Quick Details
-
Catv amplifier brand:
-
SOFTEL/OEM
-
Catv amplifier application:
-
CATV
-
Catv amplifier power:
-
15±VDC
-
Frequency range:
-
950-2300MHz
-
DC power passing:
-
500mA(max.)
-
Gain:
-
10-20dB
-
Material:
-
Zinc die-cast housing
-
lead time:
-
7 days
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SOFTEL/OEM
-
Model Number:
-
In line amplifier, catv signal amplifier/catv line extender
-
Catv amplifier brand:
-
SOFTEL/OEM
-
Catv amplifier application:
-
CATV
-
Catv amplifier power:
-
15±VDC
-
Frequency range:
-
950-2300MHz
-
DC power passing:
-
500mA(max.)
-
Gain:
-
10-20dB
-
Material:
-
Zinc die-cast housing
-
lead time:
-
7 days
Product Description
Specification
|
Frequency range (MHz)
|
950-2400
|
|
Gain (dB)
|
20±2
|
|
Flatness (dB)
|
±1
|
|
Max. output (dBμV)
|
115
|
|
Noise figure (dB)
|
≤4.0
|
|
Return loss (dB)
|
≥10
|
|
Power supply (V)
|
DC12-18
|
|
Power consumption (W)
|
≤1.0
|
Features
Design for in-line boosting SAT IF
Powerd by the receiver via coaxial cable
Model with slope gain can equilibrate cable loss
Low intermodulation distortion
Zinc die-cast housing with nickel plated
Low noise circuit design
Special design for LNB output signal amplification
75Ω, British system F-type connector
Max. passing current 0.5A
Powerd by the receiver via coaxial cable
Model with slope gain can equilibrate cable loss
Low intermodulation distortion
Zinc die-cast housing with nickel plated
Low noise circuit design
Special design for LNB output signal amplification
75Ω, British system F-type connector
Max. passing current 0.5A
Specifications
1).Input Frequency: 950~2400MHz
2).Insertion Gain: 20dB
3).Return Loss: 10dB
4).Output: 105dBuV
5).Power supply: 12~20V/DC
6).DC current consumption: 30mA
7).Max DC current to LNB: 500mA
8).Input/Output connector: 75ohm
9).Temperature: -10~+50degree
2).Insertion Gain: 20dB
3).Return Loss: 10dB
4).Output: 105dBuV
5).Power supply: 12~20V/DC
6).DC current consumption: 30mA
7).Max DC current to LNB: 500mA
8).Input/Output connector: 75ohm
9).Temperature: -10~+50degree
