Quick Details
-
Brand Name:
-
Partaker
-
Model Number:
-
B1
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Fanless Mini PC
-
Ports:
-
VGA, HD-MI, LAN, 4USB3.0+2USB2.0, SPK, MIC
-
WIFI:
-
300M Built-in Wifi Optional
-
Size:
-
19.7X19.7X3.6CM
-
Processor Graphics:
-
Intel Iris Graphics 550
-
USB port:
-
4* USB 3.0+2 * USB 2.0
-
Memory Capacity:
-
Optional
-
Hard Drive Capacity:
-
Optional
-
Case:
-
9mm Ultra Thin Brushed Aluminum Alloy
Quick Details
-
Display resolution:
-
Other
-
Screen Size:
-
No Monitor
-
Processor Main Frequency:
-
2.40 GHz
-
Brand Name:
-
Partaker
-
Model Number:
-
B1
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Fanless Mini PC
-
Ports:
-
VGA, HD-MI, LAN, 4USB3.0+2USB2.0, SPK, MIC
-
WIFI:
-
300M Built-in Wifi Optional
-
Size:
-
19.7X19.7X3.6CM
-
Processor Graphics:
-
Intel Iris Graphics 550
-
USB port:
-
4* USB 3.0+2 * USB 2.0
-
Memory Capacity:
-
Optional
-
Hard Drive Capacity:
-
Optional
-
Case:
-
9mm Ultra Thin Brushed Aluminum Alloy
Product Description
Processor has 5 options suitable for the same motherboard:
1. CPU Intel Core i5 5200U/5250U 2 cores 4 threads 2.2GHz 3MB cache TDP 7.5W Intel HD Graphics 5500.
2. CPU Intel Core i7 4500U 2 cores 4 threads 1.8GHz 4MB cache TDP 15W Intel HD Graphics 4400.
3. CPU Intel Core i5 4200U 2 cores 4 threads 1.6GHz 3MB cache TDP 15W Intel HD Graphics 4400.
4. CPU Intel Core i3 4005U/i3 4010U 2 cores 4 threads 1.7GHz 3MB cache TDP 15W Intel HD Graphics 4400. (i3 4005U/4010U/4030U/5005U will ship randomly per stock)
5. CPU Intel Core i3 6157U 2 cores 4 threads 2.4Ghz 3M Cache, TDP 28W Intel Iris Graphic 550.
This link for CPU i3 6157U only, if need other CPU , please click here.
Size: 197mmx197mmx37mm
Features:
1)- Beautiful: Industrial aesthetic design and Reasonable interface layout;
2)- Noiseless: Fanless system, low consumption, 0.00dB noise;
3)- Special: Support 64 bits computing Turbo boost Hyper-Threading Virtualization technology etc, Can install 1pc 2.5'' SSD or HDD and 1pcs MSSD(5CMx3CM) together(welcome to contact our Pre-Sales if you need it) up to 512GB SSD or 1TB HDD large volume;
4)- Slim: Only 37mm body thickness, can stand on desk by free bracket we supply;
5)- Smooth: High-end Intel Graphics HD, fight again dedicated Graphics! Support all online games, big 3D games, large-scale mapping software, blu-ray and 4K Ultra HD streams, full 1920*1080 HD resolution, 2*HDMI dual monitor display;
6)- Strong: Work with any brand monitors; 1*RJ45 Gigabit Lan Nic+1*VGA+1*HDMI+4*USB3.0+2*USB2.0 Suit for multiple application for example integrate with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projects;
7)-Low-carbon green: TDP only 15W, very economical, saving a lot energy every year, low consumption but with a very amazing performance.
8)-Certification: CE, FCC & RoHS.
What can this mini computer do?
- Office work: Office, Skype, yahoo, outlook and all other office requirement support and runs perfect;
- Design work: Photoshop, CorelDraw, Dreamweaver, iIIustrator, Flash, InDesign and all others
- Game playing: support most online games and PC games, like War craft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games.
- Entertainment: support ultra HD 4K resolution, support XBMC and others program that support Windows and Linuxs
- Used as server, used as an industrial machine, hospital, factory, etc
Main advantages
- Small size : all Adeli fanless mini pcs smaller than A4 paper, some of the small size pc only 3.5-inch size, just like the HDD sized using it traditional fat computers. Most of that small size fanless mini pc can be mounted to the backside of monitor, and takes almost no space of your desk, make your desk more clear and smart.
- Durability : all those fanless mini pcs are highly integrated, fanless design makes it runs silent and no need extra maintenance like normal fat computers. And most of them using aluminum alloy computer case, very durable.
- Low power: all the Adeli fanless mini pcs using 12V power supply, most of them power consumption from 15W to 30W, compare to 150W traditional pc's consumption, it helps saving more than 80% energy.
- Universal performance: Adeli fanless mini pcs compatible with almost all popular operating systems, such as Win10, Linux. You can use this mini computer as personal computer at home, or use it as HTPC to built your own home theater center, and also you can use it in offices, training centers, factories, internet cafe and everywhere that require computers.
