safeway scaffolding for sale with High Quality

QSR ound Universal Scaffolding has been examined by SP Swedish testing and research institute and comply with the European Standard SS-EN 12810-1

Product description

The universal scaffolding system QSRound is constructed by prefabricated steel components. Standards, ledgers, U-transoms, and diagonal braces that can be connected horizontally and vertically. Assembly rings are attached to the standards at a distance of 0.50m with eight connection points for assembly of ledgers and U transoms. The standards have the length of 0.5m to a maximum of 4.0m. Scaffolding bays come in length 3.07m,2.57m,2.07m and 1.57m. Horizontals are made in the same lengths and U transoms are 0.3m, 1.09m and 1.40m wide. All demensions are based on centre c/c between standards.

STANDARD	European Standard SS-EN 12810-1
Permissible load	load class 2-6(1.5-4.5kN/m2 )
Surface finish	hot dipped galvanized
Material	Q345, Q235

Loading conditions	Plank all lifts	One working height
Modular size	2.57x1.40m	3.07x1.40m	3.07x1.09m
Lift height	2.0m	2.0m	2.0m
Steel Plank	24.0m load class 4	24.0m load class 3	24.0m load class 4
Alu-Plank Extruded	24.0m load class 6	24.0m load class 5	24.0m load class 5

Why choose us

1. professional scaffolding and Formwork manufacturer

Qingdao Scaffolding Co.,Ltd. is the leading manufacturer in China for scaffolding systems,

tube and fittings, props and formwork accessories.

All our products are made as per European standard, American standard and Australian
Standard.

For more than 15 years, our products are widely used in mining, construction, petrochemical
and even industries all over the world; especially in whole Europe, Australia, New Zealand,
U.S.A., Canada, South American countries and African countries.

With more than 15 years of experience , adhering to the principle of "high quality,
reasonable price, best service", we have won the honor of "the only five star supplier in the

scaffold field in whole China".

2. Product

QS Round scaffolding(Ringlock Scaffolding, Galvanized)

Kwikstage type Scaffolding Systems (Galvanized and Painted)

Cuplock Type Scaffolding Systems(Galvanized and Painted)

Formwork Frames(Galvanized and Painted)

Formwork Props(Galvanized and Painted)

Jacks-All types(Formwork & Scaffolding)

Fittings / Couplers (Forged / Pressed)

Scaffold Tubes(Galvanized and Black)

Scaffold Boards(Galvanized and Timber)

Formwork and Formwork Accessories

Aluminium Scaffolding

Any component as per customers requirement and specifications can be manufactured and

supplied at reasonable prices and good quality.

3. Quality

At Qingdao Scaffolding Co., Ltd. we provide a quality product that meets all safety standards. All components

supplied by Qingdao Scaffolding are manufactured, tested and approved as per AS/NZS standard, European

Standard, German Standard and U.S.A. Standard.

4. Timely delivery

5. Inspection

A professional quality control team involves in everyday production.

6. Packaging & Shipping

We ensure your goods can be delivered safely:

We have long-term cooperative freight forwarding and shipping company .

Any interest or questions,welcome to contact us.

Warmly welcome to visit us.
