trade show array dj booth aluminum roof bolt spigot 300mm square truss

trade show array dj booth aluminum roof bolt spigot 300mm square truss

FOB Reference Price: Get Latest Price

≥4 Sets

US $800

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Material of curved truss:: Aluminum 6082-T6

Color:: silver

truss size:: 7x4m

truss section size:: 290x290mm

main tube:: 50x3mm

Brace tube:: Diameter 25*2mm / 20*2mm

circular truss size:: OD 5M

stage load capacity:: 750kg/m2

truss load catacity:: 60kg/m

Advantages:: light weight and large load

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: XY

Model Number:: X-TRUSS

Material of curved truss:: Aluminum 6082-T6

Color:: silver

truss size:: 7x4m

truss section size:: 290x290mm

main tube:: 50x3mm

Brace tube:: Diameter 25*2mm / 20*2mm

circular truss size:: OD 5M

stage load capacity:: 750kg/m2

truss load catacity:: 60kg/m

Advantages:: light weight and large load

Specification

wedding truss Information
Width	6-12m
Height	5-8m
truss section size	290x290mm / 350mmx350mm/400x400mm
Material	Aluminum 6082-T6
Truss color	silver/Yellow/white/blue
Loading	2000kg

X-LED-07.

This LED frame is an easy and fast assembly system,that can equip LED screen of 8x6m (26.2x19.7ft) with maximum weight of 3500kg (6615lbs).

The LED frame is built up from FT44 and TT74 trussingsegments and the max.lifting hewight is ca.8.6m (28ft)

Product Description

Square truss

Material:alloy 6082-T6

Size:290x290mm,350x350mm,400x400mm and so on.

Lenght:0.5-4m

Main tube 50x3mm, 50x4mm,50x2mm

bracing tube :30x2mm/25x2mm/20*2mm...

It adopts 400*400 specification truss, high load-bearing, light and fast construction, economical and durable. Used in weddings, company celebrations.

Triangle truss

Material:alloy 6082-T6
Size:290x290mm,350x350mm,400x400mm and so on.
Lenght:0.5-4m
Main tube 50x3mm, 50x4mm,50x2mm
bracing tube :30x2mm/25x2mm/20*2mm...

Ladder truss.

Material:alloy 6082-T6
Size:290x290mm,350x350mm,400x400mm and so on.
Lenght:0.5-4m
Main tube 50x3mm, 50x4mm,50x2mm
bracing tube :30x2mm/25x2mm/20*2mm...

LED SCREEN DESIGN

X-LED-04

Size:8X6M

Load:2000kg

X-LED-03

Size:6x5m

Load:2000kg

X-LED-05

Size:6x8m

Load:2000kg

X-LED-02

Size:3x3m

Load:2000kg

Roof truss show.

This Roof truss is an arch roof system designed to cover Large Stage , It`s attractive look is great for middle or large size events such as concerts,fashion and entertainment shows ,theatrical performances and many others.However,it`s design can allow big loads to be placed on the structrue.

ARCH ROOF TRUSS.

This Roof is an arch roof system designed to cover stage 8x6m (26x19.5ft).Its attractive look is great for small to middle size events such as concerts.
