-
AISI201/304/316/420/440 Stainless Steel
Changzhou Feige Steel Ball Co., Ltd.
which is a professional manufacturer for chrome steel balls and stainless steel balls with more than 30 years experience.
At present, our main steel ball varieties are as follows:
Chrome Steel Ball:
G10-G1000 AISI52100/Gcr15, 100Cr6 Size:0.8mm-50.8mm
Stainless Steel Ball:
G100-G1000 AISI304 316/316L
Size:0.8mm-50.8mm
G10-G1000 AISI420 420C AISI440 AISI440C
Size:0.8mm-50.8mm
Carbon Steel Ball:
G100-G1000 AISI1010/1015 Size:2mm-25.4mm
G100-G1000 AISI1010/1015 Size:2mm-25.4mm
Product Description
Carbon Steel Ball
Material:
AISI1010/1015 carbon steel.
Chrome Steel Ball
Material:
AISI52100 chrome steel.
Features:
hardness, bear high pressure and friction when working,steel balls made of chrome steel offer superior wear
resistance,excellent surface, high hardness and high loadbearing capacity.
Diameter:
0.8mm - 50.8mm
Grade：
G10 - G1000
Hardness：
HRC60 - 66
Applications:
They are usually used in roller bearing industry and for a variety of automobile applications.
High-speed and low-noise bearings,
bicycles, motorcycles, automobiles, slide rails, universal balls, luggage, electronic industry, and can also be used to grind other media.
Stainless Steel Ball
AISI304、316/316L
Material:
AISI304、316/316L stainless steel.
Features:
Offer good corrosion resistance to sulphuric
acid compounds.
Diameter:
0.8mm - 50.8mm
Grade：
G10 - G1000
Hardness：
HRC≤26
Applications:
Valves, perfume bottles, medical equipment, nail polish, baby bottles, cosmetic packaging, air conditioners.
AISI420、420C、440、440C
Material:
AISI420、420C、440、440C stainless steel.
Diameter:
0.8mm - 50.8mm
Grade：
G10 - G1000
Hardness： HRC52-62
Applications:
All kinds of precision machinery, bearings, electrical equipment, transportation tools, household appliances, parts aviation, aerospace, bearings, motors, high-precision instruments, valves, petroleum.
Hardness： HRC52-62
Applications:
All kinds of precision machinery, bearings, electrical equipment, transportation tools, household appliances, parts aviation, aerospace, bearings, motors, high-precision instruments, valves, petroleum.
-------------------------------------------------------------------
How To Choose
-----------------------------------------------------------------------
1.G10、G16、G20、G40、G60、G100、G500、G1000,
The lower the number, the higher the
precision
.
2.
Confirm material standards（GB、AISI、DIN、SUS、NF、BS、UNI、F0CT）
3.
Comparison of other factors
|
Material
|
①Carbon steel ball
|
②Chrome steel ball
|
③Stainless steel ball
|
||
|
Price
|
③>②>①
|
|
|
||
|
Hardness
|
②>③Series 4>①>③Series 3
|
|
|
||
|
Highest precision（Grade）
|
②=③Series 4>①>③Series 3
|
|
|
||
|
Rustproof
|
③>②>①
|
|
|
||
Product details
Product process
-----------------------------------------------------------------
Inspection Equipment
----------------------------------------------------------------
Before packing, steel balls are sent for final audit to check for surface roughness, roundness, waviness, lot size variation and hardness in a sophisticated laboratory, according to specified control plans and dock audit procedures.
Once all requirements are met, a test certificate is then prepared for the customer. Our sophisticated laboratory is equipped with high precision, worldwide respected machines and equipment and is managed by properly trained and qualified personnel.
