MiWi S-350-12 Good Price 350W 12V 29A Switching Power Supply

MiWi S-350-12 Good Price 350W 12V 29A Switching Power Supply

FOB Reference Price: Get Latest Price

≥1 Pieces

US $14

≥50 Pieces

US $13

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Zhejiang, China

Brand Name:: MiWi

Model Number:: S-350-12V

Output Frequency:: 47 ~ 63Hz

Output Current:: 29A

Product Name:: Switch Power Supply 12V

Rated Current:: 29A

DC Output Power:: 348W

Input Current:: 6.5A/115V 4A/230V

Current Range:: 0-29A

AC Inrush Current:: 25A/115V, 50A/230V

Efficiency (Typ.):: 74%

Iniet Stability:: ± 0.5%

Dimension:: 215*115*50 mm

Certifications:: CE

Quick Details

Output Power:: 301 - 400W

Input Voltage:: 90~132VAC/180~264VAC

Output Voltage:: 12V

Place of Origin:: Zhejiang, China

Brand Name:: MiWi

Model Number:: S-350-12V

Output Frequency:: 47 ~ 63Hz

Output Current:: 29A

Product Name:: Switch Power Supply 12V

Rated Current:: 29A

DC Output Power:: 348W

Input Current:: 6.5A/115V 4A/230V

Current Range:: 0-29A

AC Inrush Current:: 25A/115V, 50A/230V

Efficiency (Typ.):: 74%

Iniet Stability:: ± 0.5%

Dimension:: 215*115*50 mm

Certifications:: CE

You are here: Home >> Single Output Series >> S Series

Product Description

MiWi S-350-12V Good Price 350W 12V 29A Switching Power Supply

Input voltage selected by switch
Protection: short-circuit/ over-load/ over-voltage protection
Built-in cooling DC fan
100% full load burn-in test
Cooling fan ON-OFF auto control
1 year warranty

Model	S-350-5V	S-350-7.5V	S-350-12V	S-350-13.5V	S-350-15V	S-350-24V	S-350-27V	S-350-48V
DC Output Voltage	5V	7.5V	12V	13.5V	15V	24V	27V	48V
Iutput Voltage Error	± 2%	± 2%	± 1%	± 1%	± 1%	± 1%	± 1%	± 1%
Rated Output Current	50A	40A	29A	25.8A	23.2A	14.6A	13A	7.3A
Output Current Range	0-50A	0-40A	0-29A	0-25.8A	0-23.2A	0-14.6A	0-13A	0-7.3A
Tripple and Noise	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	200mVp-p	200mVp-p
Iniet Stability	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%
Tolerance Voltage	± 1%	± 1%	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%	± 0.5%
DC Output Power	250W	300W	348W	348.5W	348W	350.4W	351W	350.4W
Efficiency	73%	76%	74%	79%	78%	81%	82%	83%
Adjustable Range for DC Voltage	4.5-5.6V	6-9V	10-13.2V	12-15V	13.5-18V	20-26.4V	26-32V	40-56V
AC Input Voltage Range	90~132VAC/180~264VAC selected by switch 47~63Hz; 240~370VDC
Input Current	6.5A/115V 4A/230V
AC Inrush Current	Cold-Start Current: 25A/115V, 50A/230V
Leakage Current	<3.5mA/240VAC
Overload Protection	105%~150% Type: Cut Output, Reset: Auto Recovery
Over Voltage Protection	…………
High Temperature Protection	…………
Temperature Coefficient	± 0.03% /℃ (0~50℃)
Start, Rise, Hold time	200ms, 100ms, 20ms
Vibration	10~500Hz, 2G 10min,/1cycle, a total of 60 minutes, Each axes
Withstand Voltage	Between Input and Output: 1.5KVAC, Input and Shell: 1.5KVAC, Output and Shell: 0.5KVAC
Isolation Resistance	Input and Output Intermal: Input and Enclosute, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity	`-10℃~+60℃ (Refer to Output Derating Cutve), 20%~90%RH
Storage Temperature and Humidity	`20℃~+85℃, 10%~95%RH
Overall Dimension	21511550 mm
Weight	1.15 kgs
Safety Standards	CE
EMC Standards	Meet FCC Part 15J Conduction class B
Note	1. The testing condition for the parameter above is: 230VAC input, rated load, 25℃ 70%Rh, Humidity. 2. Error, include the setting error, line stability and load stability. 3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting. 4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage. 5. Load stability test: the load is from 0% to 100%, others 60%. 6. C3.4 must be knocked down,
