Quick Details
-
Power:
-
48V/4Kw
-
Min. Lifting Height:
-
6m
-
Table Size:
-
1670*760
-
Overall Dimensions:
-
1915*1210*2140
-
Weight:
-
2400 kg
-
Marketing Type:
-
New Product 2023
-
Keywords:
-
Scissor Lift
-
Product name:
-
scissor lift electric
-
Name:
-
crawler scissor lift
-
wheelbase:
-
1.89m
-
weight:
-
2400kg
-
Overall size:
-
1915*1210*2140
-
Safe working load:
-
230kg
-
color:
-
customized
-
Usage:
-
Lift Workers
-
Certificate:
-
CE ISO
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LTMG
-
Power:
-
48V/4Kw
-
Min. Lifting Height:
-
6m
-
Table Size:
-
1670*760
-
Overall Dimensions:
-
1915*1210*2140
-
Weight:
-
2400 kg
-
Marketing Type:
-
New Product 2023
-
Keywords:
-
Scissor Lift
-
Product name:
-
scissor lift electric
-
Name:
-
crawler scissor lift
-
wheelbase:
-
1.89m
-
weight:
-
2400kg
-
Overall size:
-
1915*1210*2140
-
Safe working load:
-
230kg
-
color:
-
customized
-
Usage:
-
Lift Workers
-
Certificate:
-
CE ISO
Product Description
Parameter
|
Model
|
LTWP0608LD
|
LTWP0810LD
|
LTWP1012LD
|
LTWP1214LD
|
|
Safe working load
|
450Kg
|
450Kg
|
320Kg
|
320kg
|
|
Max number of workers
|
2
|
2
|
2
|
2
|
|
Max working height
|
8m
|
10m
|
12m
|
14m
|
|
max platform height
|
6m
|
8m
|
10m
|
12m
|
|
overall length
|
2470mm
|
2470mm
|
2470mm
|
2731mm
|
|
overall width
|
2280mm
|
2280mm
|
2280mm
|
1661mm
|
|
Overall height (guardrail not folded)
|
1390mm
|
1390mm
|
1390mm
|
1390mm
|
|
Overall height (guardrail folded)
|
2280mm
|
2400mm
|
2530mm
|
2694
|
|
Working platform size
|
1745mm
|
1865mm
|
1995mm
|
2271
|
|
Platform extension size
|
2270X1120mm
|
2270X1120mm
|
2270X1120mm
|
2270X1120mm
|
|
Min turning radius
|
900mm
|
900mm
|
900mm
|
900mm
|
|
Min ground clearance
|
0m
|
0m
|
0m
|
0m
|
|
Lifting motor
|
48V/4Kw
|
48V/4Kw
|
48V/4Kw
|
48V/4Kw
|
|
Moving motor
|
2X48v/4Kw
|
2X48v/4Kw
|
2X48v/4Kw
|
2X48v/4Kw
|
|
Machine running speed
|
2.4Km/h
|
2.4Km/h
|
2.4Km/h
|
2.4Km/h
|
|
Rising / falling speed
|
38/30sec
|
45/36sec
|
70/62sec
|
70/62sec
|
|
Battery
|
8x6v/200Ah
|
8x6v200Ah
|
8x6v200Ah
|
8x6v200Ah
|
|
battery charger
|
48V/25A
|
48V/25A
|
48V/25A
|
48V/25A
|
|
Climb Capability
|
0.3
|
0.3
|
0.3
|
0.3
|
|
Max allowable working angle
|
1.5°/2.5°
|
1.5°/2.5°
|
1.5°/2.5°
|
1.5°/2.5°
|
|
weight
|
2400Kg
|
2550Kg
|
2840Kg
|
3480kg
|
Product Details
Strong Scissor Structure
High stability scissor structureMuch stronger material.
Door On Platform
Door, easy to open and close, strong and safewhen closing Non-slip cardamom board on the platform.
Product Shows
OEM/ODM
Factory Introduction
Certificate
Hot Product
FAQ
1. Why choose us?
As a manufacturer, LTMG industrial is committed to offer not only high quality product and performance and competitive price, but also in-time delivery and comprehensive 7/24 after-sale services.
2. What is the product range of our factory?
LTMG industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying loaders, forklift
trucks, excavator, diesel scissor lifts and related attachments. We can also customize non-standard products according to customer's requirements.
trucks, excavator, diesel scissor lifts and related attachments. We can also customize non-standard products according to customer's requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be
settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if
needed.
5. How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
LTMG industrial can provide customized products according to customers' requirements,both OEM and ODM are acceptable.
