Quick Details
-
Application:
-
Telecommunication/CCTV/Computer
-
Product name:
-
UTP CAT5E Lan Cable
-
Core:
-
4 Pairs 8 Core
-
Wire Core Material:
-
Copper
-
Jcaket:
-
High quality pvc
-
ues:
-
Data network signal transmission lines up to 155 MHz
-
color:
-
Grey/White/Blue, Customized
-
Shield:
-
Unshielded Twisted Pair
-
Selling Units:
-
Single item
Quick Details
-
Brand Name:
-
YUHONG
-
Model Number:
-
UTP-CAT.5e
-
Place of Origin:
-
Hubei, China
-
Application:
-
Telecommunication/CCTV/Computer
-
Product name:
-
UTP CAT5E Lan Cable
-
Core:
-
4 Pairs 8 Core
-
Wire Core Material:
-
Copper
-
Jcaket:
-
High quality pvc
-
ues:
-
Data network signal transmission lines up to 155 MHz
-
color:
-
Grey/White/Blue, Customized
-
Shield:
-
Unshielded Twisted Pair
-
Selling Units:
-
Single item
Our Advantages
Product Parameters
|
norm
|
Conductor wire diameter（mm）
|
Insulation OD（mm）
|
Finished outer diameter（mm）
|
characteristic impedance（Ω）
|
Max value of conductor resistance at 20°C（Ω/KM）
|
Operating Capacitance（nF/100m(1KHz)）
|
|
UTP-CAT5e
|
0.50
|
0.9±0.1
|
5.3±0.2
|
100±15
|
95
|
5.6
|
|
UTP-CAT5e
|
0.48
|
0.9±0.1
|
5.3±0.2
|
100±15
|
95
|
5.6
|
|
UTP-CAT5e
|
0.45
|
0.9±0.1
|
5.3±0.2
|
100±15
|
95
|
5.6
|
|
Implementation standards
|
TIA/EIA-568-C.2 ISO/IEC 11801
|
|
use
|
Data network signal transmission lines with a bandwidth of 155 MHz or less
|
|
optoelectronics
|
The conductor is made of high-purity oxygen-free copper wire, and the insulation is imported high-density HDPE insulating material.
|
|
Usage characteristics
|
1、Operating temperature: -15℃ to 70℃. 2、Bending radius: 8 times the outer diameter of the cable 3、Fire retardant and fireproof grade: CM grade
|
|
jacket
|
High quality environmentally friendly PVC sheathing material
|
Product Detail
The product has good mechanical properties, excellent electrical insulation properties, good chemical stability, and water resistance. Strong, good character performance, safer to use.
