Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
8012M
-
body material:
-
PP
-
bolt material:
-
steel or stainless steel
-
o-ring material:
-
NBR
-
color:
-
black
-
size:
-
for 125mm to 315mm pe pipe
-
max working pressure:
-
PN10
Quick Details
-
Technics:
-
injection
-
Shape:
-
Reducing
-
Head Code:
-
round
-
Place of Origin:
-
China
-
Model Number:
-
8012M
-
body material:
-
PP
-
bolt material:
-
steel or stainless steel
-
o-ring material:
-
NBR
-
color:
-
black
-
size:
-
for 125mm to 315mm pe pipe
-
max working pressure:
-
PN10
Large size 160mm 200mm 250mm 315mm PN10 pipe pp saddle clamp with 6 bolts
| Product Name | Large size 160mm 200mm 250mm 315mm PN10 pipe pp saddle clamp with 6 bolts |
| Application | For water irrigation |
| OEM and ODM | Acceptable |
| Material | PP |
| Water pressure testing | 1.6 MPA(20-63mm), 1.0MPA(63-315mm) |
| Pipe size | 125-315mm |
| Thread size | 1/2"-6" |
| Medium: | water |
| Quality Guarantee | 2 Years Quality Guarantee |
Installation Method:
1).Clean the external surface of the pipe and make O-ring at the right position.
2).Lump the upper and down portion together on the pipe, insert the bolts,screw
in the nuts and tighten the bolts diagonally.
3).Drill a hole in the pipe wall by punch, do it carefully to avoid damaging the
O-ring and the pipe.
All size we have:
Packaging:
1. Normal packing
2. As per customer's request
Shipping:
Sea shipment
Air shipment
Courier shipment
Service Advantage:
1. 10 years manufacturing and exporting experience in agriculture field.
2. Professional technical support and solution by Chief Engineer.
3. Strict quality control system & team, high reputation in the market.
4. Quick, efficient and professional response within 24 hours, 14 hours online services.
5. Multilingual communication services (English, Spanish, French, Portuguese, Japanese etc.)
6. Full range of irrigation products for choice.
7. Accept sample order before Mass Order.
8. OEM/ODM services.
