Quick Details
-
CaO Content (%):
-
a little
-
CrO Content (%):
-
0
-
SiC Content (%):
-
0
-
Place of Origin:
-
Henan, China
-
Model Number:
-
SK 32 34
-
Brand Name:
-
Lite
-
Raw material:
-
Bauxite
-
Size:
-
Straight,wedge,arch,split
-
HS code:
-
69022000
-
Bulk density(g/cm3):
-
2.0-2.2g/cm3
-
Fe2O3:
-
2%-4%
-
Color:
-
Yellow
-
Feature:
-
Volume Stability
-
Working temperature:
-
Less than 1350°C
-
Application:
-
Furnace,kiln,stove,pizza oven,fireplace
-
Sample:
-
Free
Quick Details
-
SiO2 Content (%):
-
50%-65%
-
Al2O3 Content (%):
-
30% 35% 38% 42%
-
MgO Content (%):
-
a little
-
CaO Content (%):
-
a little
-
CrO Content (%):
-
0
-
SiC Content (%):
-
0
-
Place of Origin:
-
Henan, China
-
Model Number:
-
SK 32 34
-
Brand Name:
-
Lite
-
Raw material:
-
Bauxite
-
Size:
-
Straight,wedge,arch,split
-
HS code:
-
69022000
-
Bulk density(g/cm3):
-
2.0-2.2g/cm3
-
Fe2O3:
-
2%-4%
-
Color:
-
Yellow
-
Feature:
-
Volume Stability
-
Working temperature:
-
Less than 1350°C
-
Application:
-
Furnace,kiln,stove,pizza oven,fireplace
-
Sample:
-
Free
| SK series | SK30 | SK32 | SK34 | SK35 |
| Al2O3 | 30%-35% | 35%-38% | 38%-42% | 42%-50% |
| Item |
33% Al2O3
fire clay brick
|
38% Al2O3
fire clay brick
|
42% Al2O3
fire clay brick
|
48% Al2O3
fire clay brick
|
| Al2O3 | 33% | 38% | 42% | 48% |
| Fe2O3/% | ≤3 | ≤3 | ≤3 | ≤2.5 |
| Refractoriness | ≥1690 °C | ≥1730 °C | ≥1750 °C | ≥1750 °C |
| Bulk density/g/cm3 | 1.9-2.0 | 2.0-2.1 | 2.1-2.18 | 2.15-2.3 |
| Unit weight (230*114*65mm) | ≥3.35KGS | ≥3.55KGS | 3.65KGS | ≥3.75KGS |
| Apparent porosity/% | ≤26 | ≤24 | ≤24 | ≤22 |
| Cold crushing strength | ≥20Mpa | ≥25Mpa | ≥30Mpa | ≥35Mpa |
| Refractoriness under load | ≥1250 °C | ≥1300 °C | ≥1350 °C | ≥1420 °C |
| Reheating Linear Change/% |
0~ -0.5
(1350°C,2h)
|
0~ -0.3
(1350°C,2h)
|
0~ -0.4
(1450°C,2h)
|
+0.1~ -0.4
(1450°C,2h)
|
1.
Iron & steel making:
Blast furnace,
hot blast stove
,hot metal ladle,tundish,soaking pit,heat treatment furnace,refining furnace,reheating furnace,metal mixter furnace,cupola furnace.
2.
Non-ferrous Metal:
Smelting furnace,reverberatory furnace.
3.
Building materials:
Cement kiln,glass kiln,ceramic kiln,lime kins,kiln car,tunnel kiln,rotary kiln.
4.
Energy &Incineration:
Coke oven,boiler,power generation boiler,
CFB boiler
,electric furnace,carbon roasting furnace,waste incinerators.
5. Others: Petrochemical industry furnace, pizza oven .
| Straight | Split | Arch | Wedge | Tile | Ohter Shape | |
| Have Stock |
230×114×65
230×114×75
230×57×65
|
230×114×32
230×114×40
|
230×114×65/45
230×114×65/55
|
|||
| NO stock |
230×114×25
230×114×50
|
230×114×75/45
230×114×75/55
230×114×75/65
|
230×230×38
230×230×50
230×230×65
230×230×75
|
Key brick,
Skew brick,
Soap,Checker,
Neck,
Taper,
|
||
1.Pallet+Paper or Steel angle bead+Paper board +Plastic or Steel belt +Plastic film
(1)Size 230×114×65: 448PCS/Pallet ,230×114×65/55: 480PCS/Pallet ,230×114×65/45: 512PCS/Pallet.
(2)Wooden pallet size:Usually 0.92*0.92m(standard brick) ,but 1*1m (special shape brick) at most.
