Double shaft shredder is used for plastic lumps,die material, big block material, HDPE, PVC thick wall pipe and other plastic material which is difficult to process by the crusher machine. It is with good shaft structure design, low noise, durable use and the blades are changeable.
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
Customization
-
Year:
-
2023
-
Weight (KG):
-
5000 kg
-
Power (kW):
-
22KW*2
-
Name:
-
Waste Recycling Shredder Machine
-
Keyword:
-
Double Shaft Scrap Metal Recycling
-
Application:
-
Recycle Waste Plastic
-
Crushing material:
-
Types Waste Plastic
-
Function:
-
Plastic Cutter Grinder Crusher Shredder Machine
-
Material:
-
Steel Iron
-
Capacity:
-
300-3000kg/h
-
Advantage:
-
High Producing Efficiency
-
Color:
-
Client's Requirements
-
Raw material:
-
Plastic Products Paper Wood Metal Product
Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
800
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
Customization
-
Year:
-
2023
-
Weight (KG):
-
5000 kg
-
Power (kW):
-
22KW*2
-
Name:
-
Waste Recycling Shredder Machine
-
Keyword:
-
Double Shaft Scrap Metal Recycling
-
Application:
-
Recycle Waste Plastic
-
Crushing material:
-
Types Waste Plastic
-
Function:
-
Plastic Cutter Grinder Crusher Shredder Machine
-
Material:
-
Steel Iron
-
Capacity:
-
300-3000kg/h
-
Advantage:
-
High Producing Efficiency
-
Color:
-
Client's Requirements
-
Raw material:
-
Plastic Products Paper Wood Metal Product
|
Tire shredder machine tire recycling plant/Rubber tire waste plastic bottle shredder/Tire shredders tire recycling machine
|
|
|
|
|
||||
1.Brief introduction：
2.Working Principles：
This equipment is mainly composed of feed hopper,double shaft cutting system, Plc control system, discharging conveyor system and power system, etc.
1.Feed hopper: Put the material to be crushed, so as to prevent the material from splashing out.
2.Double shaft cutting system:Using different blades according customers' material.
3.Power system:We choose famous brands of motor in China, can also be configured according to customer needs.
4.Discharging conveyor system:It adopts independent power system, and that power system is integrally fixed on the shredder by bolts, so that the power system can be integrally drawn out.
1.Feed hopper: Put the material to be crushed, so as to prevent the material from splashing out.
2.Double shaft cutting system:Using different blades according customers' material.
3.Power system:We choose famous brands of motor in China, can also be configured according to customer needs.
4.Discharging conveyor system:It adopts independent power system, and that power system is integrally fixed on the shredder by bolts, so that the power system can be integrally drawn out.
Technical Parameters
|
Model
|
600
|
1000
|
1200
|
1500
|
1900
|
2600
|
|
Motor Power
|
11*2 Kw
|
30*2 Kw
|
45*2 Kw
|
55*2 Kw
|
90*2 Kw
|
160*2 Kw
|
|
Capacity
|
300-500Kg/H
|
1-2 T/H
|
3-4 T/H
|
4-5 T/H
|
8-10 T/H
|
13-15 T/H
|
|
Blade Number
|
34 Pieces
|
34 Pieces
|
30 Pieces
|
38 Pieces
|
34 Pieces
|
25 Pieces
|
|
Input Opening Size(mm)
|
950*700
|
1200*1000
|
1500*1200
|
2000*1500
|
2500*2000
|
3000*2500
|
|
Dimension L/W/H(m)
|
2.6*0.9*1.8
|
3.6*1.5*2.2
|
4.6*1.8*2.6
|
5.2*2.0*2.6
|
6.2*2.5*2.8
|
8.2*4.0*4.3
|
|
Weight
|
3T
|
5 T
|
8 T
|
13 T
|
18 T
|
36 T
|
Raw Materials & Finished Products
1.Metal:
aluminum can bundle, steel drum, car shell, color steel tile, bicycle, copper aluminum radiator, oil filter, scrap wires, cables, aluminum composite plastic panel, steel wire rope, gas tank, iron scrap, zip-top can, engine case, paint bucket, etc.
2.Plastic: plastic pallet, plastic drum, plastic bucket, plastic film, waste appliances shell, garbage plastic drum, IBC drum, IBC
barrel,garbage bag, rubbish bag, plastic pipe, washing machine, forklift pallet, lead acid battery shell, etc.
3.Textile: scrap clothes, shoes, fishing net, woven bag, ton bag, jumbo bag, fishing net bundles, dust collector bag, industrial
textile waste, etc.
4.Wood: wood mattress, wood furniture, wood pallet, scrap timber, sawdust chipboard, composite board, wooden door, forklift
pallet, wood board, wood template, wooden case, wooden box, wood sofa, wood bed, etc.
5.Paper: scrap paper and cartons, including scrap books, carton board, carton box, packaging box, waste newspaper, office paper, printing paper, paperboard, etc.
6.Waste household appliances: TV, washing machine, refrigerator shell etc.
7. Pipes: large pipes, pipe fittings, PE pipes etc.
8.Scrap tires: car tires, truck tires etc.
9.All kinds of Kitchen waste, domestic waste, rdf derivatives, medical waste,garden waste etc.
2.Plastic: plastic pallet, plastic drum, plastic bucket, plastic film, waste appliances shell, garbage plastic drum, IBC drum, IBC
barrel,garbage bag, rubbish bag, plastic pipe, washing machine, forklift pallet, lead acid battery shell, etc.
3.Textile: scrap clothes, shoes, fishing net, woven bag, ton bag, jumbo bag, fishing net bundles, dust collector bag, industrial
textile waste, etc.
4.Wood: wood mattress, wood furniture, wood pallet, scrap timber, sawdust chipboard, composite board, wooden door, forklift
pallet, wood board, wood template, wooden case, wooden box, wood sofa, wood bed, etc.
5.Paper: scrap paper and cartons, including scrap books, carton board, carton box, packaging box, waste newspaper, office paper, printing paper, paperboard, etc.
6.Waste household appliances: TV, washing machine, refrigerator shell etc.
7. Pipes: large pipes, pipe fittings, PE pipes etc.
8.Scrap tires: car tires, truck tires etc.
9.All kinds of Kitchen waste, domestic waste, rdf derivatives, medical waste,garden waste etc.
