- Product Details
- {{item.text}}
Quick Details
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
GODEX
-
Place of Origin:
-
Guangdong, China
-
Use:
-
Receipt Printer
Quick Details
-
Max Paper Size:
-
105±0.5mm
-
Black Print Speed:
-
102MM/S
-
Color Print Speed:
-
/
-
Max. Resolution:
-
300dpi
-
Brand Name:
-
GODEX
-
Place of Origin:
-
Guangdong, China
-
Use:
-
Receipt Printer
Products Description
There's main four types material printer ribbon use on barcode printer, divide into wax, wax resin, resin and wash resin.
Wax mostly suits for rough coated paper label material, wax resin suits for adhesive paper sticker and BOPP, but its anti-scratch is much better than normal wax ribbon; Resin suits for synthetic label material like pp, bopp pvc plastic, Polyester PET, synthetic paper ; another special ribbon type is wash resin suits for many kinds garment/ clothing wash care label with waterproof, washable and durable features after washed or in severe environment.
Wash ribbon is one type of durable material designed for printing on wash care labels that made of polyamide nylon taffeta, polyester fabrics satin ribbon, tyvek, iron on label, tpu and others types. Mainly used for garment, shoes, bag, present fields, with high washability and superior resistance to dry cleaning, sweat, heat and waterproof.
Applications fields:
Wide use in logistic industry , warehouse industry , Garment industry, retailer supermarket, factory , garment processing,
Hotel management, Home appliances digital products, Pharamaceutical industry etc.
Wax mostly suits for rough coated paper label material, wax resin suits for adhesive paper sticker and BOPP, but its anti-scratch is much better than normal wax ribbon; Resin suits for synthetic label material like pp, bopp pvc plastic, Polyester PET, synthetic paper ; another special ribbon type is wash resin suits for many kinds garment/ clothing wash care label with waterproof, washable and durable features after washed or in severe environment.
Wash ribbon is one type of durable material designed for printing on wash care labels that made of polyamide nylon taffeta, polyester fabrics satin ribbon, tyvek, iron on label, tpu and others types. Mainly used for garment, shoes, bag, present fields, with high washability and superior resistance to dry cleaning, sweat, heat and waterproof.
Applications fields:
Wide use in logistic industry , warehouse industry , Garment industry, retailer supermarket, factory , garment processing,
Hotel management, Home appliances digital products, Pharamaceutical industry etc.
|
Item NO.
|
Print Speed
|
Print Width
|
Resolution
|
Print Mode
|
Label Diameter
|
Size
|
|
EZ-120
|
102mm/s
|
108mm
|
203 dpi
|
thermal/
thermal transfer
|
127mm
|
285*226*171mm
|
|
EZ-130
|
76.2mm/s
|
105.7mm
|
300 dpi
|
|
127mm
|
285*226*171mm
|
|
G500
|
127mm/s
|
108mm
|
203 dpi
|
|
108mm
|
285*226*171mm
|
|
G530
|
102mm/s
|
105.7mm
|
300 dpi
|
|
108mm
|
285*226*171mm
|
|
EZ-1100Plus
|
102mm/s
|
108mm
|
203 dpi
|
|
127mm
|
285*226*171mm
|
|
RT863i
|
76mm/s
|
106mm
|
600 dpi
|
|
127mm
|
285*210*186mm
|
|
Print Method
|
Thermal Transfer / Direct Thermal
|
|
Resolution
|
203 dpi (8 dots/mm)
|
|
Print Speed
|
5IPS (127 mm/s)
|
|
Print Width
|
4.25" (108 mm)
|
|
Print Length
|
Min. 0.16" (4 mm)**; Max. 68" (1727 mm)
|
|
Processor
|
32 Bit RISC CPU
|
|
Memory
|
8MB Flash (4MB for user storage) / 16MB SDRAM
|
|
Sensor Type
|
Adjustable reflective sensor. Fixed transmissive sensor, central aligned
|
|
Media
|
Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: 1" (25.4 mm) Min. - 4.64" (118 mm) Max. Thickness: 0.003" (0.06 mm) Min. - 0.01" (0.25 mm) Max. Label roll diameter: Max. 5" (127 mm) Core diameter: 1", 1.5", 3" (25.4 mm, 38.1 mm, 76.2 mm) |
|
Ribbon
|
Types: Wax, wax/resin, resin
Length: 981` (300 m) Width: 1.18" Min - 4.33" (30 mm - 110 mm) Max Ribbon roll diameter.: 2.67" (68 mm) Core diameter: 1" (25.4 mm) |
|
Printer Language
|
EZPL, GEPL, GZPL auto switch
|
|
Software
|
Label design software: QLabel-IV (for EZPL only), GoLabel (for EZPL only)
Driver: Windows 2000, XP, Vista, 7, 8,Windows Server 2003 & 2008 DLL: Windows 2000, XP and Vista |
|
Resident Fonts
|
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
|
Download Fonts
|
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions Scalable fonts 90°, 180°, 270° rotatable |
|
Barcodes
|
1-D Bar codes:
Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM and GS1 DataBar 2-D Bar codes: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code |
|
Code Pages
|
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257 Unicode (UTF8, UTF16) |
|
Graphics
|
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257 Unicode (UTF8, UTF16) |
|
Interfaces
|
USB + Parallel Port
USB + Serial Port + Ethernet |
|
Control Panel
|
Two bi-color status-LEDs: Ready, Status
Control key: FEED |
|
Power
|
Auto Switching 100-240VAC, 50-60Hz
|
|
Environment
|
Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C) |
|
Humidity
|
Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing. |
|
Agency Approvals
|
CE(EMC), FCC Class A, CB, cUL, CCC
|
|
Dimension
|
Length: 11.2" (285 mm)
Height: 6.8" (171 mm) Width: 8.9" (226 mm) |
|
Weight
|
6 lbs (2.72Kg) ,excluding consumables
|
|
Options
|
Cutter Module
Label Dispenser External label roll holder for 10" (250 mm) O.D. label rolls External label rewinder |
|
Note
|
* Specifications are subject to change without notice. All company and/or product names are trademarks and/or registered
trademarks of their respective owners. ** Minimum print height and maximum print speed specification compliance can be dependent on non-standard material variables such as label type, thickness, spacing, liner construction, etc. |