(3)Load weight of each pallet:Usually 1.5-1.7Tons ,but 2.0 Tons at most .
(4)20 Foot Container can be loaded 25-26Tons at most,about 13-16Pallets .
2.Can make the packing according to customer's requirements.
Quality Assurance
Lite Refractory is committed to high quality standards for all its products and services. With its thirst on State of the art technology at every level and a wide range of products, Lite Refractory can provide ideal solutions for the stringent requirement of the customer. Backed by decade of experience in different industries, and close association with customers,Lite Refractory will always bring new products which will give better life and value to the user.
The quality assurance system consists of the following steps:
a.
Inspection and Control of incoming raw materials
:According to the chemical content,raw materials are classified into different levels to ensure quality of brick first.
b.
Inspection and control of the process
:During the production,every brick will be weighed twice strictly to reduce the error of weight .
c.
Inspection of product Standardization of quality of each product by process control and experimentation.
d.
Taking corrective measures whenever deviations are noted.
e.
Quality audit by quality management.
Before delivery, the inspectors will inspect the size,appearance,physical and chemical properties of brick again in factory.
Henan Lite Refractory Material Co., Ltd is located in Zhengzhou Henan province ,which is one of the main refractory production bases in China.
Our manager has been engaged in
refractory material industry
for
more than 15 years
.In the technological team there are
more than 10 senior designers and engineers,more than 20 technicians.
Products manufacture and supply:
(1)Refractory bricks:
High alumina brick,Corundum brick,Mullite brick,Silicabrick,Sillimanite brick etc.
(2)Insulation bricks:
Clay insulating brick,High alumina insulating brick,Mullite insulation brick etc.
(3)Unshaped refractory:
Castable,Calcium aluminate cement,Ramming mass,Gunning mix,Mouldable refractory,Mortar,bauxite,refractory bed material etc.
(4)Ceramic Fiber Product: fiber board,fibre blanket,fiber module,fiber cloth,fiber tape,fiber paper etc.
(5)Refractory balls: High alumina ball,Alumina ceramic ball,Ceramic regenerative ball etc.
Why Choose Us?
(1)Product:
1.Based on
rich refractory raw materials
and
experienced refractory manufacture factories
,can provide
complete refractory in Specification and Category
with
good quality and competitive price
.
2.Larger production capacity
(3000tons per month)
ensure the fast production cycle after confirmed the order.
3.
ISO9001 Certificate,100% QC inspection
Before Shippment,and
1 year Quality Assurance
.
4.
Professional
packing avoid damage;
Competitive Price
make the products competitive in customers' market.
(2)Service
1.Alibaba Assessed
5 years Gold Supplier
,but we have exported from
2010
through other trading companies and our manager is engaged in refractory materials
more than 15 years
,can supervise
raw material,production,quality control,package,delivery professionally
to ensure the products' quality.
2.Sales person:
(1)
Quick
and
Professionally
reply:Engaged in international trade
more than 4 years
with
rich experience
,can provide customers
a series of advices and solutions
including
products,package,transport
etc to make customer
worry-saving and save time
.
(2)Provide customer more than
8 hours'consultation service
.
3.
Free samples
.Produce the products according to
clients' requirements
. To meet the refractory solutions, also can
arrange technicians to customers' plant
if needed.
FAQ
Q1.What is the difference between Refractoriness and Working temperature ?
A1:Refractoriness:the refractory material withstands high temperature without melting and softening performance in the absence of load resistance.Usually working temperature is less than refractoriness about 350-400°C.
Q2.How are the products' quality?
A2:The products will be strictly inspected before shipment, so the quality could be guaranteed.
Q3:What is the Warranty for the fire brick?
A3:For all the brick,we have 1 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.
Q4.What is the service life of the bricks?
A4:The service life of different bricks is unlike.It also depends on your using condition and method.
Q5:Are you a manufacture or trader?
A5:To be honest we are a trader,but we have stable cooperation factories.And we can supply good pre-sale service, after-sales service.
Q6.Can we visit your company?
A6:Sure,welcome at any time,seeing is believing.
Q7. Do you provide samples?
A7:Yes, samples are available.
Q8. Do you accept OEM?
A8:Yes, we can do OEM.
Q9.What's the MOQ of trial order?
A9:No limit,We can offer the best suggestions and solutions according to your condition.
Q10.What are the payment terms?
A10:Usually T/T,but L/C,Western Union etc are available for us.
Q11. How long is delivery time?
A11:The delivery time will be determined according to the quantity of the order.
Q12.How about your company's certification?
A12:ISO9001 and Test Report,also we could apply other necessary certification.
Q13:Can we get support if we have our own market position?
A13:Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
