Quick Details
-
Protection:
-
Over-discharging, Short Circuit Protection, Over-charging, Low Tension
-
Battery Type:
-
lifepo4 battery
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ODM/OEM
-
Model Number:
-
PPS2000
-
Weight:
-
17KG
-
Output Power:
-
1500W, 2000W
-
Full Charge Time:
-
5H
-
Voltage:
-
25.6V
-
Capacity:
-
60Ah
-
Energy:
-
1536wh
-
Cycle life:
-
2500 times DOD80% (0.33C)
-
AC Output Power:
-
2000W Max
-
AC output:
-
110V±10/60HZ 230V±10/50HZ
-
Dimension:
-
430 x223 x 270 mm
-
OEM/ODM:
-
Accepatable
-
Charge Current:
-
12A
Quick Details
-
Output Interface:
-
DC, Micro USB, Type C, USB/DC, USB/MICRO USB, Double Usb, Four Usb, Single USB, Apple Interface, Triple USB, Five USB, Apple Interface/USB, Apple Interface/Micro USB, Wireless
-
Input Interface:
-
usb, DC, Mini USB, Micro USB, AC, TYPE-C, Wireless
-
Socket Standard:
-
For USA/Canada, For E.U., For UK, For Australia/New Zealand, For Italy, For Brazil, For Japan, Universal, Micro USB, Others
-
Protection:
-
Over-discharging, Short Circuit Protection, Over-charging, Low Tension
-
Battery Type:
-
lifepo4 battery
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ODM/OEM
-
Model Number:
-
PPS2000
-
Weight:
-
17KG
-
Output Power:
-
1500W, 2000W
-
Full Charge Time:
-
5H
-
Voltage:
-
25.6V
-
Capacity:
-
60Ah
-
Energy:
-
1536wh
-
Cycle life:
-
2500 times DOD80% (0.33C)
-
AC Output Power:
-
2000W Max
-
AC output:
-
110V±10/60HZ 230V±10/50HZ
-
Dimension:
-
430 x223 x 270 mm
-
OEM/ODM:
-
Accepatable
-
Charge Current:
-
12A
Product Description
Specification
|
Nominal Voltage
|
25.6V
|
|
Nominal Capacity
|
60 Ah
|
|
Capacity @ 12A
|
300 min
|
|
Resistance |
≤20 mΩ @ 50% SOC |
|
Efficiency
|
99%
|
|
Self Discharge
|
<3% per Month
|
|
Cycle Life
|
2500 times DOD80% (0.33C)
|
|
Maximum Continuous Discharge Current
|
120 A
|
|
Peak Discharge Current
|
240 A (1-3 s)
|
|
Recommended Low Voltage Disconnect
|
21.6 V
|
|
BMS Discharge Voltage Cut-Off
|
20 V (2.5 ±0.08 vpc) (1s)
|
|
Reconnect Voltage
|
21.6 V (2.7 ±0.1 vpc)
|
|
Short Circuit Protection
|
200-600 µs
|
|
Dimensions (L x W x H) |
16.92 x 8.77 x 10.62 inch
430 x223 x 270 mm |
|
Net Weight
|
41.8 lbs (19 kg)
|
|
Case Material
|
ABS+SPCC
|
|
Enclosure Protection
|
IP30
|
|
Cell Type
|
LiFePO4
|
|
Recommended Charge Current
|
12 A
|
|
Maximum Charge Current
|
15 A
|
|
Recommended Charge Voltage
|
29.2 V
|
|
BMS Charge Voltage Cut-Off |
30 V (3.75 ±0.025 vpc) (1 s)
|
|
Reconnect Voltage
|
28.4 V (3.55 ±0.05 vpc)
|
|
Balancing Voltage
|
27.2 V (3.4 ±0.025 vpc)
|
|
AC Charger Input Power
|
350-450W
|
|
Full Charge Time
|
≈5h
|
|
AC Output Voltage
|
AC:100V-120V or AC220V-240V
|
|
AC Output Power Rating Power
|
2000W Max
|
|
AC peak Power
|
4000W 10mS
|
|
Highest conversion rate
|
≥85%
|
|
Solar charging Range
|
12-30V
|
|
Solar power
|
120W Max
|
|
USB-A（1）
|
QC3.0 18W 5V/3A,9V/3A,12V/1.45A
|
|
USB-A（2）
|
5V/3A
|
|
Type-C（1）
|
PD100W 5V/3A,9V/3A,12V/3A,15V/3A,20V/5A
|
|
Type-C（2）
|
PD100W 5V/3A,9V/3A,12V/3A,15V/3A,20V/5A
|
|
DC5521
|
12V 5A Max *1pcs
|
|
Car Port
|
13V 10A Max *1pcs
|
|
LED Light
|
4.8W *1pcs
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
