Quick Details
-
MF:
-
SI
-
EINECS No.:
-
000000
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Anhui Zinca Silicone Oil Technologies Co.,Ltd.
-
Model Number:
-
ZC-274/704
-
Color:
-
Colorless
Quick Details
-
CAS No.:
-
3982-82-9
-
Purity:
-
99
-
Other Names:
-
Tetramethyl Tetraphenyl Trisiloxane
-
MF:
-
SI
-
EINECS No.:
-
000000
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Anhui Zinca Silicone Oil Technologies Co.,Ltd.
-
Model Number:
-
ZC-274/704
-
Color:
-
Colorless
High Performance Tetramethyl Tetraphenyl Trisiloxane Diffusion pump oil
Synonyms:
1. 1,1,5,5-Tetraphenyl-1,3,3,5-tetramethyltrisiloxane
2. 704 silicone diffusion pump Fluid
3. 704 diffusion pump fluid
4. Oil for diffusion pumps
CAS No: 3982-82-9
Product Description:
Chemical Name: Tetramethyl tetraphenyl trisiloxane
Diffusion Pump Oil ZC-274 is a colorless transparent oily, single-component fluid designed for high vacuum of 10-7torr (untrapped). It performs well in tough, rugged applications and offers quick pump down, even after exposure to air at operating temperatures. IOTA704 is thermally and chemically stable allowing it to keep pump jets free of tars and hard carbon.
Chemical structure:
Product Specification:
| Technical index | Unit | Parameters |
| Ultimate Vacuum,torr(untrapped) | 10-7~10-8 | |
| Saturated Vapor Pressure,torr | 5*10-8 | |
| Viscosity(25℃) | cst | 38±3 |
| Specific gravity |
1.06-1.07 |
|
| Refractive index(25℃) | 1.55-1.56 | |
| Flash point(Closed cup) | ℃,≥ | 210 |
| Congealing point | ℃ | -35 |
| Molecular Description | 484 |
Application:
Electrical and electronics industry
• TV tubes, fluorescent tubes, cathode ray tubes
• ordinary bulbs
• capacitors
• rectifier metallised film vacuum system
Optical industry
• surface improvements
• anti reflective coatings
• optical filters and mirrors
Metallurgy industr
y
• high-vacuum furnaces
• melting, degassing and sintering refractory metals; thick-film deposition
Plastics industry
• surface improvements
• mirror coatings
• protective coatings
• film coatings
Other industries
• processing metals and fuels
• accelerators
• molecular plants
• R & D plants
• mass spectrometry
Others
Be used as transmission fluid in high-temperature carriers and various instruments.
Product packing:
1. Available in 1kg plastic bottles,1gallon plastic drums,5kg plastic drums,25kg plastic drums, 25kg Iron drums or 200kg Iron drums.
2 . Transport as non-hazardous chemicals, keeping away from rain and sunlight.
3. Shelf life: 3 years.
