Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JK
-
Model Number:
-
JK80BLS
-
Torque:
-
1.4N.M
-
motor type:
-
80mm*80mm
-
Product Name:
-
80BLS
-
Keywords:
-
48v brushless dc motor
-
Insulation Class:
-
B
-
Insulation Resistance:
-
100MΩ Min . 500V DC
-
Max. radial force:
-
115N @ 20mm from the flange
-
Radial play:
-
0.02mm@450g
-
End play:
-
0.008mm@450g
-
Shaft run out:
-
0.025mm
-
Max axial force:
-
45N
Quick Details
-
Speed(RPM):
-
3000rpm
-
Continuous Current(A):
-
3-10.5A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
JK
-
Model Number:
-
JK80BLS
-
Torque:
-
1.4N.M
-
motor type:
-
80mm*80mm
-
Product Name:
-
80BLS
-
Keywords:
-
48v brushless dc motor
-
Insulation Class:
-
B
-
Insulation Resistance:
-
100MΩ Min . 500V DC
-
Max. radial force:
-
115N @ 20mm from the flange
-
Radial play:
-
0.02mm@450g
-
End play:
-
0.008mm@450g
-
Shaft run out:
-
0.025mm
-
Max axial force:
-
45N
Specification
|
item
|
value
|
|
Warranty
|
3months-1year
|
|
Place of Origin
|
China
|
|
|
Jiangsu
|
|
Brand Name
|
JK
|
|
Model Number
|
JK80BLS
|
|
Usage
|
BOAT, Car, Electric Bicycle, Mechanical equipment
|
|
Type
|
BLS dc motor
|
|
Torque
|
1.4N.M
|
|
Construction
|
Shunt Wound
|
|
Commutation
|
Brushless
|
|
Protect Feature
|
Drip-proof
|
|
Speed(RPM)
|
3000rpm
|
|
Continuous Current(A)
|
3-10.5A
|
|
Efficiency
|
IE 1
|
|
motor type
|
80mm*80mm
|
|
Product Name
|
80BLS
|
|
Keywords
|
48v brushless dc motor
|
|
Insulation Class
|
B
|
|
Insulation Resistance
|
100MΩ Min . 500V DC
|
|
Max. radial force
|
115N @ 20mm from the flange
|
|
Radial play
|
0.02mm@450g
|
|
End play
|
0.008mm@450g
|
|
Shaft run out
|
0.025mm
|
|
Max axial force
|
45N
|
Product Name: Brushless DC Motor
Number of Phase: 3 Phase
Number of Poles: 4 Poles /8 Poles /10 Poles
Rated Voltage: 24v /36v /48v /310v
Rated Speed: 3000rpm /4000rpm /or customized
Rated Torque: Customized
Rated Current: Customized
Rated Power: 23w~2500W
|
80mm BLDC MOTOR SPECIFICATION:
|
|
|
|
|
|
|||||
|
|
|
Model
|
|
|
|
|||||
|
Specification
|
Unit
|
JK80BLS01
|
JK80BLS02
|
JK80BLS03
|
JK80BLS04
|
|||||
|
Number Of Phase
|
Phase
|
3
|
|
|
|
|||||
|
Number Of Poles
|
Poles
|
4
|
|
|
|
|||||
|
Rated Voltage
|
VDC
|
48
|
|
|
|
|||||
|
Rated Speed
|
Rpm
|
3000
|
|
|
|
|||||
|
Rated Torque
|
N.m
|
0.35
|
0.7
|
1.05
|
1.4
|
|||||
|
Rated Current
|
Amps
|
3
|
5.5
|
8
|
10.5
|
|||||
|
Rated Power
|
W
|
110
|
220
|
330
|
440
|
|||||
|
Peak Torque
|
N.m
|
1.05
|
2.1
|
3.15
|
4.2
|
|||||
|
Peak Current
|
Amps
|
9
|
16.5
|
24
|
31.5
|
|||||
|
Back E.M.F
|
V/Krpm
|
13.5
|
13.3
|
13.1
|
13
|
|||||
|
Torque Constant
|
N.m/A
|
0.13
|
0.127
|
0.126
|
0.124
|
|||||
|
Rotor Inertia
|
g.c㎡
|
210
|
420
|
630
|
840
|
|||||
|
Body Length
|
mm
|
78
|
98
|
118
|
138
|
|||||
|
Weight
|
Kg
|
1.4
|
2
|
2.6
|
3.2
|
|||||
|
Product Series
|
Poles No.
