- Product Details
- {{item.text}}
Quick Details
-
Model:
-
CT400
-
Voltage:
-
220V
-
Size:
-
970*580*965MM
-
Motor power:
-
750W
-
Net Weight:
-
180KG
-
After-sales Service Provided:
-
Online support
-
Service Provided:
-
Free spare parts
-
After Warranty Service:
-
Video technical support
-
Warranty Service:
-
Spare parts
-
Local Service Location:
-
None
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
CTMACH
-
Weight (KG):
-
180
-
Model:
-
CT400
-
Voltage:
-
220V
-
Size:
-
970*580*965MM
-
Motor power:
-
750W
-
Net Weight:
-
180KG
-
After-sales Service Provided:
-
Online support
-
Service Provided:
-
Free spare parts
-
After Warranty Service:
-
Video technical support
-
Warranty Service:
-
Spare parts
-
Local Service Location:
-
None
| lathe | |
| Maximum workpiece turning diameter of the bed | 420mm |
| Two of the top distance | 400mm |
| Spindle hole diameter | 20mm |
| Spindle taper | MT3 |
| Maximum longitudinal stroke | 380mm |
| Maximum lateral stroke | 120mm |
| Processing metric thread pitch range/species | 0.2-3mm/18 |
| Processing inch thread pitch range/species | 8-120TPI/32 |
| Automatic tool feed | 0.05-0.175mm/r/8 |
| Tailstock sleeve taper | MT3 |
| Spindle speed range/level | 160-1360rpm/7 |
| Drilling and milling | |
| Maximum drilling diameter | 15mm |
| Diameter of end mill | 20mm |
| Maximum face milling cutter diameter | 63mm |
| Drilling and milling spindle taper | MT3 |
| Spindle speed range/level | 117-1300rpm/14 |
| Vertical lifting stroke of drilling and milling case | 80mm |
| Working surface width | 150mm |
| Length of working surface | 200mm |
| Maximum stroke of drilling and milling axis | 85mm |
| Motor Power | 0.75kw/220v |
| N.W./G.W. | 180/220kg |
| Machine size | 970×580×965mm |
| Packing size | 1032×580×1100mm |
