Quick Details
-
Warranty:
-
25 years
-
Brand Name:
-
Wangheng
-
Place of Origin:
-
China
-
Panel Dimensions:
-
1420*1048*35mm
-
Product Name:
-
Monocrystalline Silicon Solar Panel
-
Solar cell:
-
Monocrystalline 166mm*83mm
-
Application:
-
Solar Power System
-
Keyword:
-
Monocrystalin Solar Panel
-
Material:
-
Monocrystaline Silicon
-
Frame:
-
Anodized Alluminium Alloy
-
Max. Power:
-
400W
-
Optimum Operate Voltage(VmP):
-
34.2V
-
Open circuit voltage(VOC):
-
41.04V
-
Optimum Operate current(ImP):
-
11.69A
Quick Details
-
Cell size:
-
166mm*110.66mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black
-
Panel Efficiency:
-
20.54%
-
Warranty:
-
25 years
-
Brand Name:
-
Wangheng
-
Place of Origin:
-
China
-
Panel Dimensions:
-
1420*1048*35mm
-
Product Name:
-
Monocrystalline Silicon Solar Panel
-
Solar cell:
-
Monocrystalline 166mm*83mm
-
Application:
-
Solar Power System
-
Keyword:
-
Monocrystalin Solar Panel
-
Material:
-
Monocrystaline Silicon
-
Frame:
-
Anodized Alluminium Alloy
-
Max. Power:
-
400W
-
Optimum Operate Voltage(VmP):
-
34.2V
-
Open circuit voltage(VOC):
-
41.04V
-
Optimum Operate current(ImP):
-
11.69A
Product Description
High efficiency 72 cells 300W 350W 380W 400W 500W solar panel 400 watt monocrystalline
Specification
|
Electrical Characteristics
|
|
|
|
Model No.
|
WHM-400
|
|
|
Maximum Power at STC (Pmax)
|
400W
|
|
|
Optimum Operating Voltage (Vmp)
|
36V
|
|
|
Open - Circuit Voltage (Voc)
|
43.2V
|
|
|
Optimum Operating Current (Imp)
|
8.33A
|
|
|
Short - Circuit Current (Isc)
|
9.16A
|
|
|
Maximum System Voltage
|
1000V
|
|
|
Operating Module Temperature
|
-40 °C / +85 °C
|
|
|
Diodes
|
3 by pass
|
|
|
Power Tolerance
|
-5/+5 %
|
|
|
TC: irradiance 1000 W/m2, module temperature 25 °C, AM=1.5; Power measurement
|
|
|
|
Mechanical Characteristics
|
|
|
|
Solar Cell
|
Monocrystalline 166× 83 mm
|
|
|
No. of Cells
|
72 (6 × 20)
|
|
|
Dimensions
|
1755*1038*35mm
|
|
|
Weight
|
20kg
|
|
|
Front Glass
|
3.2 mm (0.13 inches) tempered glass
|
|
|
Frame
|
Anodized aluminum alloy
|
|
|
Junction Box
|
IP65 rated
|
|
|
Output Cables
|
TUV
|
|
|
|
4.0 mm2 (0.16inches2), symmetrical lengths (-) 900 mm (35.4 inches) and (+) 900 mm (35.4inches)
|
|
|
Connectors
|
RADOX® SOLAR integrated twist locking connectors
|
|
|
Temperature Characteristics
|
|
|
|
Nominal Operating Cell Temperature (NOCT)
|
45±2 ℃
|
|
|
Temperature Coefficient of Pmax
|
-0.47%/℃
|
|
|
Temperature Coefficient of Voc
|
-0.34%/℃
|
|
|
Temperature Coefficient of Isc
|
0.045%/℃
|
|
|
Quality and Safety
|
|
|
|
Product warranty:
|
Single Solar modules will last for at least 25 years.
|
|
|
|
Free from defects in material and workmanship for 5 years.
|
|
|
|
All the panels passed IEC, TUV standards.
|
|
|
Power warranty:
|
Maintain more than 90% of minimum rated power for 10 years.
|
|
|
|
Maintain more than 80% of minimum rated power for 25 years.
|
|
|
|
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
