Quick Details
-
Screw Speed (rpm):
-
120 rpm
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Batten
-
Power (kW):
-
22
-
Weight:
-
8000 KG
-
Gearbox:
-
ZLYJ-173*2
-
cooling fans:
-
330W
-
heaters:
-
Ceramic heater
-
Frequency converter:
-
22kW
-
output:
-
80-130 kg/h
-
Die diameter(mm):
-
D120 (HDPE)
-
Mould structure:
-
Low voltage dedicated ABA
-
Marketing Type:
-
New Product 2021
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
30:1
-
Screw diameter (mm):
-
55
-
Screw Speed (rpm):
-
120 rpm
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Batten
-
Power (kW):
-
22
-
Weight:
-
8000 KG
-
Gearbox:
-
ZLYJ-173*2
-
cooling fans:
-
330W
-
heaters:
-
Ceramic heater
-
Frequency converter:
-
22kW
-
output:
-
80-130 kg/h
-
Die diameter(mm):
-
D120 (HDPE)
-
Mould structure:
-
Low voltage dedicated ABA
-
Marketing Type:
-
New Product 2021
Product Description
| main engine | |||
| Specification | Technical parameters and models | ||
| Gearbox | ZLYJ-173*2 | ||
| screw |
φ55 mm *2
Nitriding hardness HV900 |
||
| Screw material | 38CrMoAl + alloy | ||
| L/D ratio | 30:1(HDPE) | ||
| Screw speed(r/min) | 0-120 | ||
| Minimum film thickness(mm) | Single side 0.01 | ||
| Maximum film thickness(mm) | Low pressure single side 0.07 | ||
| cooling fans | 330W*2 | ||
| heaters | Ceramic heater | ||
| Main motor of extruder | 22KW *2 frequency conversion | ||
| Frequency converter | 22KW*2 | ||
| Temperature controller | Intelligent dual digital display type | ||
| Head flange | Threaded link | ||
| filter heater | Ceramic double heating | ||
| Change the screen way | Manual mode screen change | ||
| Hopper feeding method | Manual feeding | ||
| Mainframe cover | Integral | ||
| Paint color | Blue for host and blue for railing | ||
| Rack square steel |
120*120mm
thickness 4mm |
||
| output | 80-130 kg/h | ||
