Quick Details
-
Model Number:
-
OCr21Al6NbCo
-
Shape:
-
Plate
-
Material:
-
ferroalloy, fecral
-
Chemical Composition:
-
Cr21-23
-
shape:
-
plate
-
Certification:
-
ISO9001
-
width:
-
6-50mm
-
Standard:
-
GB/T 1234-2012
-
thickness:
-
0.56-5mm
-
Certificate:
-
IOS 9001
-
Feature:
-
High Corrosion Resistance
-
Surface Treatment:
-
polished
-
highest temperature:
-
1350℃
Quick Details
-
Application:
-
Industry
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Chunlong
-
Model Number:
-
OCr21Al6NbCo
-
Shape:
-
Plate
-
Material:
-
ferroalloy, fecral
-
Chemical Composition:
-
Cr21-23
-
shape:
-
plate
-
Certification:
-
ISO9001
-
width:
-
6-50mm
-
Standard:
-
GB/T 1234-2012
-
thickness:
-
0.56-5mm
-
Certificate:
-
IOS 9001
-
Feature:
-
High Corrosion Resistance
-
Surface Treatment:
-
polished
-
highest temperature:
-
1350℃
Product Description
|
Grade
|
0Cr21Al6Nb
|
|
Size
|
thickness:0.05-3mm
width:4-250mm
|
|
Surface
|
bright slitting
|
|
Weight
|
5-200kg/roll ,according customers' quantity
|
|
Resistivity
|
1.42±0.05μΩ.m
|
|
Hardness(HV）
|
200-240HV
|
|
Elongation
|
≥12%
|
Product Paramenters
|
Grade
|
Highest temperature
|
Resistivity
|
Hardness
|
Tensile strength
|
Elongation
|
|
0Cr13Al4
|
1050℃
|
1.25±0.05μΩ.m
|
180-210HV
|
≥550N/mm
2
|
≥16
|
|
0Cr15Al5
|
1100℃
|
1.3±0.05μΩ.m
|
180-210HV
|
≥550N/mm2
|
≥16
|
|
0Cr21Al6Nb
|
1300℃
|
1.42±0.05μΩ.m
|
200-240HV
|
750N/mm2
|
≥12
|
|
Cr20Ni80
|
1200℃
|
1.09±0.05μΩ.m
|
180-220HV
|
750N/mm2
|
≥20
|
|
Cr15Ni60
|
1150℃
|
1.12±0.05μΩ.m
|
175-210HV
|
750N/mm2
|
≥20
|
|
Cr20Ni35
|
1100℃
|
1.04±0.05μΩ.m
|
180-220HV
|
750N/mm2
|
≥20
|
|
Cr25Ni20
|
1100℃
|
0.86±0.05μΩ.m
|
180-220HV
|
750N/mm2
|
≥20
|
|
Grade
|
Chemical composition%
|
|
|
|
|
|
|
|
|
||||||||
|
|
C
|
P
|
S
|
Mn
|
Si
|
Cr
|
Ni
|
Al
|
Fe
|
||||||||
|
|
≤
|
|
|
|
|
|
|
|
|
||||||||
|
0Cr15Al5
|
0.04
|
0.02
|
0.01
|
0.3
|
≤0.5
|
13-14
|
＜1
|
4.8-5.0
|
balance
|
||||||||
|
0Cr21Al6Nb
|
0.05
|
0.025
|
0.02
|
0.5
|
≤0.6
|
21-23
|
≤0.6
|
5-7
|
balance
|
||||||||
|
0Cr13Al4
|
0.04
|
0.02
|
0.01
|
0.3
|
≤0.5
|
13-14
|
＜1
|
4.8-5.0
|
balance
|
||||||||
|
Cr20Ni80
|
0.08
|
0.02
|
0.015
|
0.6
|
0.75-1.6
|
20-23
|
balance
|
＜0.5
|
≤1.0
|
||||||||
|
Cr15Ni60
|
0.08
|
0.02
|
0.015
|
0.6
|
0.75-1.6
|
15-18
|
55-61
|
＜0.5
|
balance
|
||||||||
|
Cr20Ni35
|
0.08
|
0.02
|
0.015
|
1.0
|
1-3
|
18-21
|
34-37
|
－
|
balance
|
||||||||
|
Cr25Ni20
|
0.08
|
0.045
|
0.03
|
2.0
|
0.4-0.6
|
24-26
|
19-22
|
－
|
balance
|
||||||||
Recommend Products
Our main products include Iron chromium aluminum,nickel chromium two series products.Various types and specifications of resistance heatingwire,resistance strip products are widely used in industrial furnace,civil electrical appliances,rail transit braking resistor,central grounding resistance,automobile exhaust purification honeycomb carrier and other fields.
