Quick Details
-
Model Number:
-
S2700-26TP-PWR-EI, S2700-26TP-PWR-EI
-
Place of Origin:
-
Beijing, China, Beijing, China
-
Forwarding Performance:
-
2.7 Mpps/5.4 Mpps/6.6 Mpps/13.2 Mpps
-
Port Descriptions:
-
8/16/24/48 x 10/100 Base-TX 2/4 x GE ports
-
Switching Capacity:
-
32 Gbit/s
-
IPv4 routing:
-
Static routing RIP v1/v2 (S2750-EI)
-
Power Consumption:
-
< 12.8W
-
Surge Protection:
-
Surge protection capability of service ports: 7 kV
-
Certification:
-
FCC,ce
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
32Gbps
-
Model Number:
-
S2700-26TP-PWR-EI, S2700-26TP-PWR-EI
-
Place of Origin:
-
Beijing, China, Beijing, China
-
Forwarding Performance:
-
2.7 Mpps/5.4 Mpps/6.6 Mpps/13.2 Mpps
-
Port Descriptions:
-
8/16/24/48 x 10/100 Base-TX 2/4 x GE ports
-
Switching Capacity:
-
32 Gbit/s
-
IPv4 routing:
-
Static routing RIP v1/v2 (S2750-EI)
-
Power Consumption:
-
< 12.8W
-
Surge Protection:
-
Surge protection capability of service ports: 7 kV
-
Certification:
-
FCC,ce
Details Images
Product Description
We will test all the switches before shipping. All the switches are new and original
If you have Any Questions,
CLICK ME!!!
|
|
24 Port Ethernet Poe Wireless Network Switch S2700-26TP-PWR-EI with cheaper price
|
|
Switching Capacity
|
32 Gbit/s
|
|
Forwarding Performance
|
6.6 mpps
|
|
Fixed Ports
|
Downlink: 24 x 100M ports, supporting PoE+
Uplink: Two combo ports (10/100/1000 BASE-T + 100/1000 BASE-X) |
|
MAC Address Table
|
8K MAC address entries
Deletion of dynamic MAC address entries Configurable aging time of MAC addresses MAC address learning control based on ports Blackhole MAC address entries |
|
VLAN Features
|
4K VLANs, complying with IEEE 802.1Q
Port-based VLAN assignment MAC address-based assignment Port-based QinQ |
|
IP Router
|
Static routing
|
|
Interoperability
|
VLAN-based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
Link-type Negotiation Protocol (LNP) (similar to DTP) VLAN Central Management Protocol (VCMP) (similar to VTP) |
24 Port Ethernet Poe Wireless Network Switch S2700-26TP-PWR-EI with cheaper price
Highly scalable, energy-efficient 100 Mbit/s access switches for enterprise campus networks.
Cutting-edge switching technologies combined with Versatile Routing Platform (VRP) software and comprehensive built-in security features make the S2700 Series Switches ideal for building and expanding next-generation IT networks.
The S2700 utilizes cutting-edge switching technologies and Versatile Routing Platform (VRP) software to meet the demand for multi-service provisioning and access on Ethernet networks. It is easy to install and maintain. With its flexible network deployment, comprehensive security and quality of service (QoS) policies, and energy-saving technologies, the S2700 helps enterprise customers build next-generation IT networks. The S2700 is a box device that is 1 U (44.45 mm or 1.75 in.) high. It is available in a standard version (SI) or an enhanced version (EI).
Cutting-edge switching technologies combined with Versatile Routing Platform (VRP) software and comprehensive built-in security features make the S2700 Series Switches ideal for building and expanding next-generation IT networks.
The S2700 utilizes cutting-edge switching technologies and Versatile Routing Platform (VRP) software to meet the demand for multi-service provisioning and access on Ethernet networks. It is easy to install and maintain. With its flexible network deployment, comprehensive security and quality of service (QoS) policies, and energy-saving technologies, the S2700 helps enterprise customers build next-generation IT networks. The S2700 is a box device that is 1 U (44.45 mm or 1.75 in.) high. It is available in a standard version (SI) or an enhanced version (EI).
Product Selling Points
Diverse Port Types
100M/1000M ports and multiple types of access ports.
Intelligent Stack
Intelligent Stack (iStack) enables unified configuration and management, improving reliability and scalability while reducing
Operations and Maintenance (O&M) costs.
Operations and Maintenance (O&M) costs.
Noise-Free and Energy-Saving
An energy-saving mode for ports and a fan-free design eliminate device noise and lower power consumption.
