HOUNY HY-12-200 LifePO4 battery pack use the grade A LifePO4 battery, whose life span is 10 times longer than the tranditional lead acid batteries, and it is lighter. For the capacity, Lifepo4 batteries can provide twice the battery capacity in the same amount of space. With operating ranges from -40 to 158 degrees Fahrenheit, LifePO4 handle far wider variations in temperature.
- Product Details
- {{item.text}}
Quick Details
-
Battery type:
-
LiFePO4
-
Nominal Voltage:
-
12V/24V/36V/48V/Optional
-
Nominal Capacity:
-
200Ah battrie lithium 200 ah lithium battery
-
Cycle life:
-
4000 Cycles @1C 80%DOD
-
Warranty:
-
12months
-
Size:
-
520*240*218mm
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Certification:
-
CE , ISO9001, ROHS, IEC62133, MSDS, UN38.3
-
Weight:
-
24.7KG
Quick Details
-
Model Number:
-
HY12-200-4
-
Brand Name:
-
Houny
-
Place of Origin:
-
Guangdong, China
-
Battery type:
-
LiFePO4
-
Nominal Voltage:
-
12V/24V/36V/48V/Optional
-
Nominal Capacity:
-
200Ah battrie lithium 200 ah lithium battery
-
Cycle life:
-
4000 Cycles @1C 80%DOD
-
Warranty:
-
12months
-
Size:
-
520*240*218mm
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Certification:
-
CE , ISO9001, ROHS, IEC62133, MSDS, UN38.3
-
Weight:
-
24.7KG
Product Description
|
Product Name
|
Deep Cycle Lithium Iron Phosphate Battery BMS 12V 24V 48V 72V lifepo4 batteries 100Ah 200Ah 280Ah lithium battery solar storage
|
|
Capacity
|
12.8V 200Ah 2560Wh
|
|
Battery type
|
LifePO4 Battery
|
|
Size
|
522*240*218mm
|
|
Cycle Life
|
≥4000@25℃
|
|
Working temperature
|
-20~55℃
|
|
Discharge Voltage
|
12.8V
|
|
Charge Voltage
|
13.5~14.6℃
|
|
Internal Impedance(mΩ)
|
≤20
|
|
Max Charge Current(A)
|
100A
|
|
Max Discharge Current(A)
|
150A
|
-
Product performance description
-
Details Images
Waterproof
Injection molding makes the housing and cover hermetically closed, prevent the battery from rain drops.
High quality ABS materials
The ABS is a good material bacause of its crash resistance, heat resistance low temperature resistant. Now it is being widely used in many areas.
Appearance design
The battery pack can be easly carried with its grooves on both side of the upper cover.
The positive and negative terminals are glued and well sealed, the glue color can be customized.
M8 pure brass terminals is capable of having large current go through it, its brasee terminals are rust resistant guarantee its good power supplying.
Product Usage
-
-
Product usage introduction
-
Multiple applications :
* Large-scale electric vehicles: electric bus, electric car, e-tour car
* Small electric vehicles: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
* Electric drill, electric saw, lawn mower and so on
* Electric boat, aircraft, toys
* Solar power generation energy storage devices, telecom base Station
* RV,camping car and yacht
*Solar street lights,bicycle lights,LED lights,bright flashlight
* Large-scale electric vehicles: electric bus, electric car, e-tour car
* Small electric vehicles: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
* Electric drill, electric saw, lawn mower and so on
* Electric boat, aircraft, toys
* Solar power generation energy storage devices, telecom base Station
* RV,camping car and yacht
*Solar street lights,bicycle lights,LED lights,bright flashlight
Company Introduction
Packing&Shipping
Packaging:
1) carton box -pallet-container
2) Packaging also can be made by customers requirements
Shipping:
Delivery time for bulk order: 30-45 days after received the deposit.
Sample order is supposed to be shipped within 7 days , bulk order is suggested to ship by sea, we could supply forwarder service
if you need .
1) carton box -pallet-container
2) Packaging also can be made by customers requirements
Shipping:
Delivery time for bulk order: 30-45 days after received the deposit.
Sample order is supposed to be shipped within 7 days , bulk order is suggested to ship by sea, we could supply forwarder service
if you need .
FAQ
1. Q: Can I have my own logo on lifepo4 battery packs?
A: Of course , we could supply silk print for MOQ 100pcs, OEM is acceptable .
2. Are you a factory ?
A: Yes, We are manufacturer, our factory is located in Shenzhen , welcome to pay a visit to us for further cooperation.
3. How about the quality ?
The power station go with a strict QA and QC to ensure the quality during the production, we have the CE,FCC ,ROHS,MSDS etc.
certification ,besides , all our power station have 1 year warranty .
A: Of course , we could supply silk print for MOQ 100pcs, OEM is acceptable .
2. Are you a factory ?
A: Yes, We are manufacturer, our factory is located in Shenzhen , welcome to pay a visit to us for further cooperation.
3. How about the quality ?
The power station go with a strict QA and QC to ensure the quality during the production, we have the CE,FCC ,ROHS,MSDS etc.
certification ,besides , all our power station have 1 year warranty .