|
Rated Voltage
|
Rated Speed
|
Rated Torque
|
Rated Power
|
Motor Length
|
||||||
|
8
|
24v
|
4000rpm
|
0.0625~0.25N.m
|
26~105w
|
41~100mm
|
|||||||
|
4
|
36v
|
4000rpm
|
0.055~0.44N.m
|
23~184w
|
37~107mm
|
|||||||
|
8
|
48v
|
3000rpm
|
0.3~1.2N.m
|
94~377w
|
78~120mm
|
|||||||
|
4
|
48v
|
3000rpm
|
0.35~1.4N.m
|
110~440w
|
78~138mm
|
|||||||
|
8
|
48v
|
3000rpm
|
0.35~2.1N.m
|
110~660w
|
71~138.5mm
|
|||||||
|
8
|
310v
|
3000rpm
|
1.65~6.6N.m
|
518~2073w
|
83~173mm
|
|||||||
|
10
|
310v
|
3000rpm
|
2.39~11.94N.m
|
750~2500w
|
115~190mm
|
|||||||
|
Above only for representative products, products of special request can be made according to the customer request.
|
|
|
|
|
|
|
||||||
|
42mm BLDC MOTOR SPECIFICATION:
|
|
|
|
|
|
|||||
|
|
|
Model
|
|
|
|
|||||
|
Specification
|
Unit
|
JK42BLS01
|
JK42BLS02
|
JK42BLS03
|
JK42BLS04
|
|||||
|
Number Of Phase
|
Phase
|
3
|
|
|
|
|||||
|
Number Of Poles
|
Poles
|
8
|
|
|
|
|||||
|
Rated Voltage
|
VDC
|
24
|
|
|
|
|||||
|
Rated Speed
|
Rpm
|
4000
|
|
|
|
|||||
|
Rated Torque
|
N.m
|
0.0625
|
0.125
|
0.185
|
0.25
|
|||||
|
Rated Current
|
Amps
|
1.8
|
3.3
|
4.8
|
6.3
|
|||||
|
Rated Power
|
W
|
26
|
52.5
|
77.5
|
105
|
|||||
|
Peak Torque
|
N.m
|
0.19
|
0.38
|
0.56
|
0.75
|
|||||
|
Peak Current
|
Amps
|
5.4
|
10.6
|
15.5
|
20
|
|||||
|
Back E.M.F
|
V/Krpm
|
4.1
|
4.2
|
4.3
|
4.3
|
|||||
|
Torque Constant
|
N.m/A
|
0.039
|
0.04
|
0.041
|
0.041
|
|||||
|
Rotor Inertia
|
g.c㎡
|
24
|
48
|
72
|
96
|
|||||
|
Body Length
|
mm
|
41
|
61
|
81
|
100
|
|||||
|
Weight
|
kg
|
0.3
|
0.45
|
0.65
|
0.8
|
|||||
|
57mm BLDC MOTOR SPECIFICATION:
|
|
|
|
|
|
|
||||||
|
Model
|
|
Model
|
|
|
|
|
||||||
|
Specification
|
Unit
|
JK57BLS005
|
JK57BLS01
|
JK57BLS02
|
JK57BLS03
|
JK57BLS04
|
||||||
|
Number Of Phase
|
Phase
|
3
|
|
|
|
|
||||||
|
Number Of Poles
|
Poles
|
4
|
|
|
|
|
||||||
|
Rated Voltage
|
VDC
|
36
|
|
|
|
|
||||||
|
Rated Speed
|
Rpm
|
4000
|
|
|
|
|
||||||
|
Rated Torque
|
N.m
|
0.055
|
0.11
|
0.22
|
0.33
|
0.44
|
||||||
|
Rated Current
|
Amps
|
1.2
|
2
|
3.6
|
5.3
|
6.8
|
||||||
|
Rated Power
|
W
|
23
|
46
|
92
|
138
|
184
|
||||||
|
Peak Torque
|
N.m
|
0.16
|
0.33
|
0.66
|
1
|
1.32
|
||||||
|
Peak Current
|
Amps
|
3.5
|
6.8
|
11.5
|
15.5
|
20.5
|
||||||
|
Back E.M.F
|
V/Krpm
|
7.8
|
7.7
|
7.4
|
7.3
|
7.1
|
||||||
|
Torque Constant
|
N.m/A
|
0.074
|
0.073
|
0.07
|
0.07
|
0.068
|
||||||
|
Rotor Inertia
|
g.c㎡
|
30
|
75
|
119
|
173
|
230
|
||||||
|
Body Length
|
mm
|
37
|
47
|
67
|
87
|
107
|
||||||
|
Weight
|
Kg
|
0.33
|
0.44
|
0.75
|
1
|
1.25
|
||||||
|
60mm BLDC MOTOR SPECIFICATION:
|
|
|
|
|
|
|||||
|
|
|
Model
|
|
|
|
|||||
|
Specification
|
Unit
|
JK60BLS01
|
JK60BLS02
|
JK60BLS03
|
JK60BLS04
|
|||||
|
Number Of Phase
|
Phase
|
3
|
|
|
|
|||||
|
Number Of Poles
|
Poles
|
8
|
|
|
|
|||||
|
Rated Voltage
|
VDC
|
48
|
|
|
|
|||||
|
Rated Speed
|
Rpm
|
3000
|
|
|
|
|||||
|
Rated Torque
|
N.m
|
0.3
|
0.6
|
0.9
|
1.2
|
|||||
|
Rated Current
|
Amps
|
2.8
|
5.2
|
7.5
|
9.5
|
|||||
|
Rated Power
|
W
|
94
|
188
|
283
|
377
|
|||||
|
Peak Torque
|
N.m
|
0.9
|
1.8
|
2.7
|
3.6
|
|||||
|
Peak Current
|
Amps
|
8.4
|
15.6
|
22.5
|
28.5
|
|||||
|
Back E.M.F
|
V/Krpm
|
12.1
|
12.6
|
12.4
|
13.3
|
|||||
|
Torque Constant
|
N.m/A
|
0.116
|
0.12
|
0.118
|
0.127
|
|||||
|
Rotor Inertia
|
g.c㎡
|
0.24
|
0.48
