The product design is strictly audited.
Every process of product production goes through strict checks
Ensure high yields,consistent performance and durability.
100% EL Testing
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
12 Years
-
Model Number:
-
LS166 435-450W HB;LS182 575-590W HB
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2279* 1134 * 35 mm
-
Product name:
-
All Black 450 Watt Solar Home Panels
-
Junction Box:
-
IP68,3 diodes
-
Frame:
-
Anodized Aluminium Alloy
-
weight:
-
27.5kg
-
Front Glass:
-
3.2mm Coated Tempered Glass
-
Solar cell:
-
120;132;144;156
-
Efficiency:
-
19.73%-21.11%
-
Application:
-
Industrial
-
Packing:
-
Carton with pallet
-
Delivery time:
-
15-25days
Quick Details
-
Cell size:
-
166mmx83mm;182mmx91mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, HJT
-
Panel Efficiency:
-
19.73%-21.11%
-
Warranty:
-
12 Years
-
Model Number:
-
LS166 435-450W HB;LS182 575-590W HB
-
Place of Origin:
-
China
-
Panel Dimensions:
-
2279* 1134 * 35 mm
-
Product name:
-
All Black 450 Watt Solar Home Panels
-
Junction Box:
-
IP68,3 diodes
-
Frame:
-
Anodized Aluminium Alloy
-
weight:
-
27.5kg
-
Front Glass:
-
3.2mm Coated Tempered Glass
-
Solar cell:
-
120;132;144;156
-
Efficiency:
-
19.73%-21.11%
-
Application:
-
Industrial
-
Packing:
-
Carton with pallet
-
Delivery time:
-
15-25days
Specification
|
166mm Series(STC)
|
|
|
|
|||
|
Model
|
LS166 360-375W HB
|
LS166 395-410W HB
|
LS166 435-450W HB
|
|||
|
Numbers of solar cells
|
120(60*2)
|
132(66*2）
|
144(72*2)
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
Maximum power range(Pmax)
|
360W-375W
|
395W-410W
|
435W-450W
|
|||
|
Open Circuit Voltage (Voc)
|
40.79V-41.37V
|
45.56V-46.23V
|
49.4V-49.98V
|
|||
|
Short Circuit Current (Isc)
|
11.18A-11.42A
|
11.19A-11.39A
|
11.36A-11.54A
|
|||
|
Voltage at Maximum power (Vmpp)
|
33.71V-34.34V
|
36.93V-37.64V
|
40.81V-41.4V
|
|||
|
Current Maximum Power (Impp)
|
10.68A-10.92A
|
10.70A-10.89A
|
10.66A-10.87A
|
|||
|
MODULE EFFICIENCY (%)
|
19.73-20.55
|
19.75-20.5
|
19.98-20.67
|
|||
|
182mm Series(STC)
|
|
|
|
|||
|
Model
|
LS182 485-500W HB
|
LS182 530-545W HB
|
LS182 575-590W HB
|
|||
|
Numbers of solar cells
|
132(66*2）
|
144(72*2)
|
156(78*2)
|
|||
|
Power Tolerance
|
0~+5W
|
|
|
|||
|
Maximum power range(Pmax)
|
485W-500W
|
530W-545W
|
575W-590W
|
|||
|
Open Circuit Voltage (Voc)
|
48.34V-48.83V
|
49.74V-50.18V
|
50.45V-51.02V
|
|||
|
Short Circuit Current (Isc)
|
12.99A-13.2A
|
13.62A-13.83A
|
14.41A-14.57A
|
|||
|
Voltage at Maximum power (Vmpp)
|
40.08V-40.62V
|
41.63V-42.12V
|
43.04V-43.48V
|
|||
|
Current Maximum Power (Impp)
|
12.10A-12.31A
|
12.73A-12.94A
|
13.36A-13.57A
|
|||
|
MODULE EFFICIENCY (%)
|
20.42-21.06
|
20.51-21.09
|
20.57-21.11
|
|||
Installation Instructions
2. Quality First
Before and After Lamination.
Strict supervision of product production details.
Most stringent acceptance criteria and tightest tolerance.
Strict supervision of product production details.
Most stringent acceptance criteria and tightest tolerance.
3. EL Testing
Every step of the production process is tested to ensure that quality products are
produced.
Before and Following Lamination Ensure"Zero"micro crack monitoring before final inspection.
Continuous line monitoring and video/photo record for each cell and panel.
produced.
Before and Following Lamination Ensure"Zero"micro crack monitoring before final inspection.
Continuous line monitoring and video/photo record for each cell and panel.
4.High quality inspection
Every product has a barcode that can be traced back to its origin.
The quality of the products is guaranteed.
Product after-sales service is guaranteed.
The quality of the products is guaranteed.
Product after-sales service is guaranteed.
Product Application
