1310nm 20km/40km Fiber Optic Media Converter SFP Media Converter 10/100/1000M

1310nm 20km/40km Fiber Optic Media Converter SFP Media Converter 10/100/1000M

1310nm 20km/40km Fiber Optic Media Converter SFP Media Converter 10/100/1000M

Features

• Support Jumbo Frame
• Transparent Transport and very low delay
• Support DMI function for SFP+ fiber module
• Support Loopback test function
• Support hot plugging
• Full State Led display
• Easy installation
• Provide reliable long-distance connection
• Fast connection with multi-function
• Small portable size case
• Plug and play

Application

• Connection between fiber to copper 10Gbps Ethernet equipment function as fiber-to-copper media converter for long distance transmission up to 120km
• Extend the network distance between two 10 Gigabit Fiber Switches across a fiber link up to 80km in length
• Convert your 10G SFP+ Direct Attach to multimode or single mode fiber.

Technical Parameters for 10/100/1000M Adaptive Fast Ethernet Optical Media Converter
Number of Network Ports	1 channel
Number of Optical Ports	1 channel
NIC Transmission Rate	10/100/1000Mbit/s
NIC Transmission Mode	10/100/1000M adaptive with support for automatic inversion of MDI/MDIX
Optical Port Transmission Rate	1000Mbit/s
Operating Voltage	AC 100-220V or DC +5V
Overall Power	<3W
Network Ports	RJ45 port
Optical Specifications	Optical Port:  LC (Optional) Multi-Mode: 50/125, 62.5/125um    Single-Mode: 8.3/125, 8.7/125um, 8/125,10/125um Wavelength: Single-Mode: 1310/1550nm
Data Channel	IEEE802.3x and collision base backpressure supported Working Mode:  Full/half duplex supported     Transmission Rate: 1000Mbit/s with error rate of zero