- Silent operation: fanless mini pc also name as silent computer, quiet mini pc or silent desktop pc. As there is no fan inside, the pc runs totally silent all day long, make sure you can keep wholehearted in to your work.
7)-Low-carbon green: TDP only 15W, very economical, saving a lot energy every year, low consumption but with a very amazing performance.
8)-Certification: CE, FCC & RoHS.
What can this mini computer do?
- Office work: Office, Skype, yahoo, outlook and all other office requirement support and runs perfect;
- Design work: Photoshop, CorelDraw, Dreamweaver, iIIustrator, Flash, InDesign and all others
- Game playing: support most online games and PC games, like War craft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high grade 3D games.
- Entertainment: support ultra HD 4K resolution, support XBMC and others program that support Windows and Linuxs
- Used as server, used as an industrial machine, hospital, factory, etc
Main advantages
- Small size : all Adeli fanless mini pcs smaller than A4 paper, some of the small size pc only 3.5-inch size, just like the HDD sized using it traditional fat computers. Most of that small size fanless mini pc can be mounted to the backside of monitor, and takes almost no space of your desk, make your desk more clear and smart.
- Durability : all those fanless mini pcs are highly integrated, fanless design makes it runs silent and no need extra maintenance like normal fat computers. And most of them using aluminum alloy computer case, very durable.
- Low power: all the Adeli fanless mini pcs using 12V power supply, most of them power consumption from 15W to 30W, compare to 150W traditional pc's consumption, it helps saving more than 80% energy.
- Universal performance: Adeli fanless mini pcs compatible with almost all popular operating systems, such as Win10, Linux. You can use this mini computer as personal computer at home, or use it as HTPC to built your own home theater center, and also you can use it in offices, training centers, factories, internet cafe and everywhere that require computers.
- Silent operation: fanless mini pc also name as silent computer, quiet mini pc or silent desktop pc. As there is no fan inside, the pc runs totally silent all day long, make sure you can keep wholehearted in to your work.
Item Specifications
|
Key Features
|
CPU
|
Intel Core i5 6200U , 2.3GHz Max 2.8 Ghz 3M Cache
Intel Core i3 6157U , 2.4GHz 3M Cache Intel core i5 4200U , 1.6GHz Max 2.6GHz Intel core i5 5200U , 2.2GHz Max 2.7GHz Intel Core i3 5005U, 2.0Ghz 3M Cache Intel Core i7 5500U, 2.4Ghz Max 3.0Ghz |
|
|
RAM
|
Support 2G/4G/8G/16G(2*8G) DDR3L-1333/1600MHz and LPDDR3-1333/1600MHz SODIMM Notebook memory
|
|
|
Storage
|
Support mSATA SSD and 2.5 inch laptop HDD/SSD; can install maximum 1 HDD (2.5 inch) +1 SSD (mSATA 3.0) together
|
|
|
Graphics
|
Core i5 6200U i3 6100U Intel HD Graphics 520, support ultra HD 4K resolution
Core i5 5200U Intel HD Graphics 5500 , support ultra HD 4K resolution Core i5 4200U Intel HD Graphics 4400 , support ultra HD 4K resolution |
|
|
I/O
|
Mic;Speaker; 4*USB 3.0 port; 2*USB 2.0 port;1*RJ45 Gigabit LAN Port;1*VGA;1*HDMI;1* DC12V In;
|
|
|
Operating System
|
Windows 7/8/10, Linux Compatible, suggest OpenELEC for less than 16GB SSD, Win7 or Win8 for up to 32GB storage
|
|
|
Language
|
Multi Language
|
|
|
Feature
|
Fanless
|
|
|
USB port
|
4* USB 3.0+1* USB 2.0
|
|
|
Wireless
|
300MB Wifi with 2 Antennas
|
|
|
HD Output
|
1*HDMI port, support 4k output; 1*VGA port, support HDMI+VGA dual display
|
|
|
LAN port
|
1* Gigabit RJ45 port speed up to 1Gbps
|
|
Power and Working Environment
|
Input
|
DC100-240V AC/50-60Hz
|
|
|
Output
|
DC 12V~3A/5A
|
|
|
Operating Temperature
|
0/70 Centigrade (32F~140F)
|
|
|
Storage Temperature
|
-20/+85 Centigrade
|
|
|
Relative Humidity
|
0%~90% (non-condensing)
|
|
|
Energy-saving
|
Support Energy-saving technology, Speedstep
|
|
|
64 bit computing
|
Support 64 bit computing
|
|
|
Virtualization
|
Support Virtualization technology
|
|
|
Hyper-threading
|
Support Hyper-Threading
|
|
|
Consumption
|
15W~28W
|
|
Physical Properties
|
Material
|
Brushed Aluminum Alloy
|
|
|
Weight
|
NW:1.25Kg GW:2.2Kg
|
|
|
Package Content
|
1* Mini PC; 1* power adapter; 2* Antennas
|
|
|
Warranty
|
30 days free defective replacement and 3 years free repair
|
