Quick Details
-
Coil Number:
-
AUTOTRANSFORMER
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ES
-
Model Number:
-
T-D12060-A
-
Application:
-
Halogen Lamp
-
Certification:
-
UL CUL
-
Product Name:
-
Electronic Transformer
-
Type:
-
Consant Current
-
Efficiency:
-
81%
-
Output Voltage:
-
12VAC
-
Protections:
-
Over Current, Short Circuit,Over temp
-
Size:
-
65*35*23mm
-
Case material:
-
Plastice
-
Color:
-
White
Quick Details
-
Usage:
-
be used for halogen light bulbs
-
Phase:
-
Single
-
Coil Structure:
-
TOROIDAL
-
Coil Number:
-
AUTOTRANSFORMER
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ES
-
Model Number:
-
T-D12060-A
-
Application:
-
Halogen Lamp
-
Certification:
-
UL CUL
-
Product Name:
-
Electronic Transformer
-
Type:
-
Consant Current
-
Efficiency:
-
81%
-
Output Voltage:
-
12VAC
-
Protections:
-
Over Current, Short Circuit,Over temp
-
Size:
-
65*35*23mm
-
Case material:
-
Plastice
-
Color:
-
White
Products Description
|
Model No.
|
|
T-D12060-A
|
|
|
|
Input
|
Voltage Frequency Range
|
110-120VAC,50/60HZ
|
|
|
|
|
AC Current (Max)
|
0.5A at 115Vac
|
|
|
|
|
Power Factor
|
>0.95 at 115Vac with full load
|
|
|
|
|
Inrush Current (Max)
|
N/A
|
|
|
|
|
Leakage Current
|
N/A
|
|
|
|
Output
|
AC Voltage Range
|
12V AC
|
|
|
|
|
Min. Power
|
20W
|
|
|
|
|
Rated Max.Power
|
60W
|
|
|
|
|
Efficiency note1
|
81%
|
|
|
|
Others
|
MTBF
|
100K hours min. @Ta=25℃
|
|
|
|
|
Dimension (L*W*H)
|
65* 35 * 23 mm
|
|
|
|
|
Packing (L*W*H) / Carton
|
360 * 240 * 190 CM; 100pcs/9.5kg
|
|
|
Ever Shining also supplying 80W and 150W
Halogen / Xenon Electronic Transformers, Welcome to send inquiry now !
