more convenient
to be assembled
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
HY-32100
-
Battery Size:
-
lifepo4 cell 3.2V
-
Weight:
-
1.96kg, 1.96±0.05kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
1c
-
Electric Energy:
-
320 Wh
-
Brand:
-
HY-CATL
-
Battery Type:
-
lifepo4
-
Capacity:
-
100ah 142ah 152ah 177ah 202ah 304ah 560ah
-
Voltage:
-
3.2V
-
Dimension:
-
T50*W160*H118mm
-
Cycle life:
-
4000 Times
-
Warranty:
-
5 years
Quick Details
-
Anode Material:
-
LFP
-
Application:
-
Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
HY-CATL
-
Model Number:
-
HY-32100
-
Battery Size:
-
lifepo4 cell 3.2V
-
Weight:
-
1.96kg, 1.96±0.05kg
-
The charging ratio:
-
1c
-
The discharge rate:
-
1c
-
Electric Energy:
-
320 Wh
-
Brand:
-
HY-CATL
-
Battery Type:
-
lifepo4
-
Capacity:
-
100ah 142ah 152ah 177ah 202ah 304ah 560ah
-
Voltage:
-
3.2V
-
Dimension:
-
T50*W160*H118mm
-
Cycle life:
-
4000 Times
-
Warranty:
-
5 years
Products Description
EV CATL100AH lifepo4 Battery Cell 100ah 280Ah 6000 Cycle 3.2V Rechargeable Battery energy storage lifepo4 280ah battery
|
attery type：
|
Lifepo4
|
|
Nominal Voltage(V)：
|
3.2v
|
|
Nominal Capacity(mAh)：
|
100AH
|
|
Charge Voltage：
|
3.65 V
|
|
Discharge cut-off voltage：
|
2.5v/cell
|
|
1Max charge current：
|
1C
|
|
Max discharge current：
|
1C
|
|
Internal resistance：
|
less than 0.28mΩ( ±0.05mΩ)
|
|
Charge Temperature(℃)：
|
0~45Centigrade
|
|
Discharge Temperature(℃)：
|
-20~55Centigrade
|
|
Storage Temperature(℃)：
|
-20~45Centigrade
|
|
Cycle life：
|
More than 4000 times
|
|
Weight(g)：
|
1.96Kg
|
|
Size(mm)：
|
50x160x118（mm）
|
Various Capacity Options
Free busbars and studs,
Cycle Life
*
Cycle Life more than
4000
times
If you want to know more technical performance details
Please click on the "contact supplier" or "Chat Now"and send us a message,
We will provide you with specifications
match by voltage and IR
*
IR less than 0.28m
Ω（
±0.05mΩ
)
all cells will be match by voltage and IR by our
engineer
ensure nice consistency before shipment
Shipping and Package
●Thick Foam
protectthe safety of cells.
●Single box with corner protector
Single box with corner protector Strengthen the safety of box with waterproof tape and corner protector.
● Pallet Delivery
Normally Cells over a certain amount,we suggest delivery in pallet,assemble the boxes is convenient for deliver to avoid box loss.
What will we do before delivery?
Starmax shipping standard of our factory!!!!
1.We will ensure the consistency of each cell before delivery.Check the appearance of battery,no leakage and swell,ensure that it is relatively flat.
2.The voltage difference of each battery within 10 millivolts and the internal resistance within 0.1 milliohms.
3.The capacity difference within 1Ah.
4.We provide 3 days delivery and 5 years warranty.
Shipping Time
2.By Air to Europe or America,10-15 days around.
3.By Express to Europe or America,7 days around.
4.we also can ship to your agent warehouse.
3.By Express to Europe or America,7 days around.
4.we also can ship to your agent warehouse.
5.Safe and stable channel logistics company cooperation.
Notice:
*The tracking will be update after pick up by local express. Please wait patiently or contact us for help.
*Countries that do not appear in the table, Please click here to consult us for freight charges.
Why Choose Us
Why Starmax is your BEST Partner?
