Quick Details
-
Jaw crusher usage:
-
Coarse crushing process
-
Delivery time:
-
12-15 days after paying deposit
-
Jaw Crusher Colour:
-
Yellow, red or As Request
-
Installation:
-
Engineer guide
-
Max. Feeding Size:
-
100-120 mm
-
Output size range:
-
10-40 mm
-
The Machines classification:
-
PE 150 x 250 Mini Jaw Crusher Price Zambia
Quick Details
-
Place of Origin:
-
Henan, China
-
Product name:
-
Small Lab 3 tph Stone Jaw Crusher
-
After-sale service:
-
Lifetime warranty
-
Jaw crusher usage:
-
Coarse crushing process
-
Delivery time:
-
12-15 days after paying deposit
-
Jaw Crusher Colour:
-
Yellow, red or As Request
-
Installation:
-
Engineer guide
-
Max. Feeding Size:
-
100-120 mm
-
Output size range:
-
10-40 mm
-
The Machines classification:
-
PE 150 x 250 Mini Jaw Crusher Price Zambia
"Great Wall Make Great Machine"
Small Lab 3 tph Stone Jaw Crusher PE 150 x 250 Mini Jaw Crusher Price Zambia
| Usage and Application Small Lab 3 tph Stone Jaw Crusher PE 150 x 250 Mini Jaw Crusher Price Zambia |
The Jaw Crusher is widely used in mining, building materials, chemical industry, metallurgy and so on. It is suitable for primary and secondary crushing of all kinds of minerals and rocks with compressive strength less than 320 MPa.
| Working Prnciple Small Lab 3 tph Stone Jaw Crusher PE 150 x 250 Mini Jaw Crusher Price Zambia |
The belt and belt pulley are driven by a motor, and the movable jaw moves up and down via eccentric shaft. The angle between fixed jaw and movable jaw becomes smaller when the moving jaw runs down, then the materials are crushed into pieces. It becomes bigger when the movable jaw runs up. The movable jaw plate leaves the fixed jaw plate under the action of tension rod and spring, then the end products come out from the crushing cavity.
| Features Small Lab 3 tph Stone Jaw Crusher PE 150 x 250 Mini Jaw Crusher Price Zambia |
1. Simple structure, convenient maintenance;
2. High crushing ratio, even output granularity;
3. High reliability, low investment;
4. Low noise, less dust.
| Model |
Feed
Opening Size (inch) |
Feed
Opening Size (mm) |
Max. Feeding Size
(mm) |
Adjustable Range of Discharge Opening
(mm) |
Capacity
(t/h) |
Motor
Power (kW) |
Weight
(t) |
Overall
Dimension (mm) |
| PE250×400 | 10x16 | 250×400 | 200 | 20-50 | 5-20 | 15 | 2.9 | 1430×1310×1340 |
| PE400×600 | 16x24 | 400×600 | 350 | 40-100 | 15-60 | 30-37 | 6.8 | 1700×1732×1653 |
| PE500×750 | 20x30 | 500×750 | 425 | 50-100 | 40-100 | 45-55 | 11.2 | 2035×1921×2000 |
| PE600×900 | 24x36 | 600×900 | 500 | 65-160 | 60-140 | 55-75 | 16.5 | 2290×2206×2370 |
| PE750×1060 | 30x42 | 750×1060 | 630 | 80-150 | 90-230 | 90-110 | 29 | 2655×2302×3110 |
| PE900×1200 | 36x48 | 900×1200 | 750 | 95-165 | 150-350 | 110-132 | 54.5 | 3789×3050×3025 |
| PE1000×1200 | 46x48 | 1000×1200 | 850 | 105-185 | 180-400 | 132-160 | 56.5 | 3900×3320×3280 |
1. Packing Requirement: Standard Containers;
2. Inner Packing: Product wrapped by PP-Bubble;
3. Outer Packing: Load container, Spare Parts in wooden case;
4. Storage Requirement: waterproof, put in the flat ground.
Transportation:
1. These machines are processed to be rustproof and moisture proof before delivery.
2. Large mainframes are in nude, while small spare parts and motors are in wooden boxes.
3. All items are in bulk or containers, details will be negotiated by both parts afterwards.
Terms of Trade:
1.Payment: 30% advance payment by T/T, 70% balance should be paid off before loading, Western Union, L/C is available.
2. FOB and EXW all are available.
3. Production lead time: 15-40 days.
4. Shipping freight is quoted under your requests.
Small Lab 3 tph Stone Jaw Crusher PE 150 x 250 Mini Jaw Crusher Price Zambia
Our Company guarantee the quality of equipments (excluding wearing parts) for a period of one year (12months) from the date of trial run finish, but not exceeding 18 months from the date on which machines leave factory. Outside the warranty period or man-made damage to the equipment, we will provide life-long maintenance services for spare parts at cost price.
