Quick Details
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3500*1800*2900MM
-
Weight:
-
8000 kg
-
Name:
-
Animal Feed Pellet Machine
-
Capacity:
-
15-25T/H
-
Material:
-
Steel
-
Motor:
-
Siemens Brand
-
Color:
-
White AND light green
-
Function:
-
Aniaml Feed Puffed Pellet Machine
-
After Warranty Service:
-
Video technical suppor
Quick Details
-
Max. Capacity:
-
15 ton/h
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
YUDA
-
Voltage:
-
220V/380V
-
Dimension(L*W*H):
-
3500*1800*2900MM
-
Weight:
-
8000 kg
-
Name:
-
Animal Feed Pellet Machine
-
Capacity:
-
15-25T/H
-
Material:
-
Steel
-
Motor:
-
Siemens Brand
-
Color:
-
White AND light green
-
Function:
-
Aniaml Feed Puffed Pellet Machine
-
After Warranty Service:
-
Video technical suppor
|
NO. |
Item |
Parameter |
|
1 |
Capacity |
15-25 T/H |
|
2 |
Main motor power |
220 KW |
|
3 |
Feeder power |
2.2 KW |
|
4 |
Agitator power |
11 KW |
|
5 |
Inner diameter of die |
Φ 678 mm |
|
6 |
Pellet standard |
Φ 2 Φ 3 Φ4 Φ 4.5 Φ 5 Φ 6 Φ 8 Φ10 |
|
7 |
Qty. of roller |
2 |
|
8 |
Outer diameter of roller |
Φ 305 mm |
|
9 |
Rate of pellet formation |
≥95 % |
|
10 |
Rate of pellet powdering |
≤10 % |
|
11 |
Pellet stability in the water |
≥20 min |
|
12 |
Noise |
≤93 dB(A) |
|
13 |
Working temperature of die |
≤85 ℃ |
|
14 |
Steam consumption |
≥1.5 T/H |
|
15 |
Working pressure of steam |
0.2-0.4 MPa |
|
16 |
Temperature of steam |
130 – 150 ℃ |
|
17 |
Boundary dimension L×B×H mm |
3500*1800*2900 |
|
18 |
Weight |
About 8 Ton |
