Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
67000kg
-
Drive Wheel:
-
/
-
After-sales Service Provided:
-
Video technical support, Online support
-
Brand Name:
-
xcm-g
-
Place of Origin:
-
Jiangsu, China
-
Engine Brand:
-
/
-
Cylinders:
-
/
-
Gear Box Brand:
-
/
-
Forward Shift Number:
-
/
-
Dimensions (L x W x H) (mm):
-
/
-
Cargo Tank Dimension:
-
/
-
Tire Number:
-
/
Quick Details
-
Condition:
-
New
-
Horsepower:
-
/
-
Emission Standard:
-
/
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
4 - 6L
-
Gross Vehicle Weight:
-
67000kg
-
Drive Wheel:
-
/
-
After-sales Service Provided:
-
Video technical support, Online support
-
Brand Name:
-
xcm-g
-
Place of Origin:
-
Jiangsu, China
-
Engine Brand:
-
/
-
Cylinders:
-
/
-
Gear Box Brand:
-
/
-
Forward Shift Number:
-
/
-
Dimensions (L x W x H) (mm):
-
/
-
Cargo Tank Dimension:
-
/
-
Tire Number:
-
/
* According to each of the engine torque characteristic curve, perfectly match the different types of Fast manual gearbox, Allision automatic gearbox, to protect the most energy rationalization output, the vehicle has an excellent starting ability, climbing ability.
* Optimized arrangement of the traditional system architecture, reducing the loss of energy transfer process to ensure the kinetic energy efficient, rapid transmission.
* Using the unique steering and steering follower, the steering mechanism. Steering light, the failure rate lower.
* Dual-circuit brake system equipped with high pressure geography accumulator volume increases, the brake pressure increasing 25% to 1 Mpa, shorten braking distance.
| Dimensions(mm) | |
| Overall size (length×width×height) | 8860*3275*3740 |
| Cargo body size (length×width×height) | 5800×2400×1650 |
| Wheelbase | 4000+1400 |
| Cargo thickness | Bottom 16mm ,sideboard 12mm |
| Weight(kg) | |
| Kerb mass | 17000 |
| Rated loading capacity | 30000 |
| Gross vehicle weight | 47000 |
| Performance | |
| Max. travel speed | 65km/h |
| Min. turning Radius | m |
| Max. gradeability | 33% |
| Engine | |
| Model | WD10.340E32 |
| Rated output power | 340HP |
| Displacement | 9762ml |
| Front axle | 9.5T |
| Rear axle | 16T |
| Breaks | |
| Service brake: | dual circuit compressed air brake |
| Parking brake | spring energy operating on rear wheels |
| Tyers | 12.00R20 |
| Electric System | |
| Operating voltage | 24V |
| Alternator | 70A/28V |
| Batteries | 6-QAW-180DMF |
| Fuel tank | |
| Capacity | 300 L |
RISEN ConstructionMachinery (Shanghai) Co., Ltd is engaged in developing, manufacturing andexporting construction machines in the areas of building, mining, energy andlogistic engineering. Offering 8 major categories, 38 product line and morethan 1000 models, RISEN is able to provide complete equipment package to theclients from all walks of life.We are a wholesaler of many brands in China, a professional exporter of construction machinery and a one-stop solution provider. Our team has over 15 years of experience in this field.
From the factory to our customer's destination, we will conduct all-round supervision .We can also helpto sign purchase ordercontracts , test product quality , guarantee timely delivery , and accomodate special orders .
What is the proportion of your products exported?
75% of our products are exported to all over the world.
What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.
What kind of logistic service do you supply?
A. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport : Container, LCL, FRC, ro-ro, bulk cargo, train carriage, truck, air plane.
B. Term: FOB,CIF, DAP, to door service, etc.
