Quick Details
-
Model Number:
-
WB1K
-
Weight:
-
3.5Kg
-
Product name:
-
Uninterruptible Power Supply(UPS)
-
Frequency Range:
-
50/60±6Hz (default), ±10Hz (settable)
-
Battery Type:
-
Lead-acid batteries
-
DC Voltage:
-
24V-96V
-
Slot (optional):
-
SNMP/AS400 Relay Card/RS485
-
EPO (optional):
-
Support emergency shutdown
-
Operating Environment Temperature:
-
0~40℃
-
Storage Temperature:
-
20%~95% (no condensation)
-
Altitude Temperature:
-
-15~60℃ (battery: 0~40℃)
Quick Details
-
Warranty:
-
1years
-
Place of Origin:
-
China
-
Brand Name:
-
WOBO
-
Model Number:
-
WB1K
-
Weight:
-
3.5Kg
-
Product name:
-
Uninterruptible Power Supply(UPS)
-
Frequency Range:
-
50/60±6Hz (default), ±10Hz (settable)
-
Battery Type:
-
Lead-acid batteries
-
DC Voltage:
-
24V-96V
-
Slot (optional):
-
SNMP/AS400 Relay Card/RS485
-
EPO (optional):
-
Support emergency shutdown
-
Operating Environment Temperature:
-
0~40℃
-
Storage Temperature:
-
20%~95% (no condensation)
-
Altitude Temperature:
-
-15~60℃ (battery: 0~40℃)
Uninterruptible Power Supply
Top Quality Ups 3Kva 10Kva Price Router Ups for Laptop
Online UPS
The WB1K-WB3K(S) series are high-frequency online UPS, which can provide a better power environment for the load, no matter from the regulated output range, frequency range, input noise filtering, or even zero conversion between mains mode and battery mode Taking into account time and other aspects, they are all high-quality UPS structures. It provides a complete power protection solution, solving power outages, mains high voltage, mains low voltage, instantaneous voltage drops, reduced amplitude oscillation, high voltage pulses, surge voltages, harmonic distortion, clutter interference, frequency fluctuations, etc. problem, so that the product can be widely used in computer equipment, communication equipment and other control equipment, and specific options can be installed for impact loads to cope with complex industrial environments.
|
Model
|
|
WB1K
|
WB1KS
|
WB2K
|
WB2KS
|
WB3K
|
WB3KS
|
||||||
|
Rated Capacity
|
|
1KVA/1KW
|
|
2KVA/2KW
|
|
3KVA/3KW
|
|
||||||
|
Rated Input Voltage
|
|
208/220/230/240VAC
|
|
|
|
|
|
||||||
|
Voltage Range
|
|
110~300VAC, 110~176VAC, 280~300VAC power limit
|
|
|
|
|
|
||||||
|
Frequency Range
|
|
50/60±6Hz (default), ±10Hz (settable)
|
|
|
|
|
|
||||||
|
Battery Type
|
|
Lead-acid batteries
|
|
|
|
|
|
||||||
|
DC Voltage
|
|
24V
|
36V
|
48V
|
72V
|
72V
|
96V
|
||||||
|
Micro RS-232
|
|
Support Windwos 2000/2003/XP/Vista/2008/7/Linux/Unix and MAC
|
|
|
|
|
|
||||||
|
Slot (optional)
|
|
SNMP/AS400 Relay Card/RS485
|
|
|
|
|
|
||||||
|
EPO (optional)
|
|
Support emergency shutdown
|
|
|
|
|
|
||||||
|
Operating Environment Temperature
|
|
0~40℃
|
|
|
|
|
|
||||||
|
Storage Temperature
|
|
20%~95% (no condensation)
|
|
|
|
|
|
||||||
|
Altitude Temperature
|
|
-15~60℃ (battery: 0~40℃)
|
|
|
|
|
|
||||||
|
Altitude
|
|
The altitude should not exceed 1000m, derating above 1000m, up to 4000m, refer to iec62040
|
|
|
|
|
|
||||||
|
Overall Volume (D×W×H)
|
|
285×143×222
|
|
395×143×222
|
|
455×190×330
|
395×143×222
|
||||||
|
Net Weight (Kg)
|
|
7.5
|
3.5
|
14
|
5.5
|
22
|
5.7
|
||||||
Product Features：
-Adopting double conversion online design, the output waveform is pure sine wave, with zero output conversion time and input power factor correction (PFC) technology.
- Adopt DSP full digital control to improve system stability and reliability.
-Optimize the functional design of the battery pack to reduce battery consumption.
- Strong environmental adaptability, adaptable to harsh power grid environment and generators.
-Comprehensive and reliable protection, with battery undervoltage, short circuit, overcharge, overheating protection, etc.
-Improve load capacity, reduce power loss and pollution to the mains power grid.
-UPS can be monitored and managed through computer or network.
Backup UPS
The automatic voltage-stabilizing UPS designed to optimize the power environment in the domestic market effectively solves 5 types of power problems (mains power outage, voltage sags, surges, undervoltage, and overvoltage) through advanced MCU control and reliable power design. It further improves the adaptability and reliability of the product, providing protection for user equipment and the UPS itself.
|
Model
|
WB650
|
WB1000
|
WB1500
|
WB2000
|
WB3000
|
||||
|
Capacity
|
600VA/360W
|
1000VA/600W
|
1500VA/900W
|
2000VA/1200W
|
3000VA/1800W
|
||||
|
Input Voltage
|
220 VAC or 110V/120 VAC (Can Be Customized)
|
|
|
|
|
||||
|
Input Voltage Range
|
145-275VAC or 81-145VAC
|
|
|
|
|
||||
|
Frequency
|
60/50 Hz (Automatic Recognition)
|
|
|
|
|
||||
|
Output Voltage Range
|
±10%
|
|
|
|
|
||||
|
Frequency Range
|
60/50±1Hz
|
|
|
|
|
||||
|
Conversion Time
|
4-6ms
|
|
|
|
|
||||
|
Wave Battery Mode
|
Simulate Sine Wave
|
|
|
|
|
||||
|
Battery Model And Quantity
|
12V7AH×1
|
12V9AH×1
|
12V7AH×2
|
12V9AH×2
|
12V7AH×4
|
||||
|
Charging Time
|
Restore to 90% Capacity In 8 Hours
|
|
|
|
|
||||
|
Show
|
Mains Mode, Battery Mode, Load Size, Battery Capacity, Input Voltage, Output Voltage, Overload And Low Battery
|
|
|
|
|
||||
|
Humidity And Temperature
|
0-90% Humidity And 0-40℃ Temperature
|
|
|
|
|
||||
|
Size
|
330x100x155
|
330x100x155
|
375x140x170
|
375x140x170
|
395x145x210
|
||||
|
Net Weight(Kg)
|
4.9
|
5.9
|
11
|
12
|
20
|
||||
Product Features：
- Automatic voltage stabilizing output function can effectively filter out all kinds of power interference.
-UPS has reliable performance and can handle various power problems accurately and reliably.
- Independent anti-surge protection socket design
- Automatic startup and self-pickup function, unattended power management, comprehensively improve load safety.
- Provide reliable and stable power output. It can also be used with a generator.
-The automatic charging function effectively protects the battery and extends its service life.
