Quick Details
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
10000
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Dongfeng
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
6025*2200*2300
-
Engine:
-
YC6J180-33
-
Gearbox:
-
6-53H
-
cargo body size:
-
4500*2300*800
-
axles:
-
styre
-
Displacement:
-
4.214L
-
Fuel type:
-
diesel
-
Dimension (L*W*H):
-
6025*2200*2300
-
Tire:
-
8.25-20-14PR / 6+1
-
Transmission:
-
MT
Quick Details
-
Condition:
-
New
-
Horsepower:
-
150 - 250hp
-
Emission Standard:
-
Euro 2
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
10000
-
Drive Wheel:
-
4X2
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Dongfeng
-
Place of Origin:
-
China
-
Dimensions (L x W x H) (mm):
-
6025*2200*2300
-
Engine:
-
YC6J180-33
-
Gearbox:
-
6-53H
-
cargo body size:
-
4500*2300*800
-
axles:
-
styre
-
Displacement:
-
4.214L
-
Fuel type:
-
diesel
-
Dimension (L*W*H):
-
6025*2200*2300
-
Tire:
-
8.25-20-14PR / 6+1
-
Transmission:
-
MT
Product Description
Dongfeng tipper truck dump truck 4x2 10 ton dump truck M3 single cabin LHD/RHD for sale
| Model | RD3341RT |
| Driving Type | 4*2,LHD, M3 cab |
| Use scope | Construction project, building constructions site, material transporations |
| Chassis Dimensions(mm) | |
| Overall chassis length | 6095 |
| Cab width | 2225 |
| Cab height (unladen) | 2300 |
| Wheel base | 3400 |
| vehicle weights(kg) | |
| G.V.W | 3200 |
| Curb weight | 1480 |
| Payload weight | 5000-6000 |
| Frame profile Dimensions(mm) | |
| Section height | 231 |
| Section thickness | 6+4 |
| Engine | |
| Type model | YC4D130-33 |
| Emission level | EuroIII |
| Maximum power | 130hp |
| Maximum torque | 420N.m/1400-1800rpm |
| Number of cylinders | 4 |
| Displacement (lit) | 4.214 |
| Clutch | |
| Plate's diameter | 350 |
| Operating system | Fulling style |
| Gear box | |
| Type | 6-53H |
| Number of gears | 6 forward gears& 1 reverse |
| Axle | |
| Front Axle | 1*3200Kg |
| Rear Axle | 1*8000Kg |
| main reducing ratio | 5.833 |
| Suspension | |
| Front suspension | 11 Leaf spring with shock absorber |
| Rear suspension | 12+9 leaf spring with shock absorber and stabilizer bar |
| Fuel Tank | |
| Type | Steel fuel tank, with lockable cap |
| Capacity | 160L |
| Others | |
| Other options | Fixed cab mount, fixed driver seat, torsional rod lifting, laminated glass,air filter, domestic valve, no spare frame, manual air conditioning, remote control lock, electric window |
| Tyres / tyres qty. | 8.25-20-14PR / 6+1 |
| Cargo Body | |
| Dimensions(mm) | 4000*2200*800 |
| Oil Cylinder | chenglong 140 / Central lifting |
| Material | Material:Q345, Bottom 4mm,Side 3mm,Four carling +stabilizer frame |
