Solar power station systems are typically used for regional centralized power supply, such as village, island, fields monitoring
and so on. Also the power level range is between kilowatts to hundreds kilowatts.
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
SunEvo
-
Model Number:
-
EVO S
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1375*765*30mm
-
Number of Cells:
-
Mono crystalline 182*81mm (4*16pcs)
-
Weight:
-
10.87kg
-
Front Side Glass:
-
3.2 mm tempered glass
-
Frame:
-
Aluminum
-
Junction Box:
-
IP67, with bypass diodes
-
Cable:
-
90cm, length can be customized
-
Wind/Snow Load:
-
Front Side Max. 5400Pa, Rear Side Max. 2400Pa
-
Connector:
-
MC Compatible
-
Maximum system Voltage:
-
700Vdc
-
Operate Temperature:
-
-40C~ +85C
-
Certificate:
-
CE / CB / TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, IBC, HJT, hbc, N-TYPE, TOPCON
-
Panel Efficiency:
-
19.1%
-
Warranty:
-
25 YEARS
-
Brand Name:
-
SunEvo
-
Model Number:
-
EVO S
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1375*765*30mm
-
Number of Cells:
-
Mono crystalline 182*81mm (4*16pcs)
-
Weight:
-
10.87kg
-
Front Side Glass:
-
3.2 mm tempered glass
-
Frame:
-
Aluminum
-
Junction Box:
-
IP67, with bypass diodes
-
Cable:
-
90cm, length can be customized
-
Wind/Snow Load:
-
Front Side Max. 5400Pa, Rear Side Max. 2400Pa
-
Connector:
-
MC Compatible
-
Maximum system Voltage:
-
700Vdc
-
Operate Temperature:
-
-40C~ +85C
-
Certificate:
-
CE / CB / TUV
Products Description
|
Model
|
Pmax（W）
|
Vmp（V）
|
Imp
(A)
|
Voc
(V)
|
Isc
(A)
|
Length
(mm)
|
Width
(mm)
|
Thickness
(mm)
|
Weight（kg）
|
|
SE5-40M
|
40
|
16.53
|
2.42
|
19.12
|
2.55
|
580
|
395
|
25
|
2.55
|
|
SE5-50M
|
50
|
16.53
|
3.02
|
19.12
|
3.18
|
710
|
395
|
25
|
3.09
|
|
SE5-60M
|
60
|
20
|
3
|
23.18
|
3.16
|
855
|
395
|
25
|
3.69
|
|
SE5-70M
|
70
|
17.59
|
3.98
|
20.42
|
4.2
|
985
|
395
|
30
|
4.24
|
|
SE5-80M
|
80
|
16.53
|
4.84
|
19.12
|
5.09
|
570
|
765
|
30
|
4.67
|
|
SE5-90M
|
90
|
18.79
|
4.79
|
21.8
|
5.03
|
645
|
765
|
30
|
5.25
|
|
SE5-100M
|
100
|
21.03
|
4.76
|
24.47
|
5.02
|
720
|
765
|
30
|
5.83
|
|
SE5-110M
|
110
|
18.6
|
5.91
|
21.71
|
6.25
|
790
|
765
|
30
|
6.37
|
|
SE5-120M
|
120
|
19.54
|
6.14
|
22.57
|
6.46
|
1070
|
580
|
30
|
6.56
|
|
SE5-130M
|
130
|
21.25
|
6.12
|
24.58
|
6.44
|
885
|
765
|
30
|
7.1
|
|
SE5-140M
|
140
|
17.58
|
7.96
|
20.42
|
8.4
|
980
|
765
|
30
|
7.55
|
|
SE5-150M
|
150
|
18.79
|
7.98
|
21.8
|
8.42
|
1045
|
765
|
30
|
8.25
|
|
SE5-160M
|
160
|
19.99
|
8
|
23.18
|
8.43
|
1105
|
765
|
30
|
9.11
|
|
SE5-170M
|
170
|
21.18
|
8.03
|
24.54
|
8.46
|
1170
|
765
|
30
|
9.22
|
|
SE5-180M
|
180
|
37.58
|
4.79
|
43.6
|
5.05
|
1245
|
765
|
30
|
9.87
|
|
SE5-190M
|
190
|
39.79
|
4.78
|
46.26
|
5.04
|
1320
|
765
|
30
|
10.45
|
|
SE5-200M
|
200
|
18.76
|
10.66
|
21.79
|
11.24
|
1375
|
765
|
30
|
10.87
|
|
SE5-210M
|
210
|
39.73
|
5.29
|
46.23
|
5.58
|
1460
|
765
|
30
|
11.53
|
|
SE5-220M
|
220
|
17.84
|
12.33
|
20.57
|
12.97
|
1445
|
765
|
30
|
11.41
|
|
SE5-230M
|
230
|
18.85
|
12.2
|
21.83
|
12.85
|
1535
|
765
|
30
|
12.39
|
Product Packaging
Applications
Solar Home System
Solar home system are typically used for home photovoltaic power generation system, to solve electricity demand of none power or
unstable power region. Also the power level rage is between hundred watts to kilowatts.
unstable power region. Also the power level rage is between hundred watts to kilowatts.
Solar RVs/Vessels system are typically used for reducing the RVs and the vessels electricity cost, by setting up solar system to
assist gasoline/diesel power generator.
assist gasoline/diesel power generator.
Solar Street lights System
Solar Street lights System are typically used for street lightning of cities, villages, the intelligent streetlight system will
remote monitoring all street lamps to reduce the operation and maintenance costs of system.
remote monitoring all street lamps to reduce the operation and maintenance costs of system.
The Hybrid energy system contains solar, wind, diesel and city electricity energy system. The system will meet the load demand of
electricity in villages, islands, and telecom stations to reduce the system cost and improve the replenishment ratio of system.
electricity in villages, islands, and telecom stations to reduce the system cost and improve the replenishment ratio of system.
