JDSU 1550nm Optic Amplifier 19dB 1U 8 Port High Power EDFA Optical Switch

JDSU 1550nm Optic Amplifier 19dB 1U 8 Port High Power EDFA Optical Switch

FOB Reference Price: Get Latest Price

≥1 Pieces

US $850

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Output port:: 8ports

Input power:: -5~+10dbm

Each Output power:: 18dbm

Output Optic Power:: +29dbm

Optical connector:: SC/APC&SC/PC&FC/APC&SC/PC

MaterialSupply Voltage:: AC90-256V&DC48V

pump laser:: JDSU or Oclaro pump or others

Consumption:: <60W

Quick Details

Place of Origin:: Shandong, China

Product name:: 1550nm Optic Amplifier 19dB 1U 8 Port High Power EDFA Optical Switch

Wavelength:: 1530-1560nm

Output port:: 8ports

Input power:: -5~+10dbm

Each Output power:: 18dbm

Output Optic Power:: +29dbm

Optical connector:: SC/APC&SC/PC&FC/APC&SC/PC

MaterialSupply Voltage:: AC90-256V&DC48V

pump laser:: JDSU or Oclaro pump or others

Consumption:: <60W

JDSU 1550nm Optic Amplifier 19dB 1U 8 Port High Power EDFA Optical Switch

Product Information

Product Description

VX-EDFA8XX series of 1550nm ytterbium-doped fiber amplifier is designed and manufactured according to the communication level standards, amplifying the 1550nm optical signal, which is mainly used for TV image signal, digital television signals, telephone voice signals and data (or data compression) signal for a long distance optical fiber transmission.
With high-reliable multimode pump laser, it features low noise, high output power (≥4W) and high effeciency. To improve the reliablity, it has backup power supply for monitoring circuit. Special APC and ATC circuit ensure stable and reliable output power. The working parameters are shown on the LCD screen. It can be set by the buttons on the panel. When the device fails, it will alarm and shows the information on the screen. The perfect network management function with standard SNMP protocol makes it available to monitor by WEB or our own NMS remotely.

Features

1. High output power: output power is 16~24dBm per port.
2. Optical output power can be tuned in the range
3. Revise parameters by buttons and screen on the front panel
4. Network management function with standard SNMP protocol makes it available to monitor by WEB or our own NMS remotely.
5. Adapt variable frequency magnetic levitation fan to control temperature: when the temperature is lower than 30℃, fan runs with low speed. When the temperature of the whole set is between 30℃-50℃,the speed of fan will increase gradually. When the temperature of the whole set is higher than 50℃, fan runs with high speed.
6. Hot-swapped power supply with aluminium alloy housing, advanced in heat dissipation and replacement. Backup power supply makes it high stability and high reliability. AC220V and DC48V are available.

Appication

Single-mode fiber 1550 amplification network/ FTTH network/CATV network/PON network

Technique Parameter

Item	Unit	Technical parameter
CATV operation wavelength	nm	1545~1565
OLT pass wavelength	dB	1310/1490
Optical Output Power Tuning Range	dB	0.5 up and 6.0 down
Number of uplink optical ports		8
Input optical power	dBm	-5 ~ +10
Each output power	dB	18
Output power adjustable range	dBm	0~20
Input return loss		≥ 45
Output return loss	dB	≥ 45
Optical connector		SC/APC-SC/APC, SC/APC-SC/UPC,FC/APC-FC/APC
C/N	dB	≥ 50
C/CTB	dB	≥ 63
C/CSO	dB	≥ 63
Supply voltage		AC170V~265V,AC90~135V, DC36~72V
Power Consume	W	≤70
Network management interface		RJ45
Working temperature	℃	-10~+42
Max relative humidity	%	Max 95% no condensation
Storage temperature	℃	-30~+70
Product diagram	mm	480(L)440(W)50(H)
Product package weight	g	3500
