General introduction STEEL CAMEL M630-60 Agri Farmer Loadall Telehandler:
STEEL CAMEL M630-60
telehandler was designed to be operated on narrow spaces, slippery ground and can handle with heavy workloads.
Its
compact dimensions, incredible manoeuvrability, unparalleled build quality and all-day operator comfort
are just the ideal
machine you are looking for.
As a purpose-built machine to the exact needs of agricultural operators. You can therefore also expect
maximum productivity,
efficiency , safety and serviceability.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
STEEL CAMEL
-
Fork Length:
-
1270mm
-
Fork Width:
-
1120mm
-
Overall Dimensions:
-
3970x2090x2150mm
-
Weight (KG):
-
5700 kg
-
Product Name:
-
Telescopic Handler Forklift
-
Loading Capacity:
-
3000kg
-
Max. Lifting height:
-
6000mm
-
Machine weight:
-
5700kg
-
Engine:
-
Chinese Yunnei/Yanmar/Kohler
-
Engine power:
-
55 kw~74kw
-
Transmission:
-
Hydrostatic 4wd
-
Steering type:
-
4 wheel steering
-
Speed:
-
10/24km/h, variable speed
-
Color:
-
Yellow, white and Customized
Quick Details
-
Min. Lifting Height:
-
123 mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
STEEL CAMEL
-
Fork Length:
-
1270mm
-
Fork Width:
-
1120mm
-
Overall Dimensions:
-
3970x2090x2150mm
-
Weight (KG):
-
5700 kg
-
Product Name:
-
Telescopic Handler Forklift
-
Loading Capacity:
-
3000kg
-
Max. Lifting height:
-
6000mm
-
Machine weight:
-
5700kg
-
Engine:
-
Chinese Yunnei/Yanmar/Kohler
-
Engine power:
-
55 kw~74kw
-
Transmission:
-
Hydrostatic 4wd
-
Steering type:
-
4 wheel steering
-
Speed:
-
10/24km/h, variable speed
-
Color:
-
Yellow, white and Customized
Product Description
China made STEEL CAMEL new telescopic boom forklift M630-60
Specification
|
China Made High Quality 4x4 STEEL CAMEL Telescopic Forklift Telehandler M630-60
|
value
|
|
||
|
Engine
|
Engine brand
|
Chinese Yunnei/Yanmar/EPA 4 Kohler
|
||
|
Place of Origin
|
Rated power
|
55~74kw/75~100hp
|
||
|
|
Engine type
|
Direct injection, water cooled, turbocharged
|
||
|
Brand Name
|
No. of cylinder
|
4 cylinders
|
||
|
Performance
|
Loading capacity
|
3000kg
|
||
|
Min. Lifting Height
|
Max. Lifting height
|
6000mm
|
||
|
Fork Length
|
Operating weight
|
5700kg
|
||
|
Fork Width
|
Speed
|
10/24km/h, variable speed
|
||
|
Dimension
|
Max. length without fork
|
3970mm
|
||
|
Certification
|
Max. width
|
2090mm
|
||
|
Warranty
|
Max. height to top of cabin
|
2150mm
|
||
|
Transmission
|
Transmission type
|
Hydrostatic
|
||
|
Marketing Type
|
Speed
|
10/24km/h, variable speed
|
||
|
Warranty of core components
|
Pump
|
Italy closed variable displacement piston pump
|
||
|
Driving
|
Driving type
|
4 wheel drive
|
||
|
Weight (KG)
|
Truning angel
|
35 degree
|
||
|
Product Name
|
Track
|
1780mm
|
||
|
Loading Capacity
|
Wheelbase
|
2400mm
|
||
|
|
System pressure
|
20Mpa
|
||
|
Machine weight
|
Hydraulic output
|
82L/min
|
||
|
Fork
|
Dimension (LxWxT)
|
1270x1120x45mm
|
||
|
Tyres
|
Type
|
12.5/80-18, tubeless
|
||
