* Top (Finish) Coating (PE/HDP/PVDF, etc.)
* Primer Coating
* Pre Treatment (Chromate Coating)
* Plating Layer (Zn, AL, 55%AL+Zn)
* Base Metal (Cold Rolled Steel Sheet)
* Plating Layer (Zn, AL, 55%AL+Zn, Sn, Cr, etc.)
* Pre Treatment (Chromate Coating)
* Functional Painting (Epoxy, Polyester )
Type Of Coating
The coating types currently used for PPGI/PPGL steel coil include PE, PVDF, SMP, acrylic, PVC, etc.
PE
The PE-coated color-coated steel sheet is easy to be processed and formed because of its good adhesion, and the price is relatively cheap. But the other degree of UV resistance and chalking resistance is relatively low. PE color coated steel can be used for the roof of ordinary civil buildings.
SMP
SMP steel plate has better durability, and the cost is higher than the PE coating. Silicone is not as good as PE in terms of adhesion and processing formability to materials,
High Durable Polyester (HDP)
It is better than ordinary SMP coatings, and its outdoor weather resistance reaches 16 years. Its flexibility and weather resistance are higher.
PVC
PVC coating has nice anti-chemical and anti-water, and the coasting is relatively thick, which can well protect the substrate. The PVC coating is rarely used because they pollute the environment.
PVDF
PVDF coatings have great color retention and corrosion resistance. Among the PPGI sheet coating for construction, it is the highest grade.
Acrylic
The comprehensive performance is good, the price is expensive, and it is only used in specific fields (such as containers).
- Product Details
- {{item.text}}
Quick Details
-
Hardness:
-
Hard
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
guolian
-
Length:
-
as inquired
-
Grade:
-
DX51D+Z
-
RAL Color:
-
as inquired
-
Keyword:
-
ppgi Corrugated Steel Roofing Sheet
-
Shape:
-
Corrugated Steel Plate
-
Product Name:
-
Prepainted Galvanized Steel
-
Surface:
-
Painted
-
MOQ:
-
25 Tons
-
Technology:
-
Hot Rolled.cold Rolled
-
Steel Grade:
-
SGCC/SGCD/SGCE/DX51D/DX52D/S250GD/S280GD/S350GD/G550/SPCC
-
Packing:
-
Standard Seaworthy Packing
-
Sample:
-
Sample Freely
Quick Details
-
Type:
-
Steel Coil
-
Thickness:
-
0.21-0.50mm
-
Coating:
-
Z121-Z180
-
Hardness:
-
Hard
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
guolian
-
Length:
-
as inquired
-
Grade:
-
DX51D+Z
-
RAL Color:
-
as inquired
-
Keyword:
-
ppgi Corrugated Steel Roofing Sheet
-
Shape:
-
Corrugated Steel Plate
-
Product Name:
-
Prepainted Galvanized Steel
-
Surface:
-
Painted
-
MOQ:
-
25 Tons
-
Technology:
-
Hot Rolled.cold Rolled
-
Steel Grade:
-
SGCC/SGCD/SGCE/DX51D/DX52D/S250GD/S280GD/S350GD/G550/SPCC
-
Packing:
-
Standard Seaworthy Packing
-
Sample:
-
Sample Freely
|
Product name
|
color coated steel coil ppgi
|
|
Thickness
|
0.12-2.0mm
|
|
Width
|
600-1500mm, usually 1250mm,1000mm,1240mm,1500mm,914mm,750mm and so on.
|
|
Grade
|
TDX51D+Z,TDX51D+AZ
|
|
Application
|
Inner decoration/School board/Making boxing
|
|
Paint Top (microns)
|
15-35 microns
|
|
Paint Back (microns)
|
5-10 microns
|
|
Coil ID
|
508/610 mm
|
|
Coating
|
AZ30-AZ160, Z50-Z140g/m2
|
|
Surface
|
Matt, high gloss, double coated, wood pattern, marble pattern, winkle
|
PPGI Sheet Coating Layer
