Quick Details
-
Controller Type:
-
NONE
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
VDE ,EMC ,CE
-
Warranty:
-
25YEARS
-
Place of Origin:
-
China
-
Brand Name:
-
tsun
-
Model Number:
-
TSOL- ESK400-PB
-
Load Power (W):
-
400w
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
60Hz/50Hz
-
Work Time (h):
-
24 Hours
-
Recommended component power:
-
300-550W
-
Starting voltage:
-
22V
-
MTTP voltage range:
-
16-60V
-
Maximum input voltage:
-
60V
-
Maximum input current:
-
14A
-
Maximum input short circuit current:
-
20A
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
NONE
-
Controller Type:
-
NONE
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
VDE ,EMC ,CE
-
Warranty:
-
25YEARS
-
Place of Origin:
-
China
-
Brand Name:
-
tsun
-
Model Number:
-
TSOL- ESK400-PB
-
Load Power (W):
-
400w
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
60Hz/50Hz
-
Work Time (h):
-
24 Hours
-
Recommended component power:
-
300-550W
-
Starting voltage:
-
22V
-
MTTP voltage range:
-
16-60V
-
Maximum input voltage:
-
60V
-
Maximum input current:
-
14A
-
Maximum input short circuit current:
-
20A
Our system has passed certificates:
EN 50549-1: 2019, VDE-AR-N 4105: 2018, VDE0126, EN50549，INMETRO, RD1699, G98, CE,
IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3, ETSI EN 301 489-1V2.2.3, ETSI EN 301 489-17 V3.2.4, EN300 328 V2.2.2
It could be sold and used in all Europe market.
Any documents needed
please contact us.
Product Description
Product installation instructions
Specification
|
item
|
value
|
|
Warranty
|
25YEARS
|
|
Place of Origin
|
China
|
|
Brand Name
|
tsun
|
|
Model Number
|
TSOL- ESK400-PB
|
|
Application
|
Home
|
|
Solar Panel Type
|
Monocrystalline Silicon
|
|
Mounting Type
|
Ground Mounting
|
|
Load Power (W)
|
400w
|
|
Output Voltage (V)
|
220v
|
|
Output Frequency
|
60Hz/50Hz
|
|
Work Time (h)
|
24 Hours
|
|
Certificate
|
VDE ,EMC ,CE
|
|
Pre-sales project design
|
Y
|
|
Recommended module power
|
300-550W
|
|
Start-up voltage
|
22V
|
|
MTTP voltage range
|
16-60V
|
|
Maximum input voltage
|
60V
|
|
Maximum input current
|
14A
|
|
Maximum input short-circuit current
|
20A
|
product application
Our Factory
Certifications
Payment Terms
FAQ
1. Can you supply sample for testing?
Yes, but if it is for personal use, then we recommend customers to buy locally because shipping is not cost-effective.
2. What certificate do you have ?
EN 50549-1: 2019, VDE-AR-N 4105: 2018, VDE0126, EN50549，INMETRO, RD1699, G98, CE, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3, ETSI EN 301 489-1V2.2.3, ETSI EN 301 489-17 V3.2.4, EN300 328 V2.2.2
3. Do you support OEM?
Yes, we can put your brand on the product.
4. How long you can ship goods after payment?
Sample 1 week
Bulk order 25 days
Yes, but if it is for personal use, then we recommend customers to buy locally because shipping is not cost-effective.
2. What certificate do you have ?
EN 50549-1: 2019, VDE-AR-N 4105: 2018, VDE0126, EN50549，INMETRO, RD1699, G98, CE, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3, ETSI EN 301 489-1V2.2.3, ETSI EN 301 489-17 V3.2.4, EN300 328 V2.2.2
3. Do you support OEM?
Yes, we can put your brand on the product.
4. How long you can ship goods after payment?
Sample 1 week
Bulk order 25 days
