Quick Details
-
Brand Name:
-
Shanding
-
Fork Length:
-
1750mm
-
Fork Width:
-
800mm
-
Overall Dimensions:
-
80/160/1700
-
Weight (KG):
-
500 kg
-
Product Name:
-
Stacker
-
Type:
-
Pallet Stacker
-
Capacity:
-
500KG
-
Weight:
-
500KG
-
Tire:
-
Polyurethane wheel
-
Fork Size:
-
1750*160*80MM
-
Wheels:
-
6 Wheels
-
After Warranty Service:
-
Video technical support
-
Certification:
-
CE, ISO9001
-
Drive form:
-
electric
Quick Details
-
Min. Lifting Height:
-
15mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong
-
Brand Name:
-
Shanding
-
Fork Length:
-
1750mm
-
Fork Width:
-
800mm
-
Overall Dimensions:
-
80/160/1700
-
Weight (KG):
-
500 kg
-
Product Name:
-
Stacker
-
Type:
-
Pallet Stacker
-
Capacity:
-
500KG
-
Weight:
-
500KG
-
Tire:
-
Polyurethane wheel
-
Fork Size:
-
1750*160*80MM
-
Wheels:
-
6 Wheels
-
After Warranty Service:
-
Video technical support
-
Certification:
-
CE, ISO9001
-
Drive form:
-
electric
|
CDD05
|
|
|
|
|||
|
Parameters
|
|
Performance
|
|
|||
|
Product number
|
CDD05
|
Driving speed laden/unladen
|
4/5Km/h
|
|||
|
Drive form
|
electric
|
Max. lifting speed without load
|
100mm/s
|
|||
|
Driving style
|
Walking
|
Max. lifting speed with full load
|
80mm/s
|
|||
|
Rated load
|
500KG
|
Max. gradeability full load/unloaded
|
3/5%
|
|||
|
Wheelbase
|
400mm
|
Braking method
|
Electromagnetic brake
|
|||
|
Weight (including battery)
|
500KG
|
Electric machine
|
|
|||
|
Basic size
|
|
Drive motor power
|
0.8Kw
|
|||
|
Total height (when the fork is lowest)
|
2080/1580/1830/2080/2330mm
|
Increase motor power
|
2.2Kw
|
|||
|
Total height (when the fork is highest)
|
2080/2560/3060/3560/4060mm
|
Battery voltage/capacity
|
1*12V/45Ah
|
|||
|
Lifting height
|
1600/2000/2500/3000/3500mm
|
wheel
|
|
|||
|
Height of forks from the ground (at the lowest time)
|
85mm
|
Tires
|
Polyurethane wheel
|
|||
|
Height of operating handle from the ground
|
1230/750mm
|
Drive wheel size
|
210*70
|
|||
|
Vehicle length
|
1750mm
|
Front wheel size
|
80*70
|
|||
|
Vehicle width
|
800mm
|
Balance wheel size
|
125*50
|
|||
|
Fork size
|
60/535/1150
|
Number of wheels
|
1x+1/4
|
|||
|
Outer width of fork
|
535mm
|
Front track
|
520mm
|
|||
|
Minimum ground clearance
|
30mm
|
Rear track
|
513mm
|
|||
|
Right-angle stacking channel width, pallet 1000*1200
|
2305mm
|
|
|
|||
|
Turning radius
|
1120mm
|
|
|
|||
