Quick Details
-
Packaging Type:
-
Vacuum Package, Carton Box.
-
Application:
-
Smart Industry, Smart Agriculture
-
Type:
-
Camera Module
-
Series:
-
USB Camera Module
-
Features:
-
IMX290 Sensor Camera Module
-
Mounting Type:
-
USB3.0
-
Description:
-
Sony IMX290 Sensor Camera Module
-
Sensor Size:
-
1/2.8 inch
-
Sensor Model:
-
IMX290
-
Module Size:
-
38mm*38mm (±1mm)
-
Object distance:
-
1CM~Infinity
-
Temperature (Operation):
-
-20°C to 70°C
-
Temperature (Stable Image):
-
0°C to 50°C
-
Drive-free agreement:
-
USB Video Class(UVC)
-
Output format:
-
MJPG / YUY2
-
Minimum illumination:
-
0.0001 LUX
-
Interface:
-
USB3.0 Type A female terminal
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SincereFirst
-
Model Number:
-
SF2A103-3.0 USB3.0
-
Packaging Type:
-
Vacuum Package, Carton Box.
-
Application:
-
Smart Industry, Smart Agriculture
-
Type:
-
Camera Module
-
Series:
-
USB Camera Module
-
Features:
-
IMX290 Sensor Camera Module
-
Mounting Type:
-
USB3.0
-
Description:
-
Sony IMX290 Sensor Camera Module
-
Sensor Size:
-
1/2.8 inch
-
Sensor Model:
-
IMX290
-
Module Size:
-
38mm*38mm (±1mm)
-
Object distance:
-
1CM~Infinity
-
Temperature (Operation):
-
-20°C to 70°C
-
Temperature (Stable Image):
-
0°C to 50°C
-
Drive-free agreement:
-
USB Video Class(UVC)
-
Output format:
-
MJPG / YUY2
-
Minimum illumination:
-
0.0001 LUX
-
Interface:
-
USB3.0 Type A female terminal
|
Sensor:
|
IMX290
|
Pixels:
|
2MP
|
|||
|
Module Size:
|
38mm × 38mm
|
Sensor Size:
|
1/2.8"
|
|||
|
Pixel Size:
|
2.9μm X 2.9μm
|
Interface:
|
USB3.0
|
|||
|
Object Distance:
|
1CM~∞
|
Drive-free Agreement:
|
USB Video Class（UVC）
|
|||
|
SF2A103-3.0 USB3.0 IMX290 Description:
The IMX290LQR-C is a diagonal 6.46 mm (Type 1/2.8) CMOS active pixel type solid-state image sensor with a square pixel array and 2.13 M effective pixels. This chip operates with analog 2.9 V, digital 1.2 V, and interface 1.8 V triple power supply, and has low power consumption. High sensitivity, low dark current and no smear are achieved through the adoption of R, G and B primary color mosaic filters. This chip features an electronic shutter with variable charge-integration time. SF2A103-3.0 USB3.0 IMX290 Features: ◆CMOS active pixel type dots ◆Built-in timing adjustment circuit, H/V driver and serial communication circuit ◆Input frequency: 74.25 MHz / 37.125 MHz ◆Number of recommended recording pixels: 1920 (H) × 1080 (V) approx. 2.07M pixel ◆Readout mode All -pixel scan mode 720p-HD readout mode Window cropping mode Vertical / Horizontal direction-normal / inverted readout mode ◆Readout rate Maximum frame rate in Full HD 1080p mode: 120 frame / s ◆Wide dynamic range (WDR) function Multiple exposure WDR Digital overlap WDR ◆Variable-speed shutter function (resolution 1H units) ◆10-bit / 12-bit A/D converter ◆Conversion gain switching (HCG Mode / LCG Mode) ◆CDS / PGA function 0 dB to 30 dB: Analog Gain 30 dB (step pitch 0.3 dB) 30.3 dB to 72 dB: Analog Gain 30 dB + Digital Gain 0.3 to 42 dB (step pitch 0.3 dB) ◆Supports I/O switching CMOS logic parallel SDR output Low voltage LVDS (150 m Vp-p) serial ( 2 ch / 4 ch / 8ch switching) DDR output CSI-2 serial data output ( 2 Lane / 4 Lane, RAW10 / RAW12 output) ◆Recommended exit pupil distance: –30 mm to –∞ Endoscope Camera Module, Medical Endoscope Camera Module, WIFI Endoscope Camera Module, Mini Endoscope Camera Module, Smallest Endoscope Camera Module A medical endoscope is a medical instrument that can be inserted into the human body cavity and visceral cavity for direct observation and diagnosis. It includes image sensors, o ptical lenses, light source lighting, mechanical devices and other components. It's imaging mainly relies on the camera module of the front-end device, and this part of the module that obtains the image is generally called the endoscope camera module. We can provide endoscope camera module with diameter of 0.9mm~8.0mm and can be equipped with wide-angle lens and telephoto lens, which are convenient for observing objects at close distances. Endoscope Camera Module Application Areas Endoscope Camera Module, Medical Endoscope Camera Module, Industrial Endoscope Camera Module, Usb Endoscope Camera Module, Camera Module For Endoscope, Pipe Repair Drain Inspection Car Inspection, Medical Inspection Dental Checkups, Imaging And Vision Solutions, Integrated Complex And Customized Technology, Machine Vision, Intelligent Systems, Future Security, Optical Technology Solutions, Camera Module Customized Solutions, Internet Of Things End-to-end Solution, Iris Recognition Technology, VR High End Camera Solutions Face Recognition, Specially Designed For Small Uav, Airborne Camera Modules, UAV Solutions, UAV Special Modules, Drone Solutions, Aerial Filming Solutions, Optical Technology Solutions, Mobile Phone Camera Module, Camera Solutions, Optronics Solutions, Imaging Technology Solutions, Video Technology Solutions, Optoelectonic Research, Infrared Imagers For Industry, Embedded Systems Solutionintelligent Hardware Solutions, Professional Camera Modules, Iris Solutions Main Developmet Board, Graphics Processing Unit, System Adaption Main Developmet Board: Arduino, ESP32, Raspberry Pi, NVIDIA Graphics Processing Unit: Ambarella, Rockchip, MediaTek, Qualcomm, NVIDIA, ATI System Adaption: Self-developed Software, Android, Window, MAC-IOS
1 year Replacement!! 10 Years Warranty!!
|
|
|
|
|||
Q1: Are you factory or trade company?
A1: We are factory and have our own production line with 10 levels of dust-free workshops professional trained production workers.
Q2:What is your production capacity?
A2:Usually about 350,000 pieces per month.
Q3:Could you offer OEM&ODM service?
A3:Yes, we are able to provide OEM&ODM service. Supports comprehensive customization of camera modules, including the customization of the FPC length, module shape, connector, pin out, imaging directions, module size, lens, etc.
Q4:Do you have any MOQ limit?
A4:No MOQ, small quantity order is also welcome.
Q5:Do you guarantee the quality of products?
A5:We offer 10 years warranty service and introduced complete quality management system as well as rigorous technical standards.
Q6:What certificate your products have?
A6:CE, FCC, RoHS, REACH, ISO
Q7:What shipping ways do you have?
A7:We could ship the goods by DHL, UPS, Fedex, Air Mail.
Q8:Whats is the payment terms?
A8:T/T, PayPal, Western Union, L/C, MoneyGram, Ablibaba trade assurance.
