- Product Details
- {{item.text}}
Quick Details
-
Commodity:
-
Flexible pvc 3 inch 4 inch fire hose 6 inches
-
Material:
-
PVC/RUBBER/TPU
-
W.P:
-
max.50bar
-
B.P:
-
max.150bar
-
Lengh:
-
10m - 30m
-
Burst pressure:
-
15 to 60bar
-
Application:
-
Conveying water, Fire Fighting etc
-
Inner Diameter:
-
26-308 mm
-
Main scope:
-
fire fighting
-
Type:
-
we have pvc,pu ,rubber type
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
SAFETYLIFE
-
Model Number:
-
GB6246-2000
-
Commodity:
-
Flexible pvc 3 inch 4 inch fire hose 6 inches
-
Material:
-
PVC/RUBBER/TPU
-
W.P:
-
max.50bar
-
B.P:
-
max.150bar
-
Lengh:
-
10m - 30m
-
Burst pressure:
-
15 to 60bar
-
Application:
-
Conveying water, Fire Fighting etc
-
Inner Diameter:
-
26-308 mm
-
Main scope:
-
fire fighting
-
Type:
-
we have pvc,pu ,rubber type
Flexible pvc 3 inch 4 inch fire hose 6 inches
Specifications
|
Diameter
|
Working Pressure
|
Testing Pressure
|
Bursting Pressure
|
Length
|
|
(Inch/mm)
|
(MPa/BAR/PSI)
|
(MPa/BAR/PSI)
|
(MPa/BAR/PSI)
|
(M/FEET)
|
|
1 25
|
1.0/10/150
|
|
3.0/30/450
|
10
|
|
1-1/2 40
|
1.3/13/195
|
1.5/15/220
|
3.9/39/580
|
15/50
|
|
2 50
|
1.6/16/240
|
2.0/20/300
|
4.8/48/720
|
20
|
|
2-1/2 65
|
2.0/20/300
|
2.4/24/360
|
6.0/60/900
|
25
|
|
3 80
|
|
3.0/30/450
|
|
30/100
|
Detail Pictures
Diameter :19mm ,25mm,40mm,50mm,65mm,80mm,100mm,125mm,150mm
Working pressure :6bar ,8bar,10bar,13bar,17 bar
Max length :35M
1)PVC/ Rubber/ PU Lining
2)The jacket of fire hose is wove by high intensity of polyester filament or polyester short-fiber( twill/plain weave)
3)There are special adhesive between the jacket and the hose. the hose is soft and highly polished,reduce the flow resistance
4) Thinner and more soft, lighter and more convenient to use.
5) High pressure resistance, low temperature resistance, anti-corrosion. aging resistance.wear-resisting
Working pressure :6bar ,8bar,10bar,13bar,17 bar
Max length :35M
Flexible pvc 3 inch 4 inch fire hose 6 inches
1)PVC/ Rubber/ PU Lining
2)The jacket of fire hose is wove by high intensity of polyester filament or polyester short-fiber( twill/plain weave)
3)There are special adhesive between the jacket and the hose. the hose is soft and highly polished,reduce the flow resistance
4) Thinner and more soft, lighter and more convenient to use.
5) High pressure resistance, low temperature resistance, anti-corrosion. aging resistance.wear-resisting
Shanghai fire hose /canvas fire hose /tpu hose Diameter :19mm ,25mm,40mm,50mm,65mm,80mm,100mm,125mm,150mm
Working pressure :6bar ,8bar,10bar,13bar,17 bar
Max length :35M
Working pressure :6bar ,8bar,10bar,13bar,17 bar
Max length :35M
Product packaging
You have 2 choice for hose packing. Poly Bag and Carton.
Flexible pvc 3 inch 4 inch fire hose 6 inches
Flexible pvc 3 inch 4 inch fire hose 6 inches
1)PVC/ Rubber/ PU Lining
2)The jacket of fire hose is wove by high intensity of polyester filament or polyester short-fiber( twill/plain weave)
3)There are special adhesive between the jacket and the hose. the hose is soft and highly polished,reduce the flow resistance
4) Thinner and more soft, lighter and more convenient to use.
5) High pressure resistance, low temperature resistance, anti-corrosion. aging resistance.wear-resisting
2)The jacket of fire hose is wove by high intensity of polyester filament or polyester short-fiber( twill/plain weave)
3)There are special adhesive between the jacket and the hose. the hose is soft and highly polished,reduce the flow resistance
4) Thinner and more soft, lighter and more convenient to use.
5) High pressure resistance, low temperature resistance, anti-corrosion. aging resistance.wear-resisting
Factory Conor
Our fire extinguisher include ABC&BC dry powder FE,carbon dioxide FE,water&foam FE,automatic and trolley type FE.
Our products cover fire hoses, fire sprinklers, fire coupling and nozzles, fire hydrant, siamese connection, firefighting
equipment and fire alarm valves.
Our company takes technology as our core, regarding quality as the life. We have a strict quality management system to ensure the
product quality. All products have to pass strict inspection before they ship out!
Our products cover fire hoses, fire sprinklers, fire coupling and nozzles, fire hydrant, siamese connection, firefighting
equipment and fire alarm valves.
Our company takes technology as our core, regarding quality as the life. We have a strict quality management system to ensure the
product quality. All products have to pass strict inspection before they ship out!
More Products
Customer Photos
Every year we will take part in exhibitions at home and abroad,Our products have received high evaluation from customers Our customers are distributed in Southeast Asia,Europe and south america .
Customer Feedback
We have many cooperation orders, and have been widely praised by customers. We are dedicated to serve and make every customer satisfied is our aim. We have more in-depth cooperation with our customers because of our service.
Q&A
1.Q: How can I get some samples?
A: We are honored to offer you samples for free.
2. Q: Payment Terms:
A: TT. 30% Deposit, 70% balance against copy B/L.
3. Q: What's your minimum Quantity?
A: 500 pieces/size (Complete fire extinguisher belongs to 2.2class Dangerous Goods, it should be load full container)
4. Q: What's your delivery Time?
A: 10-35 Days
