Quick Details
-
Size:
-
12500*2500*1550(According to customer requirement)
-
Place of Origin:
-
Shandong, China
-
Product name:
-
2 axle 40ft container semi trailer
-
Suspension:
-
Mechanical or Air
-
Color:
-
Customers Optional
-
Axle:
-
FUWA or BPW,3units
-
Twist Locks:
-
12units
-
Tire:
-
12.00r20,11.00r20,11r22.5,12r22.5
-
King pin:
-
JOST 2.0 Inch (50mm)/3.5 Inch (90mm)
-
Landing Gear:
-
28t Heavy Duty Landing Gear
-
Electrical System:
-
Voitage:24v
-
Function:
-
Transport 20ft 40ft Container
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
50Ton
-
Brand Name:
-
YuHang
-
Size:
-
12500*2500*1550(According to customer requirement)
-
Place of Origin:
-
Shandong, China
-
Product name:
-
2 axle 40ft container semi trailer
-
Suspension:
-
Mechanical or Air
-
Color:
-
Customers Optional
-
Axle:
-
FUWA or BPW,3units
-
Twist Locks:
-
12units
-
Tire:
-
12.00r20,11.00r20,11r22.5,12r22.5
-
King pin:
-
JOST 2.0 Inch (50mm)/3.5 Inch (90mm)
-
Landing Gear:
-
28t Heavy Duty Landing Gear
-
Electrical System:
-
Voitage:24v
-
Function:
-
Transport 20ft 40ft Container
2 Axle Trucks Chassis 40FT/45Ft Skeleton Semi Trailer
|
Trailer Model |
2 axle 40ft container skeleton transportation smi trailer |
|
Overall Dimension (Lx W x H) (mm) |
12500*2500*1550mm(According to customer requirement) |
|
Function |
Carry 40ft container or other stuff |
|
Main beam |
The height of the beam is 500mm,upper plate is 16mm,middle plate is 18mm, down plate is 10mm. |
|
Loading Weight |
60-100Ton |
|
Wheel base(mm) |
6800+1310+1310 |
|
Axle Brand |
2*13TON FUWA Axle |
|
Suspension |
10 pieces spring steel suspension |
|
Tire Type and quantity |
12R22.5 12units |
|
Traction Pin |
50mm or 90mm |
|
Landing Gear |
28ton double speed |
|
Brake system |
Dual Line braking system,none ABS |
|
Platform plate |
3mm |
|
Side beam |
16# box iron |
|
Container lock |
12pieces |
|
Spare tire carriers |
2 sets |
|
Tools box |
1 set |
|
Brake air chamber |
6 big dobule air chamber |
|
Electrical circuit |
24V,7 ways socket,one set 6-core standard cable |
|
Light |
Tail lamp with turn signal,brake light&reflector,side lamp etc. |
|
Painting |
According to the requirement of customers. |