1.Your Expert For Power Solution：
With 10 years of battery industry experience, Starmax have been served more than 6000+ customers from 68 countries. Keep more than 90% repurchase rate & 99% on-time delivery rate & 95% good feedbacks rated by alibaba proved.
2.Source Factory & Direct Distributor：
All of battery 100% original Grade A & Brand New.
Weekly Fresh Date Stocks, New produced cell.
Keep Long-term supply for your project，Don't worry about stocks problem.
Keep Long-term supply for your project，Don't worry about stocks problem.
3.Quality Assurance：
100% tested guaranteed. The battery will be tested strictly before shipment.
Match IR and Volt ensure aood consistence.
Welcome QC checking,On-line video checking before shipping.
100% technical support & 100% after-sales service.
Support fully refund if used cell or bad quality cell received from us!
Welcome QC checking,On-line video checking before shipping.
100% technical support & 100% after-sales service.
Support fully refund if used cell or bad quality cell received from us!
4.Customer Service 24 hours &7 days：
Professional pre&post-sale service system will provide tailored solutions for your needs.
About Starmax
Shenzhen Starmax Energy Technology Co., Ltd
is specialized in rechargeable battery for over 10 years. With advanced equipment and technology,we can provide wide range of qualified lithium ion battery, lithium-ion polymer battery, and energy storage battery etc.
Our factory is assessed, certified, authenticated and inspected by SGS Group.
Do long-term business and reliable battery supplier.
All of our batteries
passed UL CE, ROHS, CB UN38.3,MSDS,IEC
and
other international certifications
.Safety, light weight and longer use life is battery features.
The battery widely used in Golf Carts, Boats, E-car, Electric Bicycles/scooters,Unmanned Aircraft and Solar Energy Storage Systems. We'd like to build a win-win business and bring a wonderful future for you and your business.
The battery widely used in Golf Carts, Boats, E-car, Electric Bicycles/scooters,Unmanned Aircraft and Solar Energy Storage Systems. We'd like to build a win-win business and bring a wonderful future for you and your business.
●
CAPACITY
We are able to meet large-scale order requirements, providing timely supply and transportation services.
● QUALITY
Through a series of inspections and tests, we ensure the consistency and excellent quality of every batch of batteries, providing high-quality products to our partners in most countries worldwide.
Quality Assurance
Matters Needing Attention
Please use the battery
correctly in strict
accordance with the following requirements,otherwise it is
not covered by the warranty
1.When charging and discharging the battery, ensure that the conditions for monitoring and protecting the battery voltage,current and temperature are available.
2.Please keep the battery away from heat source, ignition source and other heating and corrosive environments such as strong acid and alkali.
3.Do not short circuit the battery or install it with incorrect polarity at any time.
4.Do not mix batteries of different models or manufacturers.
5.Do not use external force to drop, impact or puncture the battery. Do not disassemble the battery or change the external structure.
6.When the battery is not used for a long time, please keep the battery charge at 30%~50% SOC, and avoid direct sunlight or high temperature and humidity.
7.When operating the battery, it is necessary to wear protective devices such as rubber gloves.
6.When the battery is not used for a long time, please keep the battery charge at 30%~50% SOC, and avoid direct sunlight or high temperature and humidity.
7.When operating the battery, it is necessary to wear protective devices such as rubber gloves.
8.If the battery leaks, smokes or is damaged, please stop using it immediately.
9.Do not charge below zero centigrade
Kindly Reminder
1. DIY battery pack must get the cells balanced (same voltage ) before assembly. Later if there happens don't know how to assembled or wrong assembly is not accepted refund.
2. Professionals will detected voltage/resistance/appearance and other issues before every shipment, we can only ensure that the single battery is good, when arrival you can test the cells within 15 days,after that means batteries have no problem, does not provide return nor refund.
3. If you found problems you can contact us for return or refund. Battery can only be unused (the electrode intact, no welding, no wear, the appearance good) to provide return. Any return behavior buyers need to be responsible for shipping fee.
3. If you found problems you can contact us for return or refund. Battery can only be unused (the electrode intact, no welding, no wear, the appearance good) to provide return. Any return behavior buyers need to be responsible for shipping fee.