|
0.72
|
0.96
|
|||||
|
Body Length
|
mm
|
78
|
99
|
120
|
141
|
|||||
|
Weight
|
Kg
|
0.85
|
1.25
|
1.65
|
2.05
|
|||||
|
86mm BLDC MOTOR SPECIFICATION:
|
|
|
|
|
|
|
||||||
|
Model
|
|
Model
|
|
|
|
|
||||||
|
Specification
|
Unit
|
JK86BLS58
|
JK86BLS71
|
JK86BLS84
|
JK86BLS98
|
JK86BLS125
|
||||||
|
Number Of Phase
|
Phase
|
3
|
|
|
|
|
||||||
|
Number Of Poles
|
Poles
|
8
|
|
|
|
|
||||||
|
Rated Voltage
|
VDC
|
48
|
|
|
|
|
||||||
|
Rated Speed
|
Rpm
|
3000
|
|
|
|
|
||||||
|
Rated Torque
|
N.m
|
0.35
|
0.7
|
1.05
|
1.4
|
2.1
|
||||||
|
Rated Current
|
Amps
|
3
|
6.3
|
9
|
11.5
|
18
|
||||||
|
Rated Power
|
W
|
110
|
220
|
330
|
440
|
660
|
||||||
|
Peak Torque
|
N.m
|
1.05
|
2.1
|
3.15
|
4.2
|
6.3
|
||||||
|
Peak Current
|
Amps
|
9
|
19
|
27
|
35
|
54
|
||||||
|
Back E.M.F
|
V/Krpm
|
13.7
|
13
|
13.5
|
13.7
|
13.5
|
||||||
|
Torque Constant
|
N.m/A
|
0.13
|
0.12
|
0.13
|
0.13
|
0.13
|
||||||
|
Rotor Inertia
|
g.c㎡
|
400
|
800
|
1200
|
1600
|
2400
|
||||||
|
Body Length
|
mm
|
71
|
84.5
|
98
|
111.5
|
138.5
|
||||||
|
Weight
|
Kg
|
1.5
|
1.9
|
2.3
|
2.7
|
4
|
||||||
Changzhou Jkongmotor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.
JKONGMOTOR warmly welcome 'OEM' & 'ODM' cooperations and other companies to establish long-term cooperation with us.
Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.
Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.
1. Can you make the gearbox or gearmotor with custom specifications?
YES. We have strong R&D capability, also a great term of engineers, each of them have many work years experience.
2. Do you provide the samples?
YES. Our company can provide the samples to you
3.Do you provide technology support?
YES. Our company have strong R&D capability, we can provide technology support if you need.
4. why should you buy from us not from other suppliers?
Professional one-to-one motor customized . The world's large enterprise of choice for high quality suppliers . ISO9001:2008 quality management system certification, through the CE, ROHS certification.
5. How to ship to us?
We will ship the samples to you according to the DHL or UPS or FEDEX etc account you provide.
6. How can I know the product is suitable for me?
Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.
YES. We have strong R&D capability, also a great term of engineers, each of them have many work years experience.
2. Do you provide the samples?
YES. Our company can provide the samples to you
3.Do you provide technology support?
YES. Our company have strong R&D capability, we can provide technology support if you need.
4. why should you buy from us not from other suppliers?
Professional one-to-one motor customized . The world's large enterprise of choice for high quality suppliers . ISO9001:2008 quality management system certification, through the CE, ROHS certification.
5. How to ship to us?
We will ship the samples to you according to the DHL or UPS or FEDEX etc account you provide.
6. How can I know the product is suitable for me?
Frist, you need to provide us the more details information about the product. We will recommend the item to you according to your requirement of specification. After you confirm, we will prepare the samples to you. also we will offer some good advances according to your product use.
