Quick Details
-
Model Number:
-
YW-140
-
Product name:
-
Endress Pressure Transmitter PMC71
-
Output:
-
4-20ma
-
Pressure type:
-
Gauge Pressure Absolute Pressure Sealed Pressure
-
Accuracy:
-
0.5%FS
-
Supply voltage:
-
DC 24V(12V~32V)
-
Protection level:
-
IP 65
-
Usage:
-
Industrial Usage
-
Pressure range:
-
-0.1....0~0.01... ~100MPa
-
Application:
-
Wide application range
-
Quality:
-
High Quality
Quick Details
-
Warranty:
-
2 Years
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
XINYI
-
Model Number:
-
YW-140
-
Product name:
-
Endress Pressure Transmitter PMC71
-
Output:
-
4-20ma
-
Pressure type:
-
Gauge Pressure Absolute Pressure Sealed Pressure
-
Accuracy:
-
0.5%FS
-
Supply voltage:
-
DC 24V(12V~32V)
-
Protection level:
-
IP 65
-
Usage:
-
Industrial Usage
-
Pressure range:
-
-0.1....0~0.01... ~100MPa
-
Application:
-
Wide application range
-
Quality:
-
High Quality
Product Description
Pressure Transmitter
uses HT series piezoresistive silicon oil-filled sensor as the signal measuring element. Signal processing circuit located in the stainless steel housing, can convert sensor signal into standard output signal. All the products through components and semi-finished products test, finished products burn-in screening, are with stable and reliable performance. Have strong anti-interference performance, can working in harsh environment conditions for long term.
Specification:
|
Measurement Range
|
-0.1….0~0.01．．．~100MPa
|
|
Proof pressure
|
≤1.5X rated pressure or 110MPa which ever is less
|
|
Pressure type
|
Gauge, absolute ,sealed gauge
|
|
Accuracy
|
±0.25%（Typical） ±0.5%（Max.）
|
|
Long term stability
|
±0.2%F.S/year
|
|
Operating Temperature Range
|
-20℃~80℃
|
|
Storage Temperature Range
|
-40℃~120℃
|
|
Power supply
|
15～30VDC
|
|
Output signal
|
4～20mA 0～10/20mA 0/1～5VDC
|
|
Pressure port
|
M20×1.5 or customize
|
|
material
|
1Cr18Ni9Ti stainless steel
|
|
Diaphragm material
|
316L
|
|
O-ring
|
Fluororubber
|
|
Electrical housing
|
Cast aluminium alloy(2088housing)
|
|
Insulation resistance
|
100MΩ,100VDC
|
|
Protection
|
IP65
|
Ordering Note
1. Media must compatible with wetted part.
2. To ensure the products can working reliable, we suggest that customer install lightning protection device and make sure products & power are earthed.
3. Special requirement ,such as strong shock, moment vibration, strong electromagnetism, radio frequency interference ,please consult us.
Warranty:
Pressure transmitters have a limited one-year warranty to the original purchaser. We will replace or repair defective products free of charge. This warranty does not apply to any units have been modified, misused, neglected.
