Quick Details
-
Weight:
-
35000 KG
-
Marketing Type:
-
New Product 2021
-
Height of Working State:
-
14900mm
-
Width of Working State:
-
2990mm
-
Length of Crawler:
-
4446mm
-
Outer Width of Crawler:
-
2990mm
-
Width of Crawler Plate:
-
600mm
-
Hauling Force:
-
198kN
-
Maximum Torque:
-
120kN.m
-
Speed:
-
8-28r/min
-
Maximum Pressure:
-
120kN
-
Pressurized Cylinder Stroke:
-
3600mm
Quick Details
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Sinomada
-
Dimension(L*W*H):
-
12630*2990*3350mm
-
Weight:
-
35000 KG
-
Marketing Type:
-
New Product 2021
-
Height of Working State:
-
14900mm
-
Width of Working State:
-
2990mm
-
Length of Crawler:
-
4446mm
-
Outer Width of Crawler:
-
2990mm
-
Width of Crawler Plate:
-
600mm
-
Hauling Force:
-
198kN
-
Maximum Torque:
-
120kN.m
-
Speed:
-
8-28r/min
-
Maximum Pressure:
-
120kN
-
Pressurized Cylinder Stroke:
-
3600mm
Yuchai Brand YCR-120 35Ton Hydraulic Rotary Drilling Rig Low Price For Sale
Product Description
Specification
Features
①Chassis
Hydraulic drive structure enhances the reliability and stability while working.
②Engine
Equipped with imported 6BT5.9-150 engine, adopting advanced power control mode which can automatically adapt the change of load.
③Main Hoist
④Auxiliary Hoist Mounted in triangle to enhance the whole stability.
⑤Mast One of the most important components, main part of suspension and guidance; automatically headstand, box type design enhanced the mast rigidity.
⑥Pulley Frame
⑦Cylinder Pressurized cylinder, stroke: 3600mm.
⑧Power Head Double-motor reducer can adjust steplessly according to the load
⑨Drill Pipe Oriented by mast, divided into friction rod and lock rod.
①Chassis
Hydraulic drive structure enhances the reliability and stability while working.
②Engine
Equipped with imported 6BT5.9-150 engine, adopting advanced power control mode which can automatically adapt the change of load.
③Main Hoist
④Auxiliary Hoist Mounted in triangle to enhance the whole stability.
⑤Mast One of the most important components, main part of suspension and guidance; automatically headstand, box type design enhanced the mast rigidity.
⑥Pulley Frame
⑦Cylinder Pressurized cylinder, stroke: 3600mm.
⑧Power Head Double-motor reducer can adjust steplessly according to the load
⑨Drill Pipe Oriented by mast, divided into friction rod and lock rod.
|
Principle Dimension
|
|
|
|
* Height of Working State
|
14900mm
|
|
|
* Width of Working State
|
2990mm
|
|
|
* Length fo Travel Position
|
12630mm
|
|
|
* Height of Travel Position
|
3350mm
|
|
|
* Width of Travel Position
|
2990mm
|
|
|
* Length of Crawler
|
4446mm
|
|
|
Technical Specification
|
|
|
|
Chassis
|
|
|
|
Outer Width of Crawler
Width of Crawler Plate Hauling Force |
2990mm
600mm 198kN |
|
|
Power Head
|
|
|
|
Maximum Torque
Speed Maximum Pressure Maximum Pulling Force Pressurized Cylinder Stroke |
120kN·m
8-28r/min 120kN 120kN 3600mm |
|
|
Hoist
|
|
|
|
Main Hoist
1st Layer of Lifting Force
Maximum Lifting Speed
Diameter of Wirerope Auxiliary Hoist 1st Layer of Lifting Force Maximum Lifting Speed Diameter of Wirerope |
60m/min Φ22mm
50kN
65m/min Φ16mm |
|
|
Mast
|
|
|
|
Rake Angle
L/R Tilt Angle |
5°
±4° |
|
|
Hydraulic Pump
|
|
|
|
Maximum Pressure
|
34Mpa
|
|
|
Hole Depth/Diameter
|
|
|
|
Maximum Drilling Diameter
Maximum Drilling Depth |
1500mm
40m |
|
|
Drill Pipe
|
|
|
|
Drilling Pipe
Working Weight |
377mm
35t |
|
