Quick Details
-
Brand Name:
-
HELI
-
Fork Length:
-
1220mm
-
Fork Width:
-
150mm
-
Overall Dimensions:
-
4710*2045*2450mm
-
Weight (KG):
-
8300 kg
-
Rated Loading Capacity:
-
5000kg
-
Load center:
-
600mm
-
The Minimum Turning Radius(outer):
-
3240mm
-
Maximum Speed (Full/Empty):
-
24/29km/h
-
Maximum Traction (Full/Empty):
-
63kn
-
Rated Power:
-
83/2000 KW/rpm
-
fork size:
-
1220*150*50mm
-
Rated torque:
-
450/1400-1500Nm/rpm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE/ISO9001
Quick Details
-
Min. Lifting Height:
-
200mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
HELI
-
Fork Length:
-
1220mm
-
Fork Width:
-
150mm
-
Overall Dimensions:
-
4710*2045*2450mm
-
Weight (KG):
-
8300 kg
-
Rated Loading Capacity:
-
5000kg
-
Load center:
-
600mm
-
The Minimum Turning Radius(outer):
-
3240mm
-
Maximum Speed (Full/Empty):
-
24/29km/h
-
Maximum Traction (Full/Empty):
-
63kn
-
Rated Power:
-
83/2000 KW/rpm
-
fork size:
-
1220*150*50mm
-
Rated torque:
-
450/1400-1500Nm/rpm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE/ISO9001
Contact
Alune Xie —— Sales Assistant
mobile phone/Wechat:
+86 19313329653
Email: alune@richmchn.com
Products Description
5ton forklift HELI CPCD50
1.longer time warranty: one year,
2.package:sea protecting package with film not nude wether by container or not.
3.quality is strong with good steel body frame, brand component, technology is mature.
4.suitable design that the length size of forklift is longer because of the suitable driving space
5.lower price compare the same machines
6.service is satisfied with our after-sales team and engineering team
2.package:sea protecting package with film not nude wether by container or not.
3.quality is strong with good steel body frame, brand component, technology is mature.
4.suitable design that the length size of forklift is longer because of the suitable driving space
5.lower price compare the same machines
6.service is satisfied with our after-sales team and engineering team
Details Images
Product Paramenters
|
Model
|
Unit
|
CPCD50
|
CPCD60
|
CPCD70
|
CPCD85
|
CPCD100
|
||||
|
Power Type
|
|
Diesel
|
|
|
|
|
||||
|
Load Capacity
|
kg
|
5000
|
6000
|
7000
|
8500
|
10000
|
||||
|
Load Center
|
mm
|
600
|
|
|
|
|
||||
|
Maximum Lifting Height
|
mm
|
|
|
|
|
|
||||
|
Free Hoisting Height
|
mm
|
|
|
|
|
|
||||
|
Overall Height(Upper frame protection)
|
mm
|
2450
|
2450
|
2450
|
2560
|
2560
|
||||
|
Full Length(with cargo fork)
|
mm
|
4710
|
4790
|
4840
|
5180
|
5430
|
||||
|
Full Width
|
mm
|
2045
|
2045
|
2045
|
2165
|
2165
|
||||
|
The Minimum Ground Clearance(the door)
|
mm
|
200
|
200
|
200
|
250
|
250
|
||||
|
The Minimum Turning Radius(outer)
|
mm
|
3240
|
3300
|
3370
|
3650
|
3900
|
||||
|
Least Square Channel Width
|
mm
|
3200
|
3260
|
3330
|
3590
|
3860
|
||||
|
Pallet Fork a*b*c
|
mm
|
1220*150*55
|
1220*150*60
|
1220*150*65
|
1220*170*70
|
1220*175*80
|
||||
|
Maximum Speed (Full/Empty)
|
km/h
|
24/29
|
|
|
|
|
||||
|
Maximum Traction (Full/Empty)
|
KN
|
63
|
63
|
62
|
60
|
58
|
||||
|
Maximum Gradeability(Full/Empty)
|
%
|
38/19
|
35/19
|
32/19
|
23/20
|
21/20
|
||||
|
Tire Type(Before/After)
|
|
2/2
|
|
|
|
|
||||
|
Engine Manufactures
|
|
CA6110
|
|
|
|
|
||||
|
Rated Power
|
KW/rpm
|
83/2000
|
|
|
|
|
||||
|
Rated torque
|
Nm/rpm
|
450/1400-1500
|
|
|
|
|
||||
|
Total water(oil)
|
kg
|
8300
|
9050
|
9650
|
11500
|
12600
|
||||
packing & shipping
